global_main.book.book Page 1 Tuesday, January 19, 2021 6:41 PM
OWNER'S MANUAL
FRIDGE & FREEZER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
MFL67447819
Rev.07_012021
Copyright © 2016-2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG GSX971NEAE
Summary of Contents for LG GSX971NEAE
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH www.lg.com MFL67447819 Rev.07_012021 Copyright © 2016-2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Before Use ......................19 Product Features....................21 Control Panel ....................24 Ice and Water Dispenser.................25 Automatic Icemaker ..................27 InstaView......................29 Door in Door .....................30 Drawer.......................30 Shelf ........................31 Door Basket ......................32 SMART FUNCTIONS LG ThinQ Application ..................33 Smart Diagnosis ....................34 MAINTENANCE Cleaning ......................36 Air Filter ......................36... - Page 3 global_main.book.book Page 3 Tuesday, January 19, 2021 6:41 PM Water Filter .......................37 TROUBLESHOOTING Before Calling for Service................40...
-
Page 4: Safety Instructions
global_main.book.book Page 4 Tuesday, January 19, 2021 6:41 PM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. - Page 5 global_main.book.book Page 5 Tuesday, January 19, 2021 6:41 PM SAFETY INSTRUCTIONS appliance. Cleaning and user maintenance shall not be made by children without supervision. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 • Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
- Page 7 global_main.book.book Page 7 Tuesday, January 19, 2021 6:41 PM SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials • If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
- Page 8 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
- Page 9 • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
-
Page 10: Caution
global_main.book.book Page 10 Tuesday, January 19, 2021 6:41 PM SAFETY INSTRUCTIONS Disposal • When discarding the appliance, remove the door gasket while leaving the shelves and baskets in place and keep children away from the appliance. CAUTION CAUTION To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Operation... -
Page 11: Caring For The Environment
They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • To remove frost from the appliance, contact an LG Electronics customer information centre. • Dispose of the ice inside the ice bin in the freezer compartment during an extended power outage. -
Page 12: Installation Before Installation
global_main.book.book Page 12 Tuesday, January 19, 2021 6:41 PM INSTALLATION INSTALLATION Before Installation Ambient Temperature • The appliance is designed to operate within a Dimensions and Clearances limited range of ambient temperatures, depending on the climate zone. Too small of a distance from adjacent items may result in the degradation of freezing capability and •... -
Page 13: Removing The Fridge And Freezer Door
global_main.book.book Page 13 Tuesday, January 19, 2021 6:41 PM INSTALLATION Accessories Rotate the hinge lever clockwise. Lift the top hinge free of the hinge lever latch *1 This feature is only available on some models. CAUTION Spanner A Spanner B •... - Page 14 global_main.book.book Page 14 Tuesday, January 19, 2021 6:41 PM INSTALLATION collet to detach the water supply line. Rotate the hinge lever counterclockwise. Lift Unscrew the cover the top hinge free of the hinge lever latch CAUTION • When lifting the hinge free of the latch, be careful that the door does not fall forward.
-
Page 15: Connecting The Water Line
global_main.book.book Page 15 Tuesday, January 19, 2021 6:41 PM INSTALLATION If a reverse osmosis water filtration system is NOTE connected to your cold water supply, the water pressure to the reverse osmosis system needs to • Disassembling/Assembling the water lines be a minimum of 138 kPa to 827 kPa (1.4-8.4 kgf/ cm²) WARNING... -
Page 16: Levelling And Door Alignment
global_main.book.book Page 16 Tuesday, January 19, 2021 6:41 PM INSTALLATION Connecting to the Water Tap Checking the Water Connection This feature is only available on some models. Turn on the water supply and switch on the appliance. Carefully check all fittings for Push the water tube into the hole of the tap possible leaks due to poorly fitted hoses. -
Page 17: Turning On The Power
global_main.book.book Page 17 Tuesday, January 19, 2021 6:41 PM INSTALLATION Levelling the Appliance Use the spanner to adjust the height by turning the adjustment hinge pin to the left or The appliance has two front levelling legs. Adjust to the right. the legs to alter the tilt from front to back or side to side. -
Page 18: Moving The Appliance For Relocation
global_main.book.book Page 18 Tuesday, January 19, 2021 6:41 PM INSTALLATION NOTE • After connecting the power supply cord (or plug) to the outlet, wait 3 or 4 hours before you put food into the appliance. If you add food before the appliance has cooled completely, your food may spoil. -
Page 19: Operation Before Use
NOTE specifications. If you wish to minimise the impact • Contact the LG Electronics customer information on the food storage due to a temperature rise, centre if the alarm sound continues even after seal or wrap the stored food in several layers. - Page 20 global_main.book.book Page 20 Tuesday, January 19, 2021 6:41 PM OPERATION • Do not store food for a long period of time if it • Express Frz. must be switched on for 7 hours spoils easily at a low temperature. before fresh products are placed in the freezer compartment.
