Gentex ZTVHL3 Manual

with Z-Nav™ Electronic Compass Display and HomeLink
Your new vehicle comes with a Gentex Automatic-Dimming Mirror with a Z-Nav™
Electronic Compass Display and an Integrated HomeLink
During nighttime driving, this safety feature will automatically detect and eliminate
dangerous rearview mirror glare while the compass indicates the direction the vehicle is
pointed. The HomeLink
door(s), estate gate, home lighting, etc.
1
Automatic-Dimming Night Vision Safety™ (NVS
®
The NVS Mirror in your vehicle is the most advanced way to eliminate dangerous and
annoying glare in the rearview mirror during any driving situation. For more information
®
regarding NVS mirrors and other applications, please refer to the Gentex website:
www.gentex.com.
Precautions
®
The NVS Mirror automatically reduces glare during driving conditions based upon light
levels monitored in front of the vehicle and from the rear of the vehicle. These light
sensors are visible through openings in the front and rear of the mirror case. Any object
that would obstruct either light sensor will degrade the automatic dimming control
feature.

Automatic-Dimming Function

To protect your vision during nighttime driving, your mirror will automatically dim upon
detecting glare from the vehicles traveling behind you. The auto-dimming function can
be controlled by the Dimming ON/OFF Button:
1. Pressing the
the green Status Indicator LED turning off.
2. Pressing the
by the green Status Indicator LED turning on.
Note:
The mirror defaults to the "ON" position each time the vehicle is started.
Automatic–Dimming Mirror
®
Universal Transceiver allows you to activate your garage
2
3 4 5
button turns the auto-dimming function OFF which is indicated by
button again turns the auto-dimming function ON which is indicated
®
8
7
6
Wireless Control System.
1. Channel 1 Button
2. Channel 2 Button
3. Status Indicator LED
4. Channel 3 Button
5. Rear Light Sensor
6. Dimming On/Off Button
7. Compass Control Button
8. Display Window
®
) Mirror
®
