ViewSonic N1930w-2M Service Manual

19” lcd tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual
ViewSonic N1930w-2M
Model No. VS12115-2M
19" LCD TV
(N1930w-2M_SM Rev. 1a Jun. 2008)
®
ViewSonic
381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N1930w-2M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ViewSonic N1930w-2M

Summary of Contents for ViewSonic N1930w-2M

  • Page 1 Service Manual ViewSonic N1930w-2M Model No. VS12115-2M 19” LCD TV (N1930w-2M_SM Rev. 1a Jun. 2008) ® ViewSonic 381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583...
  • Page 2 Further, ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    6. Trouble Shooting Flow Chart..............55 7. Block Diagram ..................... 58 8. Schematic Diagrams..................59 9. PCB Layout Diagrams ................. 72 10. Exploded View And Exploded Parts List ..........77 11. Recommend Spare Parts List..............80 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 4: Precautions And Safety Notices

    (IEC60950 or UL1950), or be applied exemption. (14) The LCD module is designed so that the CFL in it is supplied by Limited Current Circuit (IEC60950 or UL1950). Do not connect the CFL in Hazardous Voltage Circuit. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 5 Taking out the monitor by grasping the LCD panel. That may cause “Mura” Place the monitor on a clean and soft foam pad. Placing the monitor on foreign objects. That could scratch the surface of the panel or cause “Mura” ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 6: Specification

    2. Specification LCD panel of this product shall be provided by “MTD” with a model number of M190MWW1-401. The following table defines this panel specification. Any changes in panel must be pre-approved by ViewSonic in written. Parameter Specification a-Si TFT Active Matrix Wide Color, Transmissive Mode, Normally...
  • Page 7 +/- 3 db (at 1KHz @1W) Response Total Harmonic Distortion <2% <2% (Po=0.1 to 1 W, f=1KHz) 12 dB (100Hz to 1KHz) Signal to Noise: 35 dB (100Hz to 10 kHz) 8 dB (1kHz to 10kHz) ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 8 Able to withstand an ANSI / IEEE C62.41 – 1980 2000V ring wave Immunity with no damage. (Supply Transients and Outage) Able to withstand 1.25X nominal Line Voltage for one cycle with no 8 Surge Immunity Test damage. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 9 Power Key - PANTONE 032C (RED) Color Key Pads – PANTONE 10C & PANTONE 7C(Cool Gray) Texts Printed on Front Cover and Key Pads - PANTONE 427C Protocol VS key-code & protocol. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 10 =0.7mm screw mounting kit not included. Sample Sample of textured color chips, plastic material specification, and Material Safety Data Sheets shall be submitted to ViewSonic prior to Mass Production Release. In addition, all exterior surfaces shall have uniform texture/color. The maximum acceptable gap between the buckets to bezel plastic pieces shall be within 1mm.The maximum acceptable gap between LCD...

