Thank you very much for choosing the ViewSonic LCD TV Display. We recommend that you take a few minutes to read carefully through this manual before installing and switching on the TV. Please keep this manual in a safe place for your future reference.
Page 3
FOR YOUR SAFETY Before operating the TV please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Purchase Date: Product disposal at end of product life ViewSonic is concerned about the preservation of our environment. Please dispose of this product properly at the end of its useful life. Your local waste disposal company may provide information about proper disposal.
IMPORTANT SAFETY INSTRUCTUONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.
Page 6
22. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE Note to the CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
Macintosh adapter. Attach the adapter to the computer and plug the video cable into the adapter. To order a ViewSonic® Macintosh adapter, contact ViewSonic Customer Support. 4 Turn ON LCD display and computer Turn ON the LCD display, then turn ON the computer.
Using the Display (PC) Setting the Timing Mode (PC RGB Input) Setting the timing mode is important for maximizing the quality of the screen image and minimizing eye strain. The timing mode consists of the resolution (example 1280 x 768) and refresh rate (or vertical frequency; example 60 Hz).
PREPARATION Please, make sure to connect the power plug to the wall outlet socket after connecting the TV to the adapter! Place the TV on a solid surface. Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover.
Page 10
3. Remote control: Remove the cover of the battery compartment. Insert the 2 batteries supplied (Type AAA 1.5V). 4. Power: Insert the power cord in the wall socket having an AC power supply. 5. Turn the TV on: Press the power button at the bottom of the bezel to turn it on. If the TV is in power off, the indicator in front of the TV illuminates amber.
Multichannel Television Sound, Stereo or Mono V-CHIP CAPTION PRE-CH SIZE To display the previously selected TV channel. ViewSonic TV/VIDEO Select your input source: press repeatedly to select TV, AV1, AV2, S-VIDEO or COMPONENT mode, according to where you connected your external source.
TO USE THE MENUS Press the MENU button to display each menu Use the cursor up/down to select a menu item. Use the cursor left/right to enter a submenu or enable/disable the function. Press the MENU button to exit the menu. MAIN MENU Press the MENU button into the main OSD (On Screen Display).
Page 13
When adjust any item sub-OSD will show up like this. Audio Adjust Volume is adjusted from 0 to 100. Bass and Treble are adjusted from 0 to 100. W-Head Phone (optional) is the function for wireless headphone enable or disable. You can adjust audio Volume, Balance, Bass and Treble to the levels you prefer.
Page 14
CLOSED CAPTION It’s allows you to read the dialog of television programs on the TV screen. Designed to help the hearing impaired, this feature uses on screen “ text boxes” to show dialogue and conversations while the TV program is in progress. Captions will appear on the screen only during captioned broadcasts.
Page 15
V-CHIP SETUP Select V-Chip on OSD then enter 4 digits of pin number. Initial pin number is “0000”. If you enter an incorrect pin number “Incorrect” message will be displayed. It is the parental control function (V-chip). It is used to block program viewing based on the ratings by the broadcaster.
Page 16
Setting up Movie Guidelines Use Up/Down arrow buttons to move around the matrix and press Right arrow button to change the value from “U” to ‘B” or “B” to “U” CHANGE PIN Personal Identification Number is for change password to control the V- chip setup;...
Page 17
Sleep Timer It is for set a time period after which the TV should switch itself to standby. The counter runs from 0 > 30 > 60 > 90 > 120 minutes. The timer begins to count down from the number of minutes selected after the display has disappeared.
Page 18
PC Adjust Auto Adjust is the function auto-sizing for VGA input. Contrast, Brightness, Focus, Clock, H-Position, V-Position and Color Temp are the functions for PC adjustment. Color Temp for you can adjust the color temperature you prefer.
CONNECT PERIPHERAL EQUIPMENT FRONT PANEL CONTROL KNOBS Press to turn on or off the TV. Power Key: Press to show the OSD menu and exit OSD menu at the TV. MENU Key: Down / Up Key: Press to perform select function and channel. Press to confirm your function selection and adjustment.
VIDEO RECORDER How to connect 1. Connect the antenna cable to the RF IN port of your VCR. Connect another RF cable Better quality when playing from your VCR can be obtained if you also connect the Video, Audio LEFT AND right (only for stereo equipment) cables inputs AV.
CAMERA, CAMCORDER, VIDEO GAME SET, … How to connect Composite Video: Connect your camera, camcorder, videogame set,… to Audio port (Audio L for mono) and Video port S-Video Connection S-VHS quality with an S-VHS camcorder is obtained by connecting the S-VHS cable with the S-VIDEO input and AUDIO input How to use...
DIGITAL SET TOP BOX Connect DTV set top box RF output to TV Antenna input (TV channel set to CH3 or CH4). If your DTV set top box has component (Y, Pb, Pr) video ports, use them for better picture. How to connect component video: Connect the three separate component video cables ports and to the Y, Pb and Pr ports on the TV.
HEADPHONE The earphone jack is located at the rear corner of the TV. MUTE key on the remote control works on both internal speaker and the earphone. Use volume key to adjust the volume. Note: When a TV channel or external AV source is blocked because of a rating set via the Parental control menu, also the headphone is muted.
PRODUCT SPECIFICATION Feature 17” screen WXGA ( 1280 x 768 ) Resolution Wide Viewing Angle ( 170° H / 170° V ) Built-in 181 channel Tuner with MTS, SAP, Closed Caption & V-chip PC Input (Max. Resolution : 1280 x 768/60Hz) Items Screen Size Aspect Ratio...
Page 25
Signal Input PnP compatibility PC Input Input frequency Recommended Input Audio Audio Output Audio Output: L / R OSD language English / French / Spanish Table Stand Included Wall Mount VESA 100 x 100 mm Power Supply Power Power Consumption Operating Temp.
Compatibility Modes VESA VGA 640 x 480 VESA VGA 640 x 480 VESA VGA 640 x 480 VESA VGA 720 x 400 SVGA 800 x 600 SVGA 800 x 600 SVGA 800 x 600 VES A XGA 1024 x 768 VES AXGA 1024 x 768 MAC 16"...
BEFORE CALLING SERVICE Please make these simple checks before calling service. These tips may save you time and money since charges for receiver installation and adjustments of customer controls are not covered under your warranty. Symptoms ″Ghost″ or double image No power No picture Good picture but no sound...
Customer Support For technical support or product service, see the table below or contact your reseller. You will need the product serial number. NOTE: Country/ Web site Region United States www.viewsonic.com/ support Canada www.viewsonic.com/ support United Kingdom www.viewsoniceurope.com Europe, Middle www.viewsoniceurope.com...
GLOSSARY Audio / Video Inputs Located on the rear and the front of the receiver these connectors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connection options.
How long the warranty is effective: Viewsonic N1750w TV is warranted for one (1) year for all parts including the light source and one (1) year for all labor from the date of the first consumer purchase.
Safety Guidelines Warning: This device must be operated with the original power supply, part number: 12VDC LSE9901B1250, 12VDC UP06031120. CAUTION: The socket-outlet should be installed near the equipment and should be accessible. CAUTION: Use a power cable that is properly grounded. Always use the appropriate AC cord that is certified for the individual country.
