Wired Remote Controller XK19 and
Wireless Remote Controller YT1F
Owners`s manual
Wired Remote Controller XK19 and
Wireless Remote Controller YT1F
Thank you for choosing our product. Please read this Owner's Manual carefully before operation and
retain it for future reference. If you have lost the Owner's Manual, please contact the local agent or visit
www.cooperandhunter.com.
Advertisement
Table of Contents
Related Manuals for Cooper & Hunter XK19
Summary of Contents for Cooper & Hunter XK19
- Page 1 Wired Remote Controller XK19 and Wireless Remote Controller YT1F Owners`s manual Wired Remote Controller XK19 and Wireless Remote Controller YT1F Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual, please contact the local agent or visit...
- Page 2 User Notice ◆ Never install the wired remote controller in the moist circumstance or expose it directly under the sunlight. ◆ Never beat, throw, and frequently disassemble the wired remote controller and the wireless remote controller. ◆ Never operate the wired remote controller and the wireless remote controller with wet hands. Please read the manual carefully before using and installing this product.
-
Page 3: Table Of Contents
Contents Ⅰ Wired Remote Controller XK19 ..............1 1 Symbols on LCD ................... 1 1.1 Outside View of the Wired Remote Controller ............1 1.2 LCD of the Wired Remote Controller ..............1 2 Buttons ......................2 2.1 Buttons on the Wired Remote Controller .............. 2 2.2 Function of the Buttons .................. -
Page 4: Ⅰ Wired Remote Controller Xk19
Wired Remote Controller XK19 Ⅰ Wired Remote Controller XK19 1 Symbols on LCD 1.1 Outside View of the Wired Remote Controller AUTO TURBO HOUR SHIELD MEMORY MASTER SAVE E-HEATER BLOW QUIET Mode Enter/Cancel Enter/cancel Function Timer On/Off Fig.1 Outside View of the Wired Remote Controller 1.2 LCD of the Wired Remote Controller... -
Page 5: Buttons
l l o Table 1 Symbols Description Swing function. Sleep function (Only sleep 1). Running modes of the indoor unit (Cooling, Dry, Fan and Heating). Defrosting function for the outdoor unit. Gate-control function (this function is yet unavailable for this unit). Lock function. -
Page 6: Function Of The Buttons
Wired Remote Controller XK19 2.2 Function of the Buttons Table 2 Name Function Enter/Cancel Function selection and cancellation. ▲ ① Running temperature setting of the indoor unit, range:16 ～ 30℃ . ② Timer setting, range:0.5-24 hr. ▼ Setting of the high/middle/low/auto fan speed. -
Page 7: Operation Instructions
l l o 3 Operation Instructions 3.1 On/Off Press On/Off to turn on the unit and turn it off by another press. Note: The state shown in Fig.4 indicates the “Off” state of the unit after power on. The state shown in Fig.5 indicates the “On”... -
Page 8: Fan Setting
Wired Remote Controller XK19 Fig.6 3.4 Fan Setting Under the “On”/”Off” state of the unit, press Fan and then fan speed of the indoor unit will change circularly as shown in Fig.7. Middle High AUTO Enter/Cancel Mode Function Timer On/Off Fig.7... - Page 9 l l o Fig. 8 Timer off Setting under the “On” State of the Unit Timer range: 0.5-24hr. Every press of ▲or ▼ will make the set time increased or decreased by 0.5hr. If either of them is pressed continuously, the set time will increase/ decrease by 0.5hr every 0.5s.
