Section 5 — Electrical Data
RTS "HS" Type Transfer Switch
Electrical Schematic - Drawing No. 0D3818-A
126
A1
205
LS1
LS3
6
TR
9
WHITE
E1
LS2
A2
C - CONTACTOR ACTUATING COIL
GTS - TRANSFER SWITCH CONTACTOR
PM - POWER MONITOR, 3 PHASE UTILITY
TR - RELAY, TRANSFER
TS - TERMINAL STRIP (CUSTOMER CONNECTION)
LS1,LS2,LS3 - LIMIT SWITCHES, ACTUATOR
F1,F2 - FUSE 5A SENSING
14
TR
1
126
N1B
7
B1
T1 T2
2 3
RED
C
1
GTS
B2
E1
E2
N2A
LEGEND
N1B
N1B
N1B
5 6
4
B
TR
A
NOTES:
1.) ALL CONTACTS SHOWN WITH
TRANSFER SWITCH IN UTILITY
POSITION.
2.) FOR SINGLE PHASE OPERATION,
ADD JUMPER WIRE FROM PM
TERMINALS 1 TO 8.
PM
1 8
N1A
N2A
3
PM
4
N2A
5
N3
N2A
N2A
23
23
194
194
F1
N1
F2
N2
