global_main.book.book Page 1 Wednesday, January 15, 2025 8:09 AM
OWNER'S MANUAL
FRIDGE & FREEZER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
GS-X6104BE / GS-X6104EV / GS-L6104PY / GS-L6104EV
MFL72093750
Rev.00_011525
Scan the QR code to see the manual.
Copyright © 2025 LG Electronics. All Rights Reserved
www.lg.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the GS-L6104PY and is the answer not in the manual?

Questions and answers

Summary of Contents for LG GS-L6104PY

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH GS-X6104BE / GS-X6104EV / GS-L6104PY / GS-L6104EV www.lg.com MFL72093750 Rev.00_011525 Copyright © 2025 LG Electronics. All Rights Reserved...
  • Page 2 Product Features....................22 Control Panel ....................26 Ice and Water Dispenser.................28 Automatic Icemaker ..................30 InstaView......................33 Door in Door .....................34 Drawer.......................34 Shelf ........................35 Door Basket ......................35 SMART FUNCTIONS LG ThinQ Application ..................36 Smart Diagnosis ....................38 MAINTENANCE Cleaning ......................39 Air Filter ......................40 Water Filter .......................40...
  • Page 3 global_main.book.book Page 3 Wednesday, January 15, 2025 8:09 AM TROUBLESHOOTING Before Calling for Service................43...
  • Page 4 global_main.book.book Page 4 Wednesday, January 15, 2025 8:09 AM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.
  • Page 5 global_main.book.book Page 5 Wednesday, January 15, 2025 8:09 AM SAFETY INSTRUCTIONS responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. • This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices and other working environments;...
  • Page 6 • Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
  • Page 7 global_main.book.book Page 7 Wednesday, January 15, 2025 8:09 AM SAFETY INSTRUCTIONS several minutes. In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance is used should correspond to the amount of refrigerant used.
  • Page 8 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
  • Page 9 SAFETY INSTRUCTIONS • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
  • Page 10 global_main.book.book Page 10 Wednesday, January 15, 2025 8:09 AM SAFETY INSTRUCTIONS - If using an icemaker or dispenser water tank, make sure to fill it with potable water only. Disposal • When discarding the appliance, remove the door gasket while leaving the shelves and baskets in place and keep children away from the appliance.
  • Page 11 They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • To remove frost from the appliance, contact an LG Electronics customer information centre. • Dispose of the ice inside the ice bucket in the freezer compartment...
  • Page 12 global_main.book.book Page 12 Wednesday, January 15, 2025 8:09 AM INSTALLATION INSTALLATION Before Installation Ambient Temperature • The appliance is designed to operate within a Dimensions and Clearances limited range of ambient temperatures, depending on the climate zone. Too small of a distance from adjacent items may result in the degradation of freezing capability and •...
  • Page 13 global_main.book.book Page 13 Wednesday, January 15, 2025 8:09 AM INSTALLATION Accessories collet to detach the water supply line. Unscrew the cover *1 This feature is only available on some models. Spanner A Spanner B Water Filter Water Tube Remove the screw from the hinge cover at the top of the appliance.
  • Page 14 global_main.book.book Page 14 Wednesday, January 15, 2025 8:09 AM INSTALLATION Removing the Fridge Door Rotate the hinge lever counterclockwise. Lift the top hinge free of the hinge lever latch Disconnect all wire harnesses CAUTION NOTE • When lifting the hinge free of the latch, be •...
  • Page 15 global_main.book.book Page 15 Wednesday, January 15, 2025 8:09 AM INSTALLATION Lift the fridge door until it is free of the bottom Correct hinge assembly. Incorrect • If the water tube end is damaged, it should be trimmed to ensure it does not leak when refitted. CAUTION •...
  • Page 16 global_main.book.book Page 16 Wednesday, January 15, 2025 8:09 AM INSTALLATION Push the water tube into the hole of the tap WARNING connector supplied in the accessories. The pipe • Only connect the water line to a cold water should be held firmly whilst the connector is supply.
  • Page 17 global_main.book.book Page 17 Wednesday, January 15, 2025 8:09 AM INSTALLATION Levelling and Door Use the spanner to adjust the height by turning the levelling leg to the left to raise it or to the right Alignment to lower it. Before Beginning When the appliance doors appear to be uneven, follow the instructions below to align the doors.
