ICT ISOLATED 2 Series Instruction Manual

SPECIFICATIONS
Model Input Output Output
Number Voltage Voltage Current
Range (Cont.)
13.8 VDC
ICT1212-12AI2 11-18 VDC 10.0 Amps
+/- 150 mV
13.8 VDC
11-18 VDC 32.0 Amps
ICT1212-35AI2
+/- 150 mV
27.6 VDC
ICT1224-5AI2 11-18 VDC 4.0 Amps
+/- 300 mV
27.6 VDC
11-18 VDC 8.0 Amps
ICT1224-10AI2
+/- 300 mV
27.6 VDC
ICT1224-20AI2 11-18 VDC 17.0 Amps
+/- 300 mV
48.0 VDC
ICT103048-5AI2 11-30 VDC 4.0 Amps
+/- 300 mV
13.8 VDC
ICT206012-12AI2 20-60 VDC 10.0 Amps
+/- 150 mV
13.8 VDC
20-60 VDC 17.0 Amps
ICT206012-20AI2
+/- 150 mV
27.6 VDC
ICT206024-5AI2 20-60 VDC 4.0 Amps
+/- 300 mV
27.6 VDC
ICT206024-10AI2 20-60 VDC 8.0 Amps
+/- 300 mV
13.8 VDC
ICT206012-35AI2 20-60 VDC 32.0 Amps
+/- 150 mV
27.6 VDC
ICT206024-20AI2 20-60 VDC 18.0 Amps
+/- 300 mV
13.8 VDC
ICT9016012-20AI2 90-160 VDC 16.0 Amps
+/- 150 mV
27.6 VDC
ICT9016024-10AI2 90-160 VDC 8.0 Amps
+/- 300 mV
55.2 VDC
ICT9016048-5AI2 90-160 VDC 4.0 Amps
+/- 600 mV
1. The REMOTE control input requires a voltage between 10VDC and 60VDC referenced to the input ground to enable the output of the converter. Converters ship with a jumper connecting the
REMOTE input and the input positive terminal, which must be removed before the control feature will function.
2. The REMOTE control will disable the converter when the remote terminals connected to the INPUT NEG terminal of the converter. The converter is enabled when the REMOTE terminal is left floating.
OUTLINE DRAWING OUTLINE DRAWING
DIMENSIONS IN INCHES
Drawing A
3.10
4.10
Output Current Line Load Output
Current Limiting Regulation Regulation Ripple
(Peak) (Max)
12.5 Amps
12.0 Amps 0.5% 0.5% 20mV RMS
+/- 5%
35.5 Amps
35.0 Amps 0.5% 0.5% 20mV RMS
+/- 5%
5.5 Amps
5.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
10.5 Amps
10.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
20.5 Amps
20.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
5.5 Amps
5.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
12.5 Amps
12.0 Amps 0.5% 0.5% 20mV RMS
+/- 5%
20.5 Amps
20.0 Amps 0.5% 0.5% 20mV RMS
+/- 5%
5.5 Amps
5.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
10.5 Amps
10.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
35.5 Amps
35.0 Amps 0.5% 0.5% 20mV RMS
+/- 5%
21 Amps
20.0 Amps 0.5% 0.5% 30mV RMS
+/- 5%
22Amps
15mV RMS
20.0 Amps 0.5% 0.5%
+/- 5%
11Amps
0.5%
10.0 Amps 0.5% 30mV RMS
+/- 5%
5.25Amps
5.0 Amps 0.5% 0.5% 60mV RMS
+/- 5%
8.90
1.77 1.77
9.50
4.90
Efficiency Input Operating Dimensions Remote
(Typical) Fuse Temperature Terminal
Range Operation
88% 20 Amp -20°C to +40°C Drawing A
90% 60 Amp -20°C to +40°C Drawing B
88% 15 Amp -20°C to +40°C Drawing A
90% 35 Amp -20°C to +40°C Drawing A
90% 60 Amp -20°C to +40°C Drawing B
90% 35 Amp -20°C to +40°C Drawing A
88% 15 Amp -20°C to +40°C Drawing A
90% 20 Amp -20°C to +40°C Drawing A
88% 10 Amp -20°C to +40°C Drawing A
90% 20 Amp -20°C to +40°C Drawing A
90% 40 Amp -20°C to +40°C Drawing B
90% 40 Amp -20°C to +40°C Drawing B
90% 5 Amp -20°C to +40°C
Drawing A
90% 5 Amp -20°C to +40°C Drawing A
90% 5 Amp -20°C to +40°C Drawing A
Drawing B
8.75
3.92
2.45
9.35
Note 1)
Note 1)
Note 1)
ICT ISOLATED SERIES 2
Note 1)
CONVERTERS
Note 1)
Note 1) INSTRUCTION MANUAL
Note 1)
Note 1)
Note 1)
Note 1)
Note 1)
Note 1)
Note 2)
Note 2)
Note 2)
INNOVATIVE CIRCUIT TECHNOLOGY LTD.
855-315-003
THEPOWEROFRELIABILITY
