Summary of Contents for Summit Professional DW2433SS2ADA
- Page 1 Dishwasher Use and Care Manual FOR MODELS DW2433SS2* Write Serial Number (on label on side of door) here:...
-
Page 2: Table Of Contents
To prevent accidents, which could cause serious injury or death, as well as machine damage read these instructions before installation and / or use. CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS 2. INSTALLATION 3. GETTING TO KNOW YOUR DISHWASHER 4. LOADING THE DISHWASHER 4.1 UPPER RACK 4.2 LOWER RACK 4.3 PROPER AND IMPROPER LOADING OF DISHWARE... -
Page 3: Important Safety Instructions
1. IMPORTANT SAFETY INTRODUCTION Please read this user manual and INSTRUCTIONS particularly the safety instructions WARNING:When using the completely and carefully. They will save dishwasher, follow basic you time and effort and help to ensure precautions, including the optimum dishwasher performance. following: Read all instructions before Be sure to observe all listed warnings... - Page 4 Use only detergents or rinse manufacturer’s recommendations. • aids recommended for use in a If a malfunction occurs, switch • household dishwasher and keep off the appliance and turn off the them in a dry place out of the water supply to the dishwasher. reach of children.
- Page 5 run with the circuit conductors WARNING:If your and connected to the equipment- dishwasher is equipped with grounding terminal or lead on the internal illumination, lamp appliance. should only be replaced by This appliance produces ozone • the Authorised Service Agent within the washing compartment in case of failures that may during normal operation.
-
Page 6: Installation
2. INSTALLATION a dishwasher-dedicated, properly grounded electrical circuit with WARNING:When installing a fuse or breakers rated for the dishwasher, follow basic 15 amperes. Electrical supply precautions, including the conductors shall be a minimum following: of # 16 AWG copper wire rated Please check the standarts and at 75 °C (167 °F) or higher. -
Page 7: Getting To Know Your Dishwasher
3. GETTING TO KNOW YOUR DISHWASHER 1. Upper rack 2. Upper spray arm 3. Salt container (MODEL DEPENDING) 4. Cutlery basket 5. Detergent dispenser 6. Door 7. Control panel 8. Guiding track for the upper rack 9. Lower spray arm 10. -
Page 8: Loading The Dishwasher
4. LOADING THE Lower rack ( MODEL DEPENDING) DISHWASHER Pull the handle to open the door. If the door is opened during operation, the dishwasher will stop running. Once the door is closed the program will continue. Upper rack ( MODEL DEPENDING) Bottom rack load pattern for 12 place settings according to the AHAM DW-1... - Page 9 Lower rack ( Lower rack ( MODEL DEPENDING) MODEL DEPENDING) Additional Loading Pattern – Bottom International Loading Pattern – Bottom rack (10 place settings) rack (14 place settings) CAUTION:Large knives and other utensils with sharp tips Upper rack ( MODEL DEPENDING) and edges must be placed horizontally into the upper rack due to risk of injury.
-
Page 10: Upper Rack
4.1 UPPER RACK CAUTION:The cup racks are designed to support cups, Load the upper rack with dessert glasses and kitchen utensils. plates, cups, glasses etc. When the cup racks are in the dishwasher do not lean on or use the cup racks to support your body weight. - Page 11 COLLAPSIBLE UPPER BASKET COLLAPSABLE UPPER BASKET TINES TINES (MODEL DEPENDING) (MODEL DEPENDING) There are foldable tines on the upper Upper basket of the machine is basket of the machine that you can lay equipped with wires with gradual down when you need larger space for folding system (A) that you can lay big dishes.
- Page 12 FOLDING TINES (MODEL DEPENDING) There are “folding tines” in the upper rack to allow you more space to accommodate glasses or cups. Simply pull in the first front folding tine, move it to left A and right B to place in another positon.
-
Page 13: Lower Rack
HEIGHT SETTING (MODEL DEPENDING) In certain models, the height setting of the upper rack may be changed using the wheels which are present at two height levels. CAUTION:Make sure that the rack is empty. Changing the height setting while the rack contains tableware Push the latches back into the could cause the contents to... - Page 14 FOUR FOLDING PLATE SUPPORT COLLAPSABLE LOWER BASKET TINES (MODEL DEPENDING) WIRES 4 PIECES-(MODEL There are 4 separate “folding plate DEPENDING) support tines” in the lower rack of The four piece foldable wires located your dishwasher designed to allow at the lower basket of the machine you more space to accommodate are designed for an easier placement saucepans, pots and large bowls in the...
