PhoneMate PM5821 Instruction Manual

5.8 ghz cordless telephone with caller id & visual call waiting
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
5.8 GHz
Cordless Telephone
with Caller ID &
Visual Call Waiting
The picture above depicts the dual handset model PM5825
Important
Charge the handset battery for 12 continuous hours prior to first use.
PM5821manual 21mar.p65
PM5821
PM5825
Dual Handset
PM5827
Triple Handset
PM580
5
Expansion Handset
1
1
2006/5/12, ¤U¤È 05:49

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM5821 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PhoneMate PM5821

Summary of Contents for PhoneMate PM5821

  • Page 1 INSTRUCTION MANUAL PM5821 5.8 GHz Cordless Telephone PM5825 Dual Handset with Caller ID & PM5827 Triple Handset Visual Call Waiting PM580 Expansion Handset The picture above depicts the dual handset model PM5825 Important Charge the handset battery for 12 continuous hours prior to first use.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ....................4 GETTING STARTED ..................5 Checking package contents ................5 Modular jack ....................5 Installation tips ....................5 Battery setup ....................6 Connecting the base unit and charging the handset ........6 Connecting the charger and charging the handset (For PM5805) ....6 Telephone line connection ................
  • Page 3 The exclamation point within the triangle is a warning sign alerting you of important instructions accompanying the product. PhoneMate and the PhoneMate logo are registered trademarks of PhoneMate Corporation and are used under License from PhoneMate Corporation. 2006/5/12, ¤U¤È 05:49...

  • Page 4: Introduction

    INTRODUCTION Congratulations on your purchase of this PhoneMate cordless telephone. Your PhoneMate 5.8 GHz cordless telephone is a fine-quality home communica- tions product. It is carefully designed and produced by a world leader of con- sumer and industrial electronic equipment. With proper maintenance and care, it will provide you with years of enjoyment and convenience.

  • Page 5: Getting Started

    GETTING STARTED Checking package contents Make sure your package includes the items shown here. Charger (optional) Base unit Handset Belt clip Battery Telephone AC Adaptor line cord Some models such as PM5825 and PM5827, may contain multiple handsets, Belt Clips, Batteries and AC Adapters. Modular jack You need an RJ11 type modular phone jack.

  • Page 6: Battery Setup

    • It is normal for the handset and base to get warm when the handset is charging in the base. Caution: Use only the PhoneMate AC adaptor that is supplied with this phone. Using another AC adaptor may damage the phone.

  • Page 7: Telephone Line Connection

    Telephone line connection Once the handset battery is fully charged, connect the telephone line cord to the TEL LINE jack on the back of the base. Plug the other end into a telephone outlet. Tone/pulse setting 1. If you have Pulse (rotary) service, you will need to set the dial mode to pulse. If you have Touch-Tone service, do nothing as your phone has been set to Tone prior to shipment.

  • Page 8: Names And Controls

    NAMES AND CONTROLS Handset 1. Belt clip 11. TALK key (also used to end a call) 2. REDIAL key 12. MUTE/FORMAT key (MUTE/FORMAT/TRANSFER key) 3. Headset jack 13. Ringer switch 4. MEM (memory) key 14. CID/VOL (volume) up/down key 5. CH (channel)/DEL key 15.

  • Page 9: Base Unit And Charger

    NAMES AND CONTROLS Base Unit Charger For PM5805 1. Handset Cradle 2. Page Key 3. Charge/In Use LED 4. Charge LED 2006/5/12, ¤U¤È 05:49 PM5821manual 21mar.p65...

  • Page 10: Initial Programming

    INITIAL PROGRAMMING Before using this telephone, 4 initial settings must be completed on the handset: Language, Area code (this is required to use Caller ID service from your tele- phone company), Ringer tone, and Tone/Pulse setting. Language setting 1. Make sure the phone is OFF (not in TALK mode). 2.