  • Page 18 global_main.book.book Page 18 Wednesday, January 15, 2025 8:09 AM INSTALLATION the appliance has cooled completely, your food Open the door and use the spanner may spoil. loosen the keeper nut by turning it to the left. • To turn off the appliance, disconnect the power plug from the outlet socket.
  • Page 19 global_main.book.book Page 19 Wednesday, January 15, 2025 8:09 AM INSTALLATION - Do not move the appliance in zigzags. After installing the appliance, connect the power plug into a mains outlet socket and switch it on.
  • Page 20 3 cm from the sensor. completely closed. NOTE Storing Foods Effectively • Contact the LG Electronics customer information centre if the alarm sound continues even after • Food may freeze or spoil if stored at the wrong closing all doors.
  • Page 21 global_main.book.book Page 21 Wednesday, January 15, 2025 8:09 AM OPERATION • Do not store food for a long period of time if it • Express Freeze must be switched on for 7 hours spoils easily at a low temperature. before fresh products are placed in the freezer compartment.
  • Page 22 global_main.book.book Page 22 Wednesday, January 15, 2025 8:09 AM OPERATION Product Features The appearance or components of the appliance may differ from model to model. Exterior *1 This feature is only available on some models. Dispenser Control Panel Sets the the dispenser mode. Door in Door This is a convenient storage area for frequently-used items that require easy access.
  • Page 23 global_main.book.book Page 23 Wednesday, January 15, 2025 8:09 AM OPERATION Interior (Two Star *1 This feature is only available on some models. LED Lamp The LED lamps inside the appliance light up when you open the door.
  • Page 24 global_main.book.book Page 24 Wednesday, January 15, 2025 8:09 AM OPERATION Temperature Sensor This sensor senses the temperature of the fridge compartment. • Maintain the distance between the sensor and food to accurately sense the temperature. Automatic Icemaker This is where ice is automatically produced and stored. Freezer Shelf Stores frozen food such as meat, fish, and ice cream.
  • Page 25 global_main.book.book Page 25 Wednesday, January 15, 2025 8:09 AM OPERATION • Do not use it as the ice bin or place it on the shelf on top of the fridge or the vegetable drawer. Bottom Drawer Cover This is the bottom drawer cover. CAUTION •...
  • Page 26 global_main.book.book Page 26 Wednesday, January 15, 2025 8:09 AM OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Control Panel Dispenser Control Panel Ice On/Off Press and hold the Ice On/Off button for three seconds to turn the automatic icemaker On/Off.
  • Page 27 Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the LG ThinQ application. Water Filter Replace the water filter when the indicator light turns on.
  • Page 28 global_main.book.book Page 28 Wednesday, January 15, 2025 8:09 AM OPERATION Water & Ice Type Select the desired dispenser mode from the buttons on the dispenser control panel. Press the dispenser switch with a glass or other container to dispense cubed ice, water or crushed ice. NOTE •...
  • Page 29 global_main.book.book Page 29 Wednesday, January 15, 2025 8:09 AM OPERATION Filling the Water Tank with Press the dispenser paddle with a glass or Water other container to dispense cubed ice, water or crushed ice. This feature is only available on some models. The water tank holds the water to be dispensed or used by the automatic icemaker to make ice.
  • Page 30 global_main.book.book Page 30 Wednesday, January 15, 2025 8:09 AM OPERATION • If there is an insufficient amount of water in the After filling with water, close the cover or cap of water dispenser tank, ice cube size and quantity the water dispenser tank. may be affected and may result in no ice being made.
  • Page 31 • If discoloured ice is dispensed, check the water tank and the water supply for a possible source. Icemaker If the problem continues, contact the LG Electronics customer information centre. Do not use the ice or water until the problem is NOTE corrected.
  • Page 32 global_main.book.book Page 32 Wednesday, January 15, 2025 8:09 AM OPERATION Turn off the automatic icemaker. Press and NOTE hold the Ice On/Off button on the control • The icemaker begins producing ice panel for 3 seconds. approximately 48 hours after the appliance is initially installed.
  • Page 33 global_main.book.book Page 33 Wednesday, January 15, 2025 8:09 AM OPERATION InstaView not continue to make ice due to sensor disruption. This feature is only available on some models. Using the InstaView Turning the Icemaker On/Off The InstaView lets you see if you’re running low on frequently used items like beverages and snacks, To turn the automatic icemaker On/Off, press and without opening the fridge door.