- Page 15 SILVERWARE BASKET (MODEL DEPENDING) Silverware basket is designed to wash your dishes such as knife, fork, spoon, etc. in a cleaner manner. Since the cutlery basket can be moved (A, B), you can create a wider space while placing your dishes to the lower basket and free up space for your dishes in different sizes.
- Page 16 UPPER CUTLERY BASKET (MODEL DEPENDING) The upper cutlery basket is designed for small dishes, or long items that cannot fit into the lower cutlery basket. After taking out the basket by lifting it up, remove the carrier part from the rails by pulling it towards yourself (C).
-
Page 17: Proper And Improper Loading Of Dishware
4.3 PROPER AND IMPROPER LOADING OF DISHWARE 4 4 4 1: Salad Fork 2: Teaspoon 3: Dinner fork 4 4 4 4: Knife-solid handle Sliding Cutlery Basket load pattern for 12 5: Serving spoon place settings according to the AHAM DW-1 6: Serving fork Standards •... -
Page 18: What Should Not Be Washed In Your Dishwasher
5. WHAT SHOULD NOT Crystal and very fine glassware • may become opaque (etch) losing BE WASHED IN YOUR their shine over time. You may DISHWASHER prefer to wash them by hand. Rust-sensitive steel parts like iron • Do not wash sponges or dish •... -
Page 19: Operating The Product
6. OPERATING THE PRODUCT NOTICE: If you do not perform any operation after switching on the machine, it will be automatically switched off within 5 seconds. Cancel 3” 1. On/Off key Not in use 2. Programme Selection / Programme 7. Start / Cancel indicator Cancel (3 seconds) key 8. -
Page 20: Preparing The Machine
6.3 PROGRAMME SELECTION Programme Selection / Programme Cancel key 1. Press the On/Off button to turn on Press this key until the desired your machine. programme appears in the programme 2. Check the Salt and Rinse Aid indicator. indicators and add salt and/or rinse aid if needed. -
Page 22: Auxiliary Functions
6.4 AUXILIARY FUNCTIONS Automatic Detergent Detection Feature Washing programmes of your The product has a feature to dishwasher are designed to obtain the automatically detect the type of the best cleaning effect, considering the detergent and adjust the washing type of the soiling, soiling degree and programme and drying system to the properties of the dishes to be washed. -
Page 23: Scheduling The Washing Time
Interior Lighting Floor illumination (MODEL DEPENDING) Warning to show that machine is in Some models have interior lighting to washing phase illuminate the interior when the door is (MODEL DEPENDING) opened. Your machine reflects a light to the Changing the interior lighting floor during the washing process. -
Page 24: Starting The Programme
selected programme will start MODEL DEPENDING: automatically. Your machine performs Changing the settings while Time water softening depending Delay function is active on the hardness level of the supply water. Washing While the Time Delay function is time can change while activated, you cannot make changes the programme is running in the washing programme, auxiliary... -
Page 25: Cancelling The Programme
The machine will remain 6.9 RINSE AID INDICATOR ( ) silent in pause mode for Please check the rinse aid indicator some time in order to on the display to see whether there is remove the water from the adequate amount of rinse aid in the machine and on the dishes dishwasher or not. -
Page 26: Water Cut-Off Warning
Tub Clean Leave your dishes in the This programme is recommended machine for about 15 to be operated on each 1-2 months minutes to allow them cool for machine cleaning and necessary down after they are washed. hygiene. The programme should be Your dishes will dry in a operated while the machine is empty. -
Page 27: Detergent & Rinse Aid Dispenser
7. DETERGENT & RINSE AID DISPENSER 7.1 FILLING THE DETERGENT DISPENSER WARNING:Always store your detergent in locations which are cool, dry and out of the reach of children. Check that the detergent • dispenser is empty after the If you do not know the hardness completion of each wash of your water supply, use 15 ml / 3 program. -
Page 28: Filling Rinse Aid Dispenser
7.2 FILLING RINSE AID the 25 ml / 5 tsp mark. When the dishes are less dirty, it is generally DISPENSER sufficient to fill the detergent up to WARNING:Keep your the 15 ml / 3 tsp mark. rinse aids out of the reach of children. -