-
Page 10: Swing Setting
Wired Remote Controller XK19 3.6 Swing Setting Swing On: Press Function under on state of the unit to activate the swing function. In this case, Swing Off: When the Swing function is on, press Function to enter the Swing setting interface, with blinking. -
Page 11: Sleep Setting
l l o 3.7 Sleep Setting Sleep on: Press Function under on state of the unit till the unit enters the Sleep setting Sleep off: When the Sleep function is activated, press Function to enter the Sleep setting interface. After that, press Enter/Cancel to can this function. In the Cooling or Dry mode, the temperature will increase by 1℃... -
Page 12: Turbo Setting
Wired Remote Controller XK19 3.8 Turbo Setting Turbo function: The unit at the high fan speed can realize quick cooling or heating so that the room temperature can quickly approach the setting value. In the Cooling or Heating mode, press Function till the unit enters the Turbo setting interface When the Turbo function is activated, press Function to enter the Turbo setting interface and then press Enter/Cancel to cancel this function. -
Page 13: E-Heater Setting
l l o 3.9 E-heater Setting E-heater (auxiliary electric heating function): In the Heating mode, E-heater is allowed to be Once the wired remote controller or the remote controller enters the Heating mode, this function will be turned on automatically. Press Function in the Heating mode to enter the E-heater setting interface and then press Enter/Cancel to cancel this function. -
Page 14: Blow Setting
Wired Remote Controller XK19 3.10 Blow Setting Blow function: After the unit is turned off, the water in evaporator of indoor unit will be automatically evaporated to avoid mildew. In the Cooling or Dry mode, press Function till the unit enters the Blow setting interface and then press Enter/Cancel to active this function. -
Page 15: Other Functions
Wired Remote Controller XK19 3.11 Other Functions (1). Lock Upon startup of the unit without malfunction or under the “Off” state of the unit, press ▲ and ▼ at the same time for 5s till the wired remote controller enters the Lock function. In this case, LCD displays . -
Page 16: Installation And Dismantlement
Wired Remote Controller XK19 4 Installation and Dismantlement 4.1 Connection of the Signal Line of the Wired Remote Controller ● Open the cover of the electric control box of the indoor unit. ● Let the single line of the wired remote controller through the rubber ring. - Page 17 Wired Remote Controller XK19 Note：CN1 is 485 communication interface and it used for connecting the 4-core communication wire. These two needle stands(CN2、CN3) are used for connecting the smart zone controller. There is no sequence for these two needle stands. You can connect one or two needle stand(s) basing on the requirement.
- Page 18 DIP switch. There is a 2-bit DIP switch on the main board of wired controller XK19. As for the last #n wired controller in the control system, the 1-bit and the 2-bit of the DIP switch should be manually pulled to position “on” and position “off” respectively. The DIP switches of other wired controllers should be kept at the initial ex-factory status (1-bit and 2-bit are set at position “off”).
-
Page 19: Dismantlement Of The Wired Remote Controller
Wired Remote Controller XK19 cord and connection lines between the indoor and outdoor unit, with a minimum interval of 20cm, otherwise the communication of the unit will probably work abnormally. If the air conditioning unit is installed where is vulnerable to electromagnetic interference, ②... - Page 20 l l o Table 4 Meaning of Each Error Error Error Error Error Code Code Return air temperature sensor open/short Drive board communication error circuited evaporator temperature sensor open/short Compressor overheating protection circuited Indoor unit liquid valve temperature sensor Indoor and outdoor units unmatched open/short circuited Indoor gas valve temperature sensor open/ Communication line misconnected or...
-
Page 21: Ⅱ Wireless Remote Controller Yt1F
Wireless Remote Controller YT1F Ⅱ Wireless Remote Controller YT1F Notes: Be sure that there are no obstructions between the receiver and the remote controller; ① . Do not drop or throw the remote controller; ② . Do not let any liquid into the remote controller and expose the remote controller to direct ③... - Page 22 l l o 3) SLEEP Sleep On and Sleep Off can be selected by pressing this button. After powered on, the default is Sleep Off. After the unit is turned off, the Sleep function is canceled. When the sleep function is set already, the symbol will be displayed.
-
Page 23: Guide For General Operation
Wireless Remote Controller YT1F temperature, or indoor ambient temperature. When the indoor unit is powered on, the indoor set temperature will be displayed, while if the status is changed to , the indoor ambient temperature will be displayed. However, the indoor set temperature will be displayed again when the controller receives other remote controls signals. -
Page 24: Guide For Optional Operation
l l o d. Press FAN to set the fan speed, Auto, Low, Medium, or High. e. Press to select the swing angle. 3 Guide for Optional Operation a. About X-FAN This function indicates that moisture in the evaporator of the indoor unit will be dried after the unit is stopped to avoid mould. - Page 25 Cooper&Hunter International Corporation www.cooperandhunter.com...
