Passtech SL300 User Manual

Rf&keypad integrated slim locker lock
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER GUIDE
RF&KEYPAD INTEGRATED
SLIM LOCKER LOCK
(Model : SL300 / SL300E)
Passtech Co., Ltd.
Copyright ⓒ 2021 Passtech Co., Ltd. All rights reserved. You are strictly prohibited to copy, disclose,
distribute, or use this document in part or as a whole for any purposes other than those for which this
document is disclosed. This document is copyrighted and contains confidential information and other
intellectual property rights of Passtech Inc. Any unauthorized use, copy, disclosure or distribution constitutes
infringement of Passtech's intellectual property rights.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL300 and is the answer not in the manual?

Questions and answers

Related Manuals for Passtech SL300

Summary of Contents for Passtech SL300

  • Page 1 (Model : SL300 / SL300E) Passtech Co., Ltd. Copyright ⓒ 2021 Passtech Co., Ltd. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed.
  • Page 2 SL300 / SL300E Lock User Guide Passtech Co., Ltd. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. Passtech provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.

  • Page 3: Table Of Contents

    SL300 / SL300E Lock User Guide Table of Contents 1. Understanding SL300 / SL300E LOCKER LOCK ....4 1.1 What is SL300 / SL300E LOCKER LOCK? ........4 1.2 Features by model ................4 1.3 Operating cards .................. 5 2. Types of Lock Operating Scenario ........6 2.1 Free Selection (Shared Use) ..............

  • Page 4: Understanding Sl300 / Sl300E Locker Lock

    1. Understanding SL300 / SL300E LOCKER LOCK 1.1 What is SL300 / SL300E LOCKER LOCK? SL300 / SL300E LOCKER LOCK locker locks are the locker lock operated by either13,56 MHz RF Card Key. SL300 / SL300E LOCKER LOCK can work as both offline (standalone) or online mode.

  • Page 5: Operating Cards

    SL300 / SL300E Lock User Guide 1.3 Operating cards Card Card Name Description type • Security Key value to be loaded to locks at scanning. • Then, the locks will accept only the RFID cards which have the same card security key value.

  • Page 6: Types Of Lock Operating Scenario

    SL300 / SL300E Lock User Guide 2. Types of Lock Operating Scenario SL300 / SL300E LOCKER LOCK locker locks are designed to work for the various operation requirements by simple set up process. Following operation modes can be programmed before or after lock installation.

  • Page 7: Lock Operation

    3. Lock Operation 3.1 RF tag uses ① SL300 / SL300E LOCKER LOCK can be set with two different credential acceptance modes. ② RF tag mode accepts RF tag ③ These modes can be set from Maintenance card (or setup card) 3.2 Assigned Mode...
  • Page 8 SL300 / SL300E Lock User Guide (3) Registration via Mobile App Run the mobile App. If you are not registered yet, the registration page will show up right after you start the mobile application. Otherwise, go to Menu and press the “Registration”...

  • Page 9: Free Selection Mode

    3.3.1 Open & Close by RF card key ① Touch the lock + Put User card on the lock. 3.3.2 Open & Close by Smartphone How it works ① Download Passtech Mobile App from Google play store and install it into his smartphone Version 1.0 http://www.esmartlock.com...

  • Page 10: Open In Emergency

    ③ Then, you can freely choose any available lock to operate. To access your mobile device, please set your lock for CSN Free mode and change the usage mode to Free mode from the Passtech APP from your mobile device.
  • Page 11 SL300 / SL300E Lock User Guide CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Version 1.0 http://www.esmartlock.com...

  • Page 12: Card Operation

    SL300 / SL300E Lock User Guide 4. Card Operation 4.1 Owner Card The role of the Owner card is to delete the Master card registration. Therefore, Owner card will be used to delete current master card registration in the lock, and make the lock to be ready to register new Master Card.

  • Page 13: User Card

    SL300 / SL300E Lock User Guide Put the Maintenance card to the locks, then, new Master cards will be registered to ③ the lock, and lost master card will be blocked. (2) Using Owner Card Delete the old master card registrations in the lock (refer to the 4.1) with Owner Card.

  • Page 14: Assigned Mode (Permanent Use)

    SL300 / SL300E Lock User Guide 4.3.2 Assigned Mode (Permanent Use) The initial status of the lock in Assigned Mode is closed status (latch out) ① Touch to wake up the lock. ② Put the User Card to the front body of the assigned lock.

  • Page 15: Audit Trail Card

    SL300 / SL300E Lock User Guide 4.5 Audit Trail card ① Put Audit Trail Card to the lock. ② The latest event data (up to 150 events) will be downloaded from lock to the Card. Wait until melody is on.

  • Page 16: Indication Instruction

    Mifare Classic & Desfire at default, ISO14443 Type A Indicator Buzzer, Red/Green LED, E-PAPER (SL300E, SL600E only) Dimension FRONT (W*H*D) SL300, SL300E : 58mm * 87mm * 11.5mm Operation TEMP 0 °C to 50 °C Battery life 1.5year (online) 2year (stand alone) Certification FCC, CE Version 1.0...

  • Page 17: Annex A Beep & Led Table

    SL300 / SL300E Lock User Guide ANNEX A Beep & LED Table Beep Description 1 x short beep 1 x Green(2sec) 2 x short beep 1 x Red(2sec) Operation Error 3 x short beep 1 x Red & Green in...
  • Page 18 SL300 / SL300E Lock User Guide 1) Master card registration should be followed after deleting old Master card in the lock by Master card registration in the lock Owner card. was failed. 2) Put Master card on the lock before waiting time is out after Owner card.

  • Page 19: Regulatory Statement

    SL300 / SL300E Lock User Guide 7 Regulatory Statement FCC Part 15.105 statement (Class B) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