  • Page 11: Resetting To Default

    Resetting to default You can reset the phone programming to the initial factory default settings. The default settings are: Language English Area Code - - - Ringer Tone Tone/Pulse Setting Tone 1. Make sure the phone is OFF (not in TALK mode). 2.

  • Page 12: Making A Call

    Making a call 1. Press TALK. Note: If handset is in the base cradle, remove it from base before pressing the TALK key. 2. Dial the phone number. Call No. Call Timer Telephone Number Caller Name 3. Press TALK to end your call. Volume adjustment The VOLUME key adjusts the volume level of the earpiece.

  • Page 13: Pre-Dialing

    Pre-dialing (up to 32 digits) 1. Make sure the phone is OFF (not in TALK mode). 2. Enter the telephone number. The number is displayed as you enter it. 3. Press TALK. Note: Pressing *TONE will exit pre-dialing. Changing the pre-dial number 1.

  • Page 14: Tone Key

    * TONE key This feature enables Pulse service phone users to access touch-tone services offered by banks, credit card companies, etc. 1. Dial the desired number. 2. Press *TONE after your call is answered. 3. Follow the voice instructions to complete your desired action. 4.

  • Page 15: Voice Mail Indicator

    Voice mail indicator When you subscribe to a voice mail service offered by your phone company, the phone alerts you when voice mail has been received. MESSAGE WAITING appears on screen for 60 seconds when a voice mail is received. The LED on the base flashes to indicate there is a voice mail waiting.

  • Page 16: Caller Id List

    Caller ID list The incoming caller information transmitted from the phone company is received by your phone between the first and second ring and stored in the Caller ID list. If you answer a call before the second ring the caller information may not be stored. When the Caller ID list memory is full, a new call automatically replaces the oldest call in memory.

  • Page 17: Storing Caller Id Entries In The Directory

    Storing Caller ID entries in the directory Before storing a caller ID number, make sure the number appears in proper digits for your dialing area. If not, change it using the MUTE/FORMAT key. For example, if the Caller ID number appears 1-416-222-5555 but it is not a long distance number, press MUTE/FORMAT until it shows 416-222-5555 (without 1).

  • Page 18: Deleting All Entries

    Deleting all entries 1. Make sure the phone is OFF (not in TALK mode). 2. Use the CID/VOL keys to display any entry. 3. Press and hold CH/DEL, until “DELETE ALL?” shows on screen. 4. Press CH/DEL again to confirm. “NO CALLS” shows on screen. DIRECTORY You can store up to 10 names (up to 15 characters) and numbers (up to 24 digits) in the directory for quick dialing.

  • Page 19: Storing A Number In The Directory

    and not a pause. Each pause counts as 1 digit in the dialing sequence. Or you can store redial number in the directory by pressing REDIAL (Note: If the redial number is longer than 24 digits, it cannot be stored into the memory.). 8.

  • Page 20: Chain Dialing From The Directory

    With normal usage, your battery should last about one year. For a replacement battery, please contact your place of purchase or www.phonemate.com Caution: • Use only the specified battery type (Ni-MH 3.6V, 600mAh). • Do not remove the battery from the handset to charge it.

  • Page 21: Power Failure

    Make sure the telephone is off before you replace the battery. 1. Slide off the battery compartment cover. 2. Disconnect the battery plug from the jack in the compartment and remove the battery pack. 3. Insert the new battery pack and connect the cord into the jack. Note: Please refer to the pictures on page 6, “Battery setup”...

  • Page 22: Headset Jack And Belt Clip

    HEADSET JACK AND BELT CLIP Headset connection (Headset not included) For hands free conversation, connect the headset (not included) to the HEADSET jack. The handset earpiece and microphone are disabled when the headset is connected. Press TALK to answer or place a call while using the headset.