  • Page 34 global_main.book.book Page 34 Wednesday, January 15, 2025 8:09 AM OPERATION Door in Door The temperature in the Fresh Converter can be controlled by sliding the lever , where located in This feature is only available on some models. front of compartment, in either direction. Using the Door in Door Pull the lever at the bottom of the door upwards until the door in door opens.
  • Page 35 global_main.book.book Page 35 Wednesday, January 15, 2025 8:09 AM OPERATION Door Basket Refit the drawer in the reverse order of the removal process. Removing/Refitting the Door Basket Shelf Hold both edges of the basket and remove it by lifting it upward. CAUTION •...
  • Page 36 Google Play Store or Apple App Store to users. on a smartphone. • Functions may vary by model. Run the LG ThinQ application and sign in with your existing account or create an LG account to sign in. Touch the add ( ) button on the LG ThinQ application to connect your LG appliance.
  • Page 37 To check your network frequency, contact your Internet service provider or refer to your wireless router manual. Radio Equipment Specifications • LG ThinQ is not responsible for any network connection problems or any faults, malfunctions, or errors caused by network Module Name LCWB-001 connection.
  • Page 38 LG ThinQ application. NOTE • Launch the LG ThinQ application and select the • For best results, do not move the phone while Smart Diagnosis feature in the menu. Follow the tones are being transmitted.
  • Page 39 global_main.book.book Page 39 Wednesday, January 15, 2025 8:09 AM MAINTENANCE MAINTENANCE Cleaning Cleaning the Interior • Before removing a shelf or drawer from inside General Cleaning Tips the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to •...
  • Page 40 global_main.book.book Page 40 Wednesday, January 15, 2025 8:09 AM MAINTENANCE Air Filter Dry it using a hair dryer or by exposing it to sunlight. The filter is reusable. Reusing the Air Filter You can remove the odors absorbed by the Air Filter and reuse it.
  • Page 41 • To purchase a replacement water filter: back into the compartment. - Use replacement cartridge: LT1000P, LT1000PC, LT1000PCS or ADQ747935** - Visit your local dealer or distributor or contact the LG Electronics Customer Information Centre. For further assistance, visit our website at lg.com...
  • Page 42 Dispense water for approximately 5 minutes to remove trapped air and contaminants. CAUTION • Failure to replace filters when required or using non LG authorised water filters can cause the filter cartridge to leak and result in property damage. Application Guidelines/Water Supply Parameters •...
  • Page 43 • Press I on the automatic icemaker switch or set ON for the automatic icemaker button on the control panel. (For more details on how to use, visit LG Electronics website or use your smart device.) Is the temperature of the freezer compartment set too high? •...
  • Page 44 global_main.book.book Page 44 Wednesday, January 15, 2025 8:09 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Ice is not dispensed. Is the ice path blocked? (You can check the ice passage by separating the ice bucket.) • Ice may not be dispensed properly if the ice passage is blocked. Check the ice and clean the ice path regularly.
  • Page 45 global_main.book.book Page 45 Wednesday, January 15, 2025 8:09 AM TROUBLESHOOTING Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Appliance is unplugged. • Plug the power plug in the outlet properly. A fuse in your home may be blown or the circuit breaker tripped.
  • Page 46 global_main.book.book Page 46 Wednesday, January 15, 2025 8:09 AM TROUBLESHOOTING Condensation & Frost Symptoms Possible Cause & Solution There is condensation Did you store hot food without cooling it first? inside the appliance or • Cool the hot food first before putting it inside the fridge or freezer. on the bottom of the vegetable drawer Did you leave the appliance door open?
  • Page 47 Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp. Noises Symptoms Possible Cause & Solution...
  • Page 48 global_main.book.book Page 48 Wednesday, January 15, 2025 8:09 AM TROUBLESHOOTING Symptoms Possible Cause & Solution The appliance is noisy Are objects scattered behind the appliance? and generates • Remove the scattered objects from behind the appliance. abnormal sounds. Is there an object on top of the appliance? •...
  • Page 49 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
  • Page 50 global_main.book.book Page 50 Wednesday, January 15, 2025 8:09 AM Memo...
  • Page 51 global_main.book.book Page 51 Wednesday, January 15, 2025 8:09 AM Memo...
  • Page 52 global_main.book.book Page 50 Wednesday, January 15, 2025 8:09 AM...