  • Page 11: Front Panel Function Control Description

    Channel down when source is TV, or select a control while in CH Down OSD menu. CH Up Channel up when source is TV, or select a control while in OSD menu. INPUT Select input source. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 12 A/V device. PC Audio input Connect the RGB Audio Out on your computer to the RGB Audio on the rear of the LCD TV. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 13 Connect the Audio in cable for YPbPr/ HDMI-DVI from this jack to the corresponding connectors on your A/V device. Audio input (left/ right) Connect this jack to your Cable or VHF/UHF antenna. 12 TV Input Jack ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 14 POWER mode. Press it again to return to the standby mode. ▲▼◄► Press these buttons to navigate the OSD menus. ▲/▼ buttons is for function select, and ◄/► is for function adjustment. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 15 TV broadcasting station. (EX: Mono, Stereo, SAP) 18 C.C Press to select the Closed Caption menu in the TV mode. Press to return to previous channel. 19 RECALL N4750p ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 16 (It shows all or some of the information about Input, Channel, Resolution, Audio Type, etc., depending on what input source it is in) ＊The picture here shows an example of the INFO screen in a DTV source. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 17 (► will only appear when the control is highlighted) 6. Press ◄► to adjust or select the settings. 7. Press MENU to exit from the OSD menu. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 18 4. To cancel the selection, Press ENTER again on the selected channel. 5. Press MENU to exit. ＊To view your favorite channels, press FAV button to show Favorite List and select your favorite channels that have already been stored. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 19 5. Use ▲ or ▼ to choose letters or signs, ◄ or ► to move forward or backward. 6. After you input the channel name, press MENU or ENTER to complete the setting. 7. Press MENU to exit. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 20 (2) Press ◄ or ► to select your desired top Menu. (3) Press ▲ or ▼ to select the control with ►, including “Treble/Bass”, “Closed Caption”, “Restore Default”, then press ► to perform the function or enter detailed settings. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 21 Advanced Selection, and use ◄ or ► to make your choice. Basic Selection: To set basic analog closed caption options. (CC1~CC4, TEXT1~TEXT4, Off) Advanced Selection: To select closed caption signal formats and set up caption modes for digital TV channels. (Service1~6, Off) ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 22 3. Press ENTER or ▼ to enter Password. 4. Enter the password. (The default password is 0000) 5. Move to “System Lock”, and select “On” to enable the detailed settings. 6. Move to “US” or “Canada” rating system. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 23 PG-13 (recommended for children 14 years of age or older) R (mature audience) NC-17 (no one under 17 years of age) X (adult audience only) N/A (not applicable) 3. Press MENU to exit. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 24 8ans+ (children eight years and older) 13ans+ (not appropriate for children of less than 13 years) 16ans+ (not appropriate for children of less than 16 years) 18ans+ (reserved to adults) EXEMPT (exempt) 4. Press MENU to exit. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 25 4. Enter your new password again on “Confirm Password”. After you complete the last step, the screen will return to the top page of LOCK menu. If so, the password has been changed successfully. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 26 3. Press ENTER or ► to enter “OPTION” menu. 4. Press ▲ or ▼ to select “Restore Default”, then press ► to restore the factory default setting. 5. Select “Yes” and press ENTER to confirm the setting. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 27 If you forget your initial password,you can press"3660"to resume. "MENU" Lock & Un-lock: Pressing "Vol+" and "Vol-" from Front Panel Keys. "POWER" Lock & Un-lock: Pressing "Vol+" and "MENU" from Front Panel Keys. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 28: Circuit Description

    CVBS0 Analog Input Analog Composite Input for TV CVBS0 31 CVBS1 Analog Input Analog Composite Input for TV CVBS1 30 CVBS2 Analog Input Analog Composite Input for TV CVBS2 29 CVBS3 Analog Input Analog Composite Input for TV CVBS3 28 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 29 DDC_ROMSCL I/O DDC ROM Clock for D-SUB Input 35 DDC_ROMSDA I/O DDC ROM Data for D-SUB Input 36 SDRAM Interface SDR_CSZ Output SDRAM Chip Select; active low 134 SDR_CKE Output SDRAM Clock Enable 126 SDR_AD[11:0] Output SDRAM Address Bus 148-137 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 30 FB2 Analog Input Input for 2nd Feedback Loop 208 FAULTZ Analog Input Fault Detection (Low Enable) 209 VIN Analog Input System Input Voltage Detection 210 Misc. Interface RESET Schmitt Trigger Input w/ 5V-tolerant Hardware Reset; active high 61 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 31 It contains a 12-bit A/D converter and a PWM generator for automatic gain control. A host interface with an I2C bus is also included to control the behavior of the MSD809. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 32: Adjustment Procedure

