- Page 1 Dishwasher Installation Manual FOR MODELS DW2433SS2*...
-
Page 2: Table Of Contents
To prevent accidents, which could cause serious injury or death, as well as machine damage read these instructions before installation and / or use. Contents 1. IMPORTANT SAFETY INSTRUCTIONS 1.1 INSPECT THE DISHWASHER 1.2 HOW TO CONTACT US : 2. TOOLS WHICH MAY BE NEEDED 3. -
Page 3: Important Safety Instructions
INTRODUCTION WARNING Please read this installation manual When installing the dishwasher, follow and particularly the safety instructions basic precautions, including the completely and carefully. They will save you following: time and effort and help to ensure optimum • The dishwasher installation must be dishwasher performance. -
Page 4: Inspect The Dishwasher
1.1 INSPECT THE DISHWASHER dishwasher-dedicated, properly grounded electrical circuit with a fuse or breakers After unpacking the dishwasher and prior rated for 15 amperes. Electrical supply to installation, thoroughly inspect the conductors shall be a minimum of # 14 dishwasher for possible freight or cosmetic AWG copper wire rated at 75 °C (167 damage. -
Page 5: Tools Which May Be Needed
2. TOOLS WHICH MAY BE NEEDED 3. MATERIALS WHICH MAY BE NEEDED (Additional materials may be required to comply with local codes) Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. Electrical Supply Cable - Minimum #14AWG, 2 conductors, 1 ground, insulated copper conductors. -
Page 6: Materials Supplied
4. MATERIALS SUPPLIED 4.1 PARTS SUPPLIED Parts for your dishwasher will come in several plastic bags. Check your parts bags shown to make sure you have all the parts as listed to the left. 4.2 MANUAL BAG The dishwasher comes with a manual bag containing: • User manual, • Installation manual and • Quick reference guide. -
Page 7: Dishwasher Specifications
5. DISHWASHER SPECIFICATIONS 2 4 ” ( 6 1 2 4 ” ( 6 1 ” m 5.1 TECHNICAL FEATURES Load capacity 14 place settings Permissible water 4.35 - 145 psi (0.3 - 10 bars) pressure 120 V (volts), 12 A (amps), Electrical connection 60 Hz (hertz) Total power... -
Page 8: Enclosure Preparation
6. ENCLOSURE PREPARATION Notice : • For proper dishwasher operation and appearance ensure that the enclosure has the minimum dimensions shown in the figure above. 6.1 ELECTRICAL PREPARATION WARNING To avoid electrical shock and/or a fire hazard, make sure electrical work is properly installed. -
Page 9: Preparation For Installing Mounting Brackets
6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS WARNING Dishwasher must be secured to adjacent cabinetry using the mounting brackets provided. Failure to do this may cause damage to property or bodily injury. Place the two mounting brackets into the top corners of the dishwasher. Bend sides of mounting brackets (A) in order to fix from sides (if necessary). - Page 10 6.3.1 INSTALLING THE FOOT SUPPORTS Supplied (4) 15 / ” (50mm) 7 / 16 If the height of the enclosure is 33 ” to 1 / 4 ” (850mm - 870mm) use short supports as shown in the figure. 15 / ”...
-
Page 11: Installing The Side Trim Strips
Adjust the front foot level with the adjusting wrench to balance and raise the dishwasher to the enclosure height. Adjust the rear foot level with a screwdriver to balance and raise the dishwasher to the enclosure height. Notice : • Make sure the dishwasher is plumb and notice dishwasher can be placed with a small clearance under the counter top. -
Page 12: Preparing The Water Connection (A)
6.5 PREPARING THE WATER CONNECTION (A) Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder connections must be made before the water line is connected to the dishwasher’s water inlet valve. Water can also be supplied to the dishwasher by using a flexible braided hose line. -
Page 13: Drain Preparation
6.6 DRAIN PREPARATION The dishwasher drain hose may be connected to the drain plumbing in one of three ways (Figure A, B, C). Notice : • Either one of the above methods must be used or the dishwasher will not operate properly. -
Page 14: Steam Protection Foil
6.7 STEAM PROTECTION FOIL Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top. 6.6.2 FITTING THE PROTECTION FOIL Before applying the steam protection foil to the underside of the countertop, clean the area with... -
Page 15: Placement Of Dishwasher Into The Opening
7. PLACEMENT OF DISHWASHER INTO THE OPENING Now place the dishwasher into the opening and get ready to connect all hoses and electrical connections. CAUTION Make sure all hoses and electrical wire are pulled through the side opening of the cabinet, no hoses are kinked and all slack is taken out as shown in the... -
Page 16: Electrical Connection
7.1.2 WATER SUPPLY CONNECTION Water supply may be connected to the dishwasher in one of two ways: • With metal braided hose. • With copper tubing. 7.1.3 BRAIDED HOSE/COPPER TUBING After connections are made turn on the water supply to check for leaks. CAUTION • Hot water supply line: Use minimum 3/8”... - Page 17 Install a strain relief (not supplied) into the opening on the kick plate. (Figure A) Pass the electrical supply cable through the strain relief; make sure the strain relief clamps the insulated outer casing of your electrical supply cord and not the wires themselves. 15 / 15 / Leave 2...
-
Page 18: Readjusting Foot Levels
7.3 READJUSTING FOOT LEVELS Now that the dishwasher is in the cabinet you must readjust the feet to (3,5mm) Ø " bring the dishwasher up to the required height and attach it underneath the countertop. (3,5mm) Ø " 1. Readjust the front foot levels with adjusting wrench to balance the dishwasher and raise it up under the countertop, make sure the unit is level. - Page 19 Lock the toe kick brackets as shown with the plastic tab in the figure C by pushing the plastic tab on the dishwasher into the teeth of the bracket (C). 3. Now attach the toe kick to the bracket with the two (Ø...
-
Page 20: Installer Checklist
Notice : Notice : If the dishwasher does not operate properly, The installer is responsible for the refer to the self help hints. dishwasher installation. Incorrect installation is not covered by the warranty. 10. SELF HELP HINTS: 8. INSTALLER CHECKLIST The power indicator light doesn’t come on: Your installer must have completed and • Check to make sure the breaker to the... - Page 21 17 1799 01 00 AC-USA...
