LG HT502THW-D1 Owner's Manual

Wireless dvd/cd receiver system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HT502THW-D1.DESPHLP_ENG_MFL41266948
WIRELESS DVD/CD
RECEIVER SYSTEM
OWNER'S MANUAL
MODEL: HT502THW
Main Unit - HT502THW-D1
Speakers - SH52TH-F
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and
completely.
SH52TH-S
SH52TH-C
SH52TH-W
W92-T, W92-R
R

Advertisement

Table of Contents
loading

Related Manuals for LG HT502THW-D1

Summary of Contents for LG HT502THW-D1

  • Page 1 HT502THW-D1.DESPHLP_ENG_MFL41266948 WIRELESS DVD/CD RECEIVER SYSTEM OWNER’S MANUAL MODEL: HT502THW Main Unit - HT502THW-D1 Speakers - SH52TH-F SH52TH-S SH52TH-C SH52TH-W W92-T, W92-R Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
  • Page 2 CAUTION: The apparatus should not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such RISK OF ELECTRIC SHOCK as vases, should be placed on the apparatus. DO NOT OPEN CAUTION concerning the Power Cord Most appliances recommend they be placed upon CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK...

  • Page 3: Table Of Contents

    Introduction Maintenance and Service Maintenance and Service ....3 Before use ......4 Refer to the information in this chapter before Front Panel/Rear Panel .

  • Page 4: Before Use

    Introduction Before use Types of Playable Discs To ensure proper use of this product, please read this (8 cm / 12 cm disc) owner’s manual carefully and retain it for future reference. Video CD (VCD) (8 cm / 12 cm disc) This manual provides information on the operation Audio CD and maintenance of your DVD/CD Receiver.

  • Page 5: Front Panel/Rear Panel

    Front Panel/Rear Panel POWER DISC Tray DISPLAY Window VOLUME controller TUNING(-/+)/SKIP/ SEARCH(. . /> > ) STOP (x) AUDIO IN connector PAUSE ( X X )/ MONO/STEREO (ST.) USB port FUNC.(-)/PLAY(B) Connect to a USB port of a memory Press and hold down this button device (USB memory etc.) about 3 seconds, then press repeatedly to select other function.

  • Page 6: Remote Control

    Views the various displays of the RDS DIMMER options. Changes brightness of the display window on the front panel during in Controls the TV. (LG TV only) power-on status. (See page17) To start a search for a specific PTY type. Remote Control Operation Range...

  • Page 7: Installation And Setup

    Installation and Setup TV Connection Make one of the following connections, depending on Video connection the capabilities of your existing equipment. Connect the MONITOR OUT jack from the DVD/CD Receiver to the VIDEO IN jack on the TV using the Tips: video cable (V).

  • Page 8: Optional Equipment Connection

    Optional Equipment Connection OPTICAL IN connection (O) Auxiliary device DVD Player Connect an optical output of DVD Player (or Digital (or Digital Device etc) to the OPTICAL IN connector. Device, etc) VIDEO AUDIO (L) AUDIO IN connection (D) AUDIO (R) OPTICAL Connect a output of portable device (MP3 or PMP etc) To AUDIO OUT (L/R)

  • Page 9: Speaker System Connection

    Speaker System Connection Notes: Optimum performance can be implemented only when the Connect the speakers to the front (right, left) or Wireless Transmitter and the Wireless Receiver within center speaker connectors at the main set. distance of 2m to 10m is used since communication Connect the subwoofer to the woofer connector.

  • Page 10: Setup The Wireless System

    Setup the Wireless System Wireless Receiver Note: LED indicator If there is a strong electromagnetic wave product Displays the operated nearby, an interference may be occurred. Put the unit status. (Wireless Receiver and main unit) away from there. (Ex : Micro wave oven) Wireless transmitter LED indicator of Wireless Receiver * LED indicator - “BLUE”...

  • Page 11: Setting An Id Of Transmitter

    Setting an ID of Wireless Note: If there is no audio signal for longer than 10 minutes, Transmitter the Wireless Receiver and Wireless Transmitter will be automatically switched to standby mode. At power When the unit is manufactured, the ID is already set. saving mode, both LEDs will turn red.

