Operation

Front Control Panel

• Scrolls down Main Menu, highlighting
control to be adjusted
• Decreases value of selected control
• Shortcut to Contrast and Brightness
adjustment screens
• Displays OnView ® Main Menu
• Exits adjustment screen and
saves adjustments

Using the OnView

1 To turn the monitor on, press the Power button (shown above).
2 To display the OnView Main Menu, press button [1].
3 To select a user control, press the M or L button repeatedly until the
control is highlighted.
4 To display an OnView adjustment screen, press button [2].
Press button [2] to toggle between controls grouped in pairs on the Main
Menu (see page 12).
5 To adjust the selected user control, press the M or L button.
Exception: For user controls that do not require adjustments, press button [2]
again to activate. (examples: DEGAUSS, MEMORY RECALL).
6 To save your adjustments and exit all screens, press button [1] twice.
The screen will clear automatically about 30 seconds after the last control
button you press. To return to the Main Menu, repeat step 2.
ViewSonic A70
• Scrolls up Main Menu, high-lighting
control to be adjusted
• Increases value of selected control
• Shortcut to Contrast and Brightness
adjustment screens
• Press once to display
adjustment screen
• (For some controls) press
again to toggle between
controls shown in pairs on
Main Menu
®

Controls

Power Light
Power On/Off Button
Operation
E
N
G
L
I
S
H
7