    Figure 4, Set Color bar to 100 IRE then move the cursor to the White Balance figure 5. Press “►” Key figure 6. That will do auto white balance. Finally change 16 gray scale must be claire in each grays. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 33 A.DVI MODE: Depend on the TIMING of TIMING TABLE (TABLE 3 ) to check MODE in order. B.HDMI MODE: make sure the 480i, 480p, 720p, 1080i TIMING is right. 6. OSD FUNCTION TEST Time:1400*900@60Hz Pattern: 16*12 pane Make sure that Each FUNCTION has one right action. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 34 B. Input full white pattern then measure the luminance. For example Value A C. Input full dark pattern the measure the luminace. For example Value B D. These two value ratio must be more than 8000. (A/B). ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 35 613.75 655.00 614 – 620 615.25 619.75 661.00 621.25 620 – 626 625.75 667.00 627.25 626 – 632 631.75 673.00 679.00 632 – 638 633.25 637.75 639 – 644 639.25 643.75 685.00 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 36 331.25 335.75 631.25 635.75 336 – 342 337.25 341.75 383.00 636 –642 637.25 641.75 693.00 342 – 348 343.25 347.75 389.00 642 –648 643.25 647.75 689.00 348 – 354 349.25 395.00 353.75 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 37 DIGITAL CABLE TV Frequence Table (table 3) U.S.A Channel Frequency Assignments (Cable) unit:MHz. CH NO. DTV Center Freq CH NO. DTV Center Freq CH NO. DTV Center Freq ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 38 (3). After all of FUNCTION TEST completed, we must erase all saved changes again and restore the factory defaults. DTV TEST ITEM CHANNEL FREQUENCY SOUND PETTEN CHECK CONTENT Dynamic 471.25MHz Picture picture 603.25MHz Color bar Color Dynamic 801.25MHz Sound and Picture picture ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 39 LEVEL<45~85> dBu, regards as normally. TIMING TABLE (FACTORY PRESET MODE) (table 4) Resolution V-freq D-SUB DVI TO HDMI HDMI 1440x900 59.8 59.9 1280x1024 1280x960 1360x768 1280x768 1280x720 1152x864 1152x870 1024x768 832x624 800x600 640x480 720x400 640x350 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 40 5.4.2 Connection PC to the Tv set by the tool as the follow picture (pc1~pc4) Action: The D_SUB cable must be 15 pin, and the TV set must be AC ON pc.1 pc 2 pc 3 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 41 Press the “config” , if the the ISP board have been found ,you will see the picture as bellow. pc.5 Press the “Connect” ,If all the things are ok and ready, it will show the device type as the bellow picture. Than pres “確定” pc.6 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 42 6. Pull away the AC power Cord and the D-SUB Cable. And start another TV set. When we start another TV set with AC ON, we only need to press the “RUN” ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 43 - RS-232 cable - Barcode Reader - VGA Cable N1930W2M LCD TV DDC Card RS-232 Cable VGA Cable Barcode Reader 5.5.2 Setup Procedure 1. Connect VGA Card and DDC Card with RS-232 cable. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 44 4. Connect Power Cord to N1930W2M LCD TV. 5. Press ‘MENU’and ‘ENTER’ at the same time, then go into the BURN IN MODE. 5.5.3 DDC Key In Procedure 1. run DDC exe 2. Choose model number the ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 45 3. Press “ENTER” key. 4. Press “F4” key and Input bar code ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 46 5. Press “ENTER” key, then the successful picture is as follows. “DDC DOWNLOED 6. Exit program. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 47 N1930W2M LCD TV RS-232 Cable HDMI Cable Barcode Reader 5.6.2 Setup Procedure 1. Connect HDMI Card and DDC Card with RS-232 cable. 2. Barcode Reader connects with keyboard and PC keyboard port. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 48 3. Connect DDC Card and N1930W2M LCD TV with HDMI Cable. 4. Connect Power Cord to N1930W2M LCD TV. 5.6.3 DDC Key In Procedure 1. Run DDC.exe 2. Choose model number then ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 49 3. Press “ENTER” key. 4. Press “F4” key. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 50 5. Input bar code 6. Press “ENTER” key, then the successful picture is as follows. “DDC DOWNLOED 7. Exit program. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 51 1.4 Place the LCD TV into the carton and then Put the other cushions on the LCD TV,put all the accessories into the carton. At last, close the carton and seal it with tape. (Figure 4) 1.User’s Guide 2.Guarant Card 3.Battery Power Cord Remote control Figure 3 Figure 4 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 52 PACKING PART LIST ( N1930w-2 ) ViewSonic Model Number: VS12115-2M Rev: 1a Item ViewSonic P/N Ref. P/N Description Q'ty N1930W2M monitor P-00008710 2013150901P POLYETHY BAG P-00009099 2012107400P POLYFOAM (R) P-00009100 2012107500P POLYFOAM (L) P-00008947 2013222536P POLYETHY BAG 2001131950P OWNER GUIDE...
  • Page 53 Disassembly Procedure Disassembly of Stand, Front Cover and Rear Cover from LCD TV. 1.1 Unscrew 4 screws to remove Stand. Stand 1.2 Unscrew 6 screws to remove Front Cover. Front Cover ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 54 1.3 Unscrew 2 screws to remove Rear Cover. Rear Cover 2. Disassembly of Arm, Shield Plate, Main Board, Power Board and Panel Unit. 2.1 Unscrew 4 screws to remove Arm. ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 55 2.2 Unscrew 5 screws to remove Bracket Fix. Bracket Fix 2.3 Unscrew 8 screws to remove Shield Plate. Shield Plate ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 56 2.4 Unscrew 5 screws and disconnect the wires to remove Power Board. Power Board 2.5 Unscrew 4 screws and disconnect the wires to remove Main Board. Main Board ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 57 2.6 Unscrew 4 screws to remove Panel Unit and Panel Bracket. Panel Unit ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 58: Trouble Shooting Flow Chart