-
Page 21: Product Features
global_main.book.book Page 21 Tuesday, January 19, 2021 6:41 PM OPERATION Product Features The appearance or components of the appliance may differ from model to model. Exterior *1 This feature is only available on some models. Control Panel Sets the refrigerator temperature and freezer temperature, the water filter condition and the dispenser mode. - Page 22 global_main.book.book Page 22 Tuesday, January 19, 2021 6:41 PM OPERATION Interior (Two Star *1 This feature is only available on some models. Door in Door Model: InstaView Door in Door Model: LED Lamp The LED lamps inside the appliance light up when you open the door. Automatic Icemaker This is where ice is automatically produced and stored.
- Page 23 global_main.book.book Page 23 Tuesday, January 19, 2021 6:41 PM OPERATION Stores frozen food for longer storage. • The bottom drawer is not 2 star compartment according to new energy labeling regulation (EU) 2019/ 2016. Freezer Door Basket Stores small packages of frozen food. Do not store ice cream or food which will be stored for a long period of time.
-
Page 24: Control Panel
global_main.book.book Page 24 Tuesday, January 19, 2021 6:41 PM OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Pure N Fresh This function reduces odours inside the fridge. If the Replace indicator lights up, replace the filter. Express Freeze This function can quickly freeze a large amount of ice or frozen foods. -
Page 25: Ice And Water Dispenser
Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the LG ThinQ application. Water & Ice Type Select a desired dispenser mode from the buttons on the control panel. Press the dispenser switch with a glass or other container to dispense cubed ice, water or crushed ice. - Page 26 global_main.book.book Page 26 Tuesday, January 19, 2021 6:41 PM OPERATION NOTE NOTE • When the ice maker produces smaller ice cubes, • Lint from a cloth may adhere to the outlets. or the cubes become lumped together, the amount of water supplied to the ice maker may be low due to insufficient water in the water Cleaning the Dispenser Tray tank.
-
Page 27: Automatic Icemaker
global_main.book.book Page 27 Tuesday, January 19, 2021 6:41 PM OPERATION Fill with bottle or filtered water up to the NOTE maximum fill line. (Total capacity: 4 ℓ) • Before using the water dispenser tank after installing the appliance, it should be washed before filling it with water. - Page 28 It may result in injury. • If discolored ice is dispensed, check the water tank and the water supply for a possible source. If the problem continues, contact the LG Electronics customer information centre. Do not Removing/Refitting the Ice use the ice or water until the problem is corrected.