  • Page 12: Displaying Disc Information On-Screen

    Displaying Disc Information GENERAL OPERATION On - screen 1. Press SETUP. The Setup menu appears. 2. Use v / V to select the desired option then press You can display various information about the disc B to move to the second level. The screen shows loaded on-screen.

  • Page 13: Display

    DISPLAY Progressive Scan Progressive Scan Video provides the highest quality DISPLAY pictures with less flickering. 16 : 9 TV Aspect Widescreen Display Mode If you are using the COMPONENT VIDEO OUT jacks, Progressive Scan but are connecting the receiver to a standard (analog) television, set Progressive Scan to Off.

  • Page 14: Audio

    AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the receiver’s AUDIO options according to the type of audio system you use. 1. Press ENTER, and the 5.1 Speaker Setup menu appears.

  • Page 15: Lock (Parental Control)

    LOCK (Parental Control) Area Code Enter the code of the area whose standards were LOCK used to rate the DVD video disc, based on the list on Rating Unlock page 24. Password **** Area Code 1. Select “Area Code” on the LOCK menu then press B.

  • Page 16: Operation

    Operation General features Buttons Operations Discs Z (OPEN / CLOSE) Opens or closes the disc tray. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. DivX SKIP (. / >) During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track.

  • Page 17: Additional Features

    DivX Your remote control is capable of operating your To enter a Marker DVD/CD Receiver as well as limited functions of LG You can start playback from up to nine memorized Follow the instructions below to operate your LG TV.

  • Page 18: Playing An Audio Cd Or Mp3/Wma File

    Playing an Audio CD or Programmed Playback MP3/WMA file The program function enables you to store your favorite tracks from any disc in the receiver memory. A This unit can play Audio CDs or MP3/WMA files. program can contain 300 tracks. MP3/ WMA/ Audio CD 1.

  • Page 19: Viewing A Jpeg File

    Zoom Viewing a JPEG file JPEG Press the ZOOM repeatedly. This unit can play discs with JPEG files. Zoom on y Zoom off Before playing JPEG recordings, read the notes on Press v, B or M to enlarge the photo(video) image. JPEG Recordings on the right.

  • Page 20: Playing A Divx Movie File

    Playing a DivX Movie file DivX disc compatibility with this player is limited as follows: Using this DVD/CD Receiver you can play DivX disc. • Available resolution size of the DivX file is under 1. Insert a disc and close the tray. The MOVIE menu 800x600 (W x H) pixel.

  • Page 21: Presetting The Radio Stations

    Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM (MW). Preset radio stations in the DVD/CD Receiver’s Before tuning, make sure that you have turned down memory first (see “Presetting radio stations” on the the volume.

  • Page 22: Rds Operation

    RDS Operation Programme Search (PTY) A major benefit of RDS is its ability to encode This unit is equipped with RDS (Radio Data System), broadcasts with Programme Type (PTY) codes that which brings a wide range of information to FM radio. indicate the type of material being broadcast.

  • Page 23: Sleep Timer Setting

    The SLEEP indicator and the sleep time appears in the display window. XTS-P ON The unique sound quality of the LG Technology 2. Each time you press SLEEP the setting creates the optimum sound for you to play the changes in the following order.

  • Page 24: Reference

    Reference Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian...

  • Page 25: Troubleshooting

    Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the • The power cord is disconnected. No power. wall outlet. • Insert a disc. (Check that the DVD or, •...
  • Page 26 Symptom Cause Correction • The antenna is positioned or connected • Connect the antenna securely. Radio stations cannot poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...

  • Page 27: Specifications

    Specifications Power supply Refer to main label. Power consumption Refer to main label. Net Weight 3.6 kg External dimensions (W x H x D) 430 x 70 x 311 mm Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal Operating humidity 5% to 85% Laser Semiconductor laser, wavelength 650 nm...
  • Page 28 P/NO : MFL41266948...