Page 29: Set The Dose Of Rinse Aid
Close the lid until it clicks in 3. Carefully wipe off spilled rinse aid. Excessive rinse aid causes excessive foam formation, which may hinder cleaning. 7.3 SET THE DOSE OF RINSE AID The dose of rinse aid to be used can be set by means of the dispenser regulator 4 between levels 1 and 6. -
Page 30: Setting The Water Softener
8. SETTING THE WATER SOFTENER (MODEL DEPENDING) WATER HARDNESS & REGENERATION SETTINGS The dishwasher requires lime free water. Hard water leaves watermarks on your dishes. Your dishwasher has a special water softening system to remove the hardness of the tap water. Setting this system correctly will increase the washing effectiveness. -
Page 31: Filling The Dishwasher Salt Dispenser
9. FILLING THE DISHWASHER If the hardness level of the water that you use is above 90°dF (French SALT DISPENSER standard for water hardness) or if (MODEL DEPENDING) you are using well water, than it is CAUTION :Never use recommended to use filter and water culinary or table salt. -
Page 32: Care And Maintenance
10. CARE AND MAINTENANCE Open the screw-in cap of the salt container by turning it counter WARNING:Before cleaning clockwise (Fig. A, B). or carrying out maintenance, switch off the appliance, disconnect the mains plug and turn off the water tap. WARNING:Do not repair or replace any part of the dishwasher or attempt any... -
Page 33: Caring For Your Dishwasher Exterior
10.1 CARING FOR YOUR 10.2 CARING FOR YOUR DISHWASHER EXTERIOR DISHWASHER INTERIOR NOTICE: Cleaning your CAUTION :Possible dishwasher at regular dishwasher damage: intervals ensures longer Abrasive cleaners, scouring product life and reduces the pads, abrasive cloths (paper risk of recurring problems. towels) can damage the Always disconnect the power dishwasher decorative door. -
Page 34: Cleaning The Filters
10.3 CLEANING THE FILTERS Clean the filters at least once a week in order for the machine operates efficiently. Check if food residues are left on the filters. If there are food residues on filters, take them out and clean well under running water. 1. -
Page 35: Cleaning The Hose Filter
10.4 CLEANING THE HOSE 10.5 CLEANING THE FILTER IMPELLERS Damages on the machine that may be Clean the impellers at least once a caused by impurities coming from the week in order for the machine operates urban supply water or your own water efficiently. - Page 36 UPPER IMPELLER CEILING IMPELLER Check if the holes on the upper (MODEL DEPENDING) impeller (1) are clogged. If they Check if the holes on the top ceiling are clogged, remove and clean the impeller (1) of your machine are impeller. Turn its nut to left to remove clogged.
-
Page 37: Troubleshooting
11. TROUBLESHOOTING Machine does not start. Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 38 door and wait for evacuation of the steam inside for a while. Unload the dishes after the pieces cool down to a touchable level. Start unloading process from the lower basket. Thus, dropping of water remained on a piece at upper basket onto the pieces at lower basket is prevented. Selected programme is unsuitable.
- Page 39 There is a different odour in the machine A new machine has a peculiar odour. It will fade out after a couple of washing. Filters are clogged. >>> Check if the filter system is clean. Clean the filter • system regularly as illustrated in section “Cleaning and Care”. Dirty dishes are kept in dishwasher for 2-3 days.
- Page 40 Detergent remains in detergent dispenser. Detergent dispenser was damp when adding detergent. >>> Make sure that • the detergent dispenser is dried well prior to filling it with detergent. Detergent is added long before the washing process. >>> Pay attention to •...
- Page 41 A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled •...
-
Page 42: Technical Features
If you cannot eliminate the problem although you follow the instructions in this section, consult your dealer or the Authorised Service Agent. Never try to repair a nonfunctional product yourself. 12. TECHNICAL FEATURES Load capacity 14 place settings Permissible water 4.35 - 145 psi (0.3 - 10 bars) pressure Electrical connection...