-
Page 29: Instaview
global_main.book.book Page 29 Tuesday, January 19, 2021 6:41 PM OPERATION Hold the ice bin with both hands and pull it out NOTE while lifting it upward. • Do not keep the power turned on to the icemaker if the water line is not connected. Doing so can damage the icemaker. -
Page 30: Door In Door
global_main.book.book Page 30 Tuesday, January 19, 2021 6:41 PM OPERATION Knock twice on the glass to turn the LED light CAUTION inside the Door in Door on or off. • Do not open the door of the appliance with the door in door open, or do not open the door in The LED light turns off automatically after ten door while the door of the appliance is open. -
Page 31: Shelf
global_main.book.book Page 31 Tuesday, January 19, 2021 6:41 PM OPERATION • Make sure that the fridge doors are fully open Lift the vegetable drawer up and remove it by before removing and refitting the drawers. pulling it out. Using the Vegetable Drawer *1 This feature is only available on some models. -
Page 32: Door Basket
global_main.book.book Page 32 Tuesday, January 19, 2021 6:41 PM OPERATION Pull the shelf out. Mount them in the reverse order of the removal process. Mount them in the reverse order of the removal process. CAUTION • Glass shelves are heavy. Use special care when removing them. -
Page 33: Smart Functions
Internet service provider or refer to your appliance improvement purposes without notice wireless router manual. to users. • LG ThinQ is not responsible for any network • Functions may vary by model. connection problems or any faults, malfunctions, or errors caused by network connection. -
Page 34: Smart Diagnosis
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in The Wi-Fi button, when used with the LG ThinQ this product, please visit http:// application, allows the appliance to connect to a opensource.lge.com. - Page 35 LG ThinQ application. NOTE • Launch the LG ThinQ application and select the • For best results, do not move the phone while Smart Diagnosis feature in the menu. Follow the tones are being transmitted.
-
Page 36: Maintenance Cleaning
global_main.book.book Page 36 Tuesday, January 19, 2021 6:41 PM MAINTENANCE MAINTENANCE Cleaning Cleaning the Interior • When removing a shelf or drawer from inside General Cleaning Tips the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to •... - Page 37 • Caution should be taken not to change the the LG Electronics Customer Information Centre. direction of the filter to be inserted into the filter For further assistance, visit our website at lg.com cover. If the Replace icon is lit on the control panel, replace the air filter.
- Page 38 - Use replacement cartridge: ADQ736939** Dispense water for approximately 5 minutes to - Visit your local dealer or distributor or contact remove trapped air and contaminants from the the LG Electronics Customer Information system. Centre. For further assistance, visit our website at lg.com...
- Page 39 CAUTION • Failure to replace filters when required or using non LG authorised water filters can cause the filter cartridge to leak and result in property damage. NOTE • Application Guidelines/Water Supply Parameters - Service Flow: 1.9 lpm...
- Page 40 • Press I on the automatic icemaker switch or set ON for the automatic icemaker button on the control panel. (For more details on how to use, visit LG Electronics website or use your smart device.) Is the temperature of the freezer compartment set too high? •...
- Page 41 global_main.book.book Page 41 Tuesday, January 19, 2021 6:41 PM TROUBLESHOOTING Symptoms Possible Cause & Solution Ice is not dispensed. Unable to hear the sound of ice coming out? • In the control panel, select the modes for cubed ice and crushed ice alternately to dispense the ice.
- Page 42 global_main.book.book Page 42 Tuesday, January 19, 2021 6:41 PM TROUBLESHOOTING Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Check the power of other appliances. •...
- Page 43 global_main.book.book Page 43 Tuesday, January 19, 2021 6:41 PM TROUBLESHOOTING Condensation & Frost Symptoms Possible Cause & Solution There is condensation Did you store hot food without cooling it first? inside the appliance or • Cool the hot food first before putting it inside the fridge or freezer. on the bottom of the vegetable drawer Did you leave the appliance door open?
- Page 44 The inside lamp in the Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp.
- Page 45 global_main.book.book Page 45 Tuesday, January 19, 2021 6:41 PM TROUBLESHOOTING Noises Symptoms Possible Cause & Solution The appliance is noisy Is the appliance installed on a weak floor or improperly levelled? and generates • Install the appliance on a solid and flat area. abnormal sounds.
- Page 46 • Spare parts referenced in Regulation EU 2019/2019 are available for 7 years (only door gaskets are available for 10 years). • To purchase spare parts, contact an LG Electronics customer information centre or our website at www.lg.com.
- Page 47 global_main.book.book Page 47 Tuesday, January 19, 2021 6:41 PM TROUBLESHOOTING NOTE • Regulation EU 2019/2019, valid from 1st March 2021, is related to the Energy Efficiency classes by Regulation EU 2019/2016. • For more information about the energy efficiency of the appliance, visit https://ec.europa.eu and search using the model name (valid from 1st March 2021).