    VCC2.5VOK? D807,I801,I801 I104,SUROUND CAP I201,I206 BEAD OK? SUROUND CAP OK? CHECK CHECK VCC1.2OK? D807,I801,I801 I105,SUROUND CAP I204,I205 BEAD OK? SUROUND CAP OK? CHECK CHECK 5VIF OK? D807,I801,I801 I101,SUROUND L106 OK? L105 OK? ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 59 30VTU,TUNER-5V TV SOUCE I501TUNER Check Check Check Check P501SUROUND HDMI SOUCE HDMI CABLE I201,I206 6.2. LOSE COLOR Some bits lost Check I206 poor P106soldering soldering I202 poor I201 poor soldering soldering CABLE ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 60 5VAMP Check Check I602 I601 Check Check P602 speaker 6.4. REMOTE CONTROL NO USE Check Change CHANGE BATTERY BATTERY BATTERY Check Check P204 P701 Check Check I701 IR5V Check CHANGE I205 REMOTE ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 61: Block Diagram

    7. Block Diagram MSB1501(DEMO) LCD Module COMBO TUNER NTSC MSD2232AL HDMI Flash AV(CVBS) S_VIDEO YPbPr PC(D-Sub) Speaker AV/SV/YPbPrAudio(RCAx1) (2.5Wx2) AD5265A PC Audio(mini jack) EAR PHONE...