  • Page 23: Lcd Screen Messages

    END OF LIST Indicates that there is no additional information in Caller ID list. HANDSET 1 This handset is handset 1 (For use with model PM5821). This handset is handset 2 (For use with models HANDSET 2 PM5805 and PM5825).

  • Page 24: Sound Signals

    Waiting Caller ID service is subscribed to and is functioning properly. • If you answer the call before the first ring has been completed, the Caller ID information may have not been completely received by your PhoneMate phone. • If you are using the additional handset(s) PM5805, try re-registering it to the PM5821 base as described in the manual.
  • Page 25 • When you press a button from the keypad, you should hear the confirmation "beep" from the PM5821 or PM5805, and also the tone or pulse (depending on your dialling method) that actually dials the number. Try dialling more slowly and ensure you hear both of these sounds.
  • Page 26 • Charge battery. • Make sure base is not plugged into an outlet with another household appliance. Phone beeps • Place handset in base for a minimum of 20 seconds to reset the security code. If that does not work, charge battery for 12 continuous hours. •...
  • Page 27 Disconnect the handset battery for 5-10 seconds and then reconnect. Place the handset back on the base and then replug the AC adapter. • If you are using the additional handset(s) PM5805, try re-registering it to the PM5821 base as described in the manual. 2006/5/12, ¤U¤È 05:49 PM5821manual 21mar.p65...

  • Page 28: Maintenance

    Causes of poor reception • Aluminum siding. • Foil backing on insulation. • Heating ducts and other metal construction can shield radio signals. • You are too close to appliances such as microwaves, stoves, computers, etc. • Atmospheric conditions, such as strong storms. •...

  • Page 29: Maximize Battery Performance

    2. Then charge it for 12 continuous hours. 3. Repeat the above once more. As your PhoneMate PM5821, PM5825, PM5827 and PM5805 products use a Ni-MH battery you are free to leave your handset in the base charger for as long as you like, without effecting the performance of the battery life.

  • Page 30: Technical Information

    TECHNICAL INFORMATION REN Number: interpreted as a defect of the phone. 2. RANGE The Ringer Equivalence Number (REN) assigned to each terminal’s device Because radio frequencies are used, provides an indication of the maximum the location of the base station can number of terminals allowed to be affect the operating range of the connected to a telephone interface.
  • Page 31 (telephone information. Use only with specified extension cord). The customer should PHONEMATE power adaptor. be aware that compliance with the above conditions may not prevent NOTICE: This equipment meets the degradation of service in some applicable Industry Canada Terminal situations.

  • Page 32: Fcc Statement

    TECHNICAL INFORMATION Equipment Technical Specifications. that Industry Canada technical This is confirmed by the registration specifications were met. It does not number. The abbreviation, IC, before imply that Industry Canada approved registration number signifies that the equipment. registration was performed based on a Declaration of Conformity indicating FCC STATEMENT interference by one or more of the...

  • Page 33: Consumer Information

    Excessive RENs on a telephone line may result in the device www.phonemate.com not ringing in response to an incoming Minneapolis Service Center call. In most but not all areas, the sum of 10901 Louisiana Ave.
  • Page 34 NOTICE If your home has specially wired alarm equipment connected to the telephone line, ensure the installa- tion of this PM5821 does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your tele- phone company or a qualified installer.

  • Page 35: Manufacturer's Warranty

    This product purchased new, unused a. Products purchased outside of the in the USA and Canada through an USA and Canada. authorized PhoneMate dealer are b. Communications products warranted against manufacturing purchased in a used condition. defects in materials and workmanship c.
  • Page 36 In no event shall PHONEMATE or any of its Authorized Dealers be liable for special or consequential damage arising from 2006/5/12, ¤U¤È...
  • Page 37 IMPORTANT SAFETY INSTRUCTIONS 19. Do not use the telephone to report a gas leak in the vicinity of the leak. 20.Do not place this product on an unstable cart, stand or table. Some of the following information may not apply to your particular product; The product may fall, causing serious damage to the product.
