Gentex OBIHL3 Owner's Manual

Suggested Owners Manual Text for Gentex Auto-Dimming Mirror with HomeLink
Automatic–Dimming Mirror with HomeLink
Your new vehicle comes with an Automatic-Dimming Mirror with an Integrated
®
HomeLink Wireless Control System. During nighttime driving, this safety feature will
automatically detect and eliminate dangerous rearview mirror glare while the
®
HomeLink Universal Transceiver allows you to activate your garage door(s), estate
gate, home lighting, etc.
1

Automatic-Dimming Mirror

The Automatic-Dimming Mirror in your vehicle is the most advanced way to eliminate
dangerous and annoying glare in the rearview mirror during any driving situation. For
more information regarding Gentex Corporation mirrors and other applications, please
refer to the Gentex website:
www.gentex.com.

Precautions

The Automatic-Dimming Mirror automatically reduces glare during driving conditions
based upon light levels monitored in front of the vehicle and from the rear of the vehicle.
These light sensors are visible through openings in the front and rear of the mirror case.
Any object that would obstruct either light sensor will degrade the automatic dimming
control feature.

Automatic-Dimming Function

To protect your vision during nighttime driving, your mirror will automatically dim upon
detecting glare from the vehicles traveling behind you. The auto-dimming function can
be controlled by the Dimming OFF and ON Buttons:
O
1. Pressing the button turns the auto-dimming function OFF which is indicated by the
green Status Indicator LED turning off.
I
2. Pressing the button turns the auto-dimming function ON which is indicated by the
green Status Indicator LED turning on.
Note:
The mirror defaults to the "ON" position each time the vehicle is started.
2 6
3 5
4
7
®
®
1. Channel 1 Button
2. Channel 2 Button
3. Status Indicator LED
4. Channel 3 Button
5. Rear Light Sensor
6. Dimming ON Button
7. Dimming OFF Button