  • Page 62: Schematic Diagrams

    100nF R130 measure current 200K R131 Q105 R132 C144 VCC5V-ST MMBT3904 100nF R141 R134 200K R133 PANEL-ON/OFF-GPIO10 Q106 PANEL-ON/OFF-GPIO10 MMBT3904 4.7K R135 Q107 VCC5V-ST MMBT3904 R142 R136 POWER-ON/OFF-PWM2 Q108 POWER-ON/OFF-PWM2 MMBT3904 4.7K ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 63 0x72 10u/16V VCC3.3V_ADJ R250 R251 0xB2 NC/1K NC/1K 0x32 1.2V DTV Demodulator D207 DTV-VDD12 SR36 I205 1084-ADJ DTV-VDD33 VOUT DTV-VDD12 2 C256 C255 C257 C258 100nF 100nF 10u/16V R252 220u/16V 120R R253 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 64 SIF_IN- Close to Tuner Tuner-5V C510 R511 ATV_CVBS Q501 Close to Mstar IC L501 R588 R512 C511 CVBS+ 100nF TV_IN+ TV_IN+ R513 C512 C513 R514 1K 0603 R515 C514 100nF TV_IN- TV_IN- ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 65 R311 4.7K I211 C316 R337 R339 24C04 100nF VCC5V-ST Q202 R295 , R309 ------ JEAN STD 10u/16V MMBT3906 R291 , R306 ------ CUSTOMER 24C04_I2C-SCL R312 100R R333 24C04_I2C-SDA R313 100R R334 R335 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 66 1K 1% 0603 VCC2.5V-ST MVREF-1 VCC2.5V-ST C201 C202 C203 C204 C205 C206 C207 C208 C209 C210 R216 C211 C212 10u/16V 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 1K 1% 0603 100nF 10u/16V ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 67 2,3,4,10,15 +5V_General UART-RX DDC_SDA_D R554 NC UART-TX +5V_General UART-TX D514 BAT54C R555 R556 VGA-TX R557 100R VGA5V 100R 100R VGA-RX R559 100R C520 I503 R558 100nF 24C21 R560 VGA-VCLK VCLK VGA-SCL VGA-SDA ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 68 L503 R576 C538 3.3uH 0805 47nF 4.7P CVBS_IN CVBS1_IN CVBS1_IN 6 C548 C539 C540 R583 1u 0603 D520 680pF 330pF R577 RC_AUL0 AUL0 AUL0 C551 D524 C550 R585 560pF 4.7P 330pF 4.7P ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 69 R532 HDMI-HPDIN 100nF R533 VCLK Q504 4.7K HPD_CTRL HPD_CTRL 6 MMBT3904 HDMI_SCL R534 100R HDMI-SCL HDMI_SDA R535 100R HDMI-SDA 100R R536 DDC_SCL DDC_SCL 6 24C22 SMD 100R R537 DDC_SDA DDC_SDA 6 R538 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 70 L611 0 0603 R630 C635 330pF PHONE_DET 13 5VAMP PHONE JACK NORMAL OPEN R698 C663 R697 22K 100nF 5VAMP Q601 R631 NC 0: SPEAKER MODE 5VAMP 2,13 1: HEADPHONE R632 MODE C636 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 71 SD LOW==>> SHUT DOWN R624 DTV-VDD33 4.7K DTV-VDD33 3 Q603 C666 R625 4.7K R634 MMBT3904 10u/16V AUDIO_DOWN-N POWER-ON/OFF-PWM2 POWER-ON/OFF-PWM2 R635 Q606 MMBT3906 R319 SHUT_DOWN_AU SHUT_DOWN_AU 6 R633 HIGH-->STAND BY ENABLE LOW-->STAND BY DISABLE ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 72 RXOC- RXO2+ LVB2P RXO2+ RXO2- LVB2M RXO2+ LVB2P RXO2- RXO1+ LVB1P RXO2- LVB2M RXO1+ RXO1- LVB1M RXO1+ LVB1P RXO1- RXO0+ LVB0P RXO1- LVB1M RXO0+ RXO0- LVB0M RXO0+ LVB0P RXO0- RXO0- LVB0M CON30p ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 73 D916 1N4148/DIP D904 1N4148 D911 BAV70/SOT R961 3.3M 2N7002/SOT23 Z905 R962 3.3M Q907 BAV70/SOT R959 5.6V C942 D912 R963 3.3M R952 1M R969 100K R968 R967 R953 R931 R954 R956 R958 C919 R932 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 74 R823 option R825 R802 10 3A R842 1.3K 1% C826 0.1U R843 F801 I802 I803 R851 T2.5AH/250V TLP621 TL431D R816 C827 1.21K1% C802 10UF/50V R858 100pF C803 100pF P801 AC IN 100~240V ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 75: Pcb Layout Diagrams

    9. PCB Layout Diagrams 9.1. MAIN PCB TOP VIEW ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 76 9.2. MAIN PCB BOTTOM VIEW ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 77 9.3. CON PCB TOP VIEW 9.4. CON PCB BOTTOM VIEW ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 78 9.5. POWER PCB TOP VIEW ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 79 9.6. POWER PCB BOTTOM VIEW ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...

  • Page 80: Exploded View And Exploded Parts List

    10. Exploded View And Exploded Parts List ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 81 ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
  • Page 82 M3*5MM 2081440084P SCREW (WASH) M4*8 P=0.7(TOOTH WASHER) BLACK M-SCW-0824-0285 2084730082P SCREW BND T+ M3X8(BND T+) 2022276803P CABI BACK N1930W-2M ABS HB BLACK C FOR 92UA HW-00003031 2071872900P BRACKET FIX JT198QP SECC 0.8T WALL MOUNT M-SCW-0824-6719 2082630062P SCREW M3X6 P=0.5 2082630064P SCREW M3*6 P=0.5 BLACK...

