PhoneMate PM5820 Installation And Operating Manual

5.8ghz cordless telephone with call waiting caller id
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PM5820Manual_En-ˆ •´
2004.10.6 12:59 PM
˘
www.phonemate.com
` 1
AGFA SelectSet Avantra 25
Model PM5820
5.8
GHz
C O R D L E S S
T E L E P H O N E
W I T H C A L L
W A I T I N G
C A L L E R
I D
I N S TA L L AT I O N
A N D
O P E R AT I N G
G U I D E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM5820 and is the answer not in the manual?

Questions and answers

Related Manuals for PhoneMate PM5820

Summary of Contents for PhoneMate PM5820

  • Page 1 PM5820Manual_En-ˆ •´ 2004.10.6 12:59 PM ˘ AGFA SelectSet Avantra 25 Model PM5820 C O R D L E S S T E L E P H O N E W I T H C A L L W A I T I N G C A L L E R www.phonemate.com...

  • Page 2: Table Of Contents

    TROUBLE SHOOTING....................35 GLOSSARY.......................37 WARRANTY STATEMENT ..................38 Thank you for purchasing this PhoneMate Telephone. Please read this manual carefully prior to using. PhoneMate and the PhoneMate Logo are registered trademarks of PhoneMate Corporation and are used under license from PhoneMate Corporation.

  • Page 3: Important Safety Instructions

    AGFA SelectSet Avantra 25 NOTES IMPORTANT SAFETY INSTRUCTIONS Model PM5820 !! Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electrical shock. When using this product, basic precautions should always be followed to reduce...
  • Page 4 AGFA SelectSet Avantra 25 IMPORTANT SAFETY INSTRUCTIONS NOTES Model PM5820 adjustment of other controls may result in damage and require work by a qualified technician to restore the product to normal operation. 13. Avoid using a telephone (other than a cordless type) during an electrical storm.

  • Page 5: Fcc Regulations

    1. This equipment complies with Part 68 of the FCC rules and the requirements consumer of a PhoneMate branded product by the Manufacturer and is valid only with adopted by the ACTA. On the bottom of this equipment is a label that contains, respect to consumers within the United States of America and Canada.
  • Page 6 PM5820Manual_En-ˆ •´ 2004.10.6 12:59 PM ` 11 AGFA SelectSet Avantra 25 FCC R EG ULAT IONS G LOSSA R Y M odel PM 5820 Service can be obtained at: P B X ( P r ivat e B r anch Ex change) Ð A small, central, privately owned, switching telephone system where a digit (like "9") must be dialed first in order to access an outside PhoneM ate Service C enter line...

  • Page 7: Ic Regulations

    If you answer the call before the first ring has been completed, the Caller ID interface. The termination on any interface may consist of Ringer Equivalence Numbers of all information may have not been completely received by your PM5820. the device does not exceed 5.

  • Page 8: Battery Cautionary Instructions

    ` 15 AGFA SelectSet Avantra 25 BATTERY CAUTIONARY INSTRUCTIONS TROUBLE SHOOTING Model PM5820 CAUTION : No dial tone/phone will not dial out Check that the AC power adapter is plugged into a working AC power outlet. Risk of explosion if battery is replaced by an incorrect type. Dispose of used...

  • Page 9: Pm5820 Parts Checklist

    Cord for desk use The PM5820 should be kept free of dust and moisture. If it gets wet, wipe it dry Belt Clip immediately. Liquids can contain minerals that can corrode electronic circuits.

  • Page 10: Controls And Features

    The Caller ID key is used to recall and well as store numbers into the Phone review the Caller ID information stored Book. in Memory. The PM5820 stores up to Security Code Temporary Tone/View Left Key 40 Names and Numbers.
  • Page 11 2004.10.6 12:59 PM ˘ ` 21 AGFA SelectSet Avantra 25 CALLER ID CONTROLS AND FEATURES Model PM5820 Press the CID button to access the Caller ID Memory View Right Key The View Right Key is used to scroll Use the to scroll through the Caller ID memory until you find the desired entry.
  • Page 12 AGFA SelectSet Avantra 25 CONTROLS AND FEATURES CALLER ID Model PM5820 BASE To end one call, press the FLASH button at the end of the conversation. As the caller also hangs up, that call will be terminated and the other call will now be...
  • Page 13 If someone tries to call you while you are currently having a telephone conversation, your flash slowly. Beside this icon the number of PM5820 will generate a "beep" and will temporarily mute the handset volume, to notify new calls in the Caller ID log will be you that someone else is attempting to call you.

  • Page 14: Choosing A Location

    Note: Once the Caller ID information is received it is stored in the Caller ID memory. This Away from other cordless telephones information can be recalled later to return the call. The PM5820 can store up to 40 calls. Place the base near an AC electrical outlet and near a telephone line jack Place the base away from metal walls and metal file cabinets.

  • Page 15: Telephone Setup

    Select between ringer On, or ringer Off. Wall Mounting The PM5820 telephone conforms to a standard wall mount bracket. If you are not using Press the MUTE/PROG button twice. The display will now show the "REJ" icon. a standard wall mount bracket, the PM5820 maybe installed onto two screws (not included) fastened into the wall.
  • Page 16 PM5820Manual_En-ˆ •´ 2004.10.6 12:59 PM ` 31 AGFA SelectSet Avantra 25 T ELEP H ONE SET UP SP EED DIA LING M odel PM 5820 W all M ount ing Inst r uct ions: Ed it in g a St or ed Na m e a n d Num ber Remove the handset from the base Press M EM / SAVE.

  • Page 17: Battery Installation

    ` 33 AGFA SelectSet Avantra 25 SPEED DIALING BATTERY INSTALLATION Model PM5820 Making a Call from the Phone Book To install the 3.6V 600mAh cordless handset battery pack: To place a call using the phone book, press MEM/SAVE Slide open the battery compartment door on the back of the handset.

  • Page 18: Headset And Belt Clip

    PM5820Manual_En-ˆ •´ 2004.10.6 12:59 PM ` 35 AGFA SelectSet Avantra 25 H EA DSET A ND B ELT-CLIP SP EED DIA LING M odel PM 5820 T he Headset Jack KEY # Press Press Press 3 Press 4 Press 5 Press 6 Press 7 Press 8...

  • Page 19: Basic Operation

    If the handset is off the base, you will need to press Talk to answer the call. When you are finished, push Talk or place the handset back on the base. For example, to enter the name PhoneMate do the following: Press 7 once for the letter "P"...

  • Page 20: Settings

    Using the scroll keys select between On and Off. Auto-Answer On/Off: The PM5820 comes with a factory default setting of "Off". When set to "On" the call is automatically answered as soon as the handset is Once you have selected the setting, press the MEM/SAVE button to save the lifted out of the base.
  • Page 21 ˘ ` 41 AGFA SelectSet Avantra 25 SETTINGS SETTINGS Model PM5820 Press FLASH/EDIT button to change the setting. "2" will flash in the display. Changing the Language Using the scroll keys select the appropriate dialing delay. Press and hold the MUTE/PROG key.
  • Page 22 ˘ ` 43 AGFA SelectSet Avantra 25 SETTINGS SETTINGS Model PM5820 Setting the Time and Date Press and hold the MUTE/PROG key. Press and hold the MUTE/PROG key. Press "5" to access the PBX Number option. Press "3" to access the TIME SET option.
