- Page 1 Unit 4/1 Rocklea Drive Port Melbourne Vic 3207 1300 109 108 www.traxxcp.com.au TM-G125 G125 CONCRETE GRINDER OPERATIONS MANUAL ORIGINAL INSTRUCTIONS For your personal safety, READ and UNDERSTAND before using, SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
- Page 2 Power Input 110-120V:1700W, 220-240V:2200W Voltage 110-120V~ 50-60Hz , 220-240V~ 50-60Hz (See machine nameplate) No Load/min 4300 - 7200 Wheel Diameter 125mm (5") Spindle Thread Arbor 22.23mm (7/8") & 25.4 (1") Dimensions 500mm x 195mm x 175mm Weight 4.7kg (10.3Lbs) 1. Motor 2.
-
Page 3: Work Area Safety
General Safety Rules WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fi re and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 4 moment of inattention while operating power tools may result in serious personal injury. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
- Page 5 5. SERVICE Have your power tool serviced by a qualifi ed repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Only use original Festool parts for repair and maintenance. The use of incompatible accessories or spare parts can result in electric shocks or other injuries.
- Page 6 that do not match the mounting hardware of the power tool will run out of balance, vibrate excessively and may cause loss of control. • Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires.
-
Page 7: Electrical Connection
precautions are taken. • Never place your hand near the rotating accessory. Accessory may kickback over your hand. • Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging. •... -
Page 8: List Of Parts
serious injury. WARNING: Indicates a potentially hazardous situation which if not avoided will result in death or serious injury. BEFORE USING THIS TOOL WARNING: Some dust created by the power sanding, sawing, grinding, drilling and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: •... -
Page 9: Front Handle
THE SWITCH The machine has a lockable trigger switch. Squeeze the trigger to start Lock Button the machine. To lock the switch on, press the lock button while holding the trigger switch on. To release, squeeze the trigger and release. CAUTION: After the machine has been switched off, the spindle will continue rotating. -
Page 10: Vacuum Connection
before continuing. CAUTION: Whenever the machine overloads, always run the machine at no load for a few minutes to allow the temperature to return to normal before proceeding to work. SPEED STABILIZATION This machine is equipped with an electronic speed stabilization system which maintains constant speed under load. - Page 11 TOOL CHANGE – Removing and Replacing Diamond Cup Wheel CAUTION: Before Working on or adjusting the machine, switch the machine “OFF” and UNPLUG machine from the socket. CAUTION: The wheel can become very hot during the working process. Before replacing, allow the wheel to cool down Place the machine on a level and sturdy workspace.
-
Page 12: Replacing Carbon Brushes
REPLACING DUST SKIRT BRUSHES The dust skirt brushes may be replaced when worn. To replace, remove the 3 screws to replace the small brush on the half moon door and remove the 6 screws to replace the large brush on the dust skirt. REPLACING CARBON BRUSHES The carbon brushes are a normal wearing part and must be replaced when they reach their wear limit. - Page 13 WIRING WHITE WHITE BLUE WHITE WIRE CONNECTOR BLOCK...
-
Page 14: Exploded View
EXPLODED VIEW 110V 220V NO.01~76 A1 Version 1.3 OPTIONAL... -
Page 15: Parts List
PARTS LIST Parts Name Q'TY Parts Name Q'TY POWER SUPPLY CABLE ARBOR LOCK CORD ARMOR O-RING (Ø5x1) PANHEAD TAPPING SCREW (M4x14) SPRING WASHER (M5) CABLE CLIP PANHEAD TAPPING SCREW (M5x30) HANDLE HALF-RIGHT NEEDLE BEARING (HK 1010) CARBON CAP BEVEL GEAR (M1.5x37T) PANHEAD TAPPING SCREW (M4x12) O-RING (Ø72x2) HANDLE HALF-LEFT... - Page 16 Unit 4/1 Rocklea Drive Port Melbourne Vic 3207 1300 109 108 www.traxxcp.com.au...