  • Page 83: Recommend Spare Parts List

    Remark 1: Above listed items are examples, supplier can expand the rows to add more necessary items. Remark 2: All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
  • Page 84 BOM LIST ( N1930W-2 ) ViewSonic Model Number: VS12115-2M Rev: 1a Serial No. Prefix: R1C Location Item ViewSonic P/N Ref. P/N Description Universal number# Q'ty 2340110096P CS 0402/NPO/50V 10p J T CAP CHIP C104 2340110096P CS 0402/NPO/50V 10p J T...
  • Page 85 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2345710496P CS 0402/Y5V/16V 0.1u Z T CAP CHIP C283 2345710496P CS 0402/Y5V/16V 0.1u Z T CAP CHIP C284 2345710496P CS 0402/Y5V/16V 0.1u Z T CAP CHIP C286 2345710496P CS 0402/Y5V/16V 0.1u Z T...
  • Page 86 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2345710496P CS 0402/Y5V/16V 0.1u Z T CAP CHIP C622 2345710496P CS 0402/Y5V/16V 0.1u Z T CAP CHIP C623 2346710596P CS 0603/Y5V/16V 1.0u Z T CAP CHIP C624 2346710596P CS 0603/Y5V/16V 1.0u Z T...
  • Page 87 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2379560196P Z= 600 ohm 0805 I=1.5A BEAD,HI-CURRENT L108 2379560196P Z= 600 ohm 0805 I=1.5A BEAD,HI-CURRENT L110 2370122016P 22uH 12*12*4.6 YC124RT220MS YOUTH COIL CHOKE SMD L111 2370101696P YC5D18T100M 10uH YOUTH COIL CHOKE SMD...
  • Page 88 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2253156096P RC 0402 1/16W 56 ohm J T RES CHIP 1/16W R202 2253156096P RC 0402 1/16W 56 ohm J T RES CHIP 1/16W R203 2253156096P RC 0402 1/16W 56 ohm J T...
  • Page 89 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2253100096P RC 0402 1/16W 0 ohm J T RES CHIP 1/16W R336 2253210196P RC 0603 1/10W 100 ohm J T RES CHIP 1/10W R340 2253110496P RC 0402 1/16W 100Kohm J T...
  • Page 90 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2253112396P RC 0402 1/16W 12Kohm J T RES CHIP 1/16W R628 2253110296P RC 0402 1/16W 1K ohm J T RES CHIP 1/16W R629 2253110296P RC 0402 1/16W 1K ohm J T...
  • Page 91 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2336310613P EC 10u/ 16V 4*7 P=2.5 T CAP MINI ELE 105'C C308 E-00000999 2336347613P EC 47u/ 16V 5*7 P=2.5 T CAP MINI ELE 105'C C313 2336310613P EC 10u/ 16V 4*7 P=2.5 T...
  • Page 92 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2364600496P-03 RLS4148-T11 SOD80C ROHM DIODE,SWITCH D908 RC 2364600496P-01 MM4148 SOD80C GRANDE DIODE,SWITCH SMD D909 RA 2364600496P-02 BAS32L SOD80C PHILIPS DIODE,RECT(SMD) D909 RB 2364600496P-03 RLS4148-T11 SOD80C ROHM DIODE,SWITCH D909 RC 2364600496P-01 MM4148 SOD80C...
  • Page 93 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2253300096P RC 0805 1/8 W 0 ohm J T RES CHIP 1/8W R971 2202140300P JC198MSP P/B FR1 150*133mm PC BOARD U801 2364513016P RLZ13B LL-34 ROHM DIODE,ZENER SMD Z801 2364513016P RLZ13B LL-34...
  • Page 94 Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty 2335815811P-01 EC 1500u/ 16V 10*20 P=5.0 C HI-LIFE LOW ESR E.CAP(6000hr) C824 RB E-00008737 2336010811P EC 1000u/ 16V 10*16 P=5.0 C HI-LIFE LOW ESR E.CAP(6000hr) C829 RA 2335710811P-01 EC 1000u/ 16V 10*16 P=5.0 C HI-LIFE LOW ESR E.CAP(6000hr)
  • Page 95 Company: Add: Tel: Fax: E-mail: After completing this form, please return it to ViewSonic Quality Assurance in the USA at facsimile 1-909-839-7943. You may also e-mail any suggestions to the Director, Quality Systems & Processes (marc.maupin@viewsonic.com) ViewSonic Corporation N1930w-2M Confidential - Do Not Copy...
