- Page 1 Home Appliances Dishwashing User Manual Fullsize Dishwasher QW-S12I492X-FR For Life...
- Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................1 1.3. During Use........................2 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................6 2.5. Electrical Connection ....................7 2.6. - Page 4 8.CLEANING AND MAINTENANCE ................. 16 8.1. Cleaning the Machine and Filters ................16 8.2. Spray Arms ........................16 9.TROUBLESHOOTING ....................17 10.PRACTICAL INFORMATION ..................19...
-
Page 5: Safety Instructions
1.1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. -
Page 6: Installation Warnings
1.2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void. - Page 7 The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position. For models with the automatic door-opening system, when the EnergySave option is active, the door will open at the end of a program.
- Page 8 be performed by an authorised service company, otherwise the warranty will be void. Before repair work, the machine should be disconnected from the mains. Do not pull the cable to unplug the machine. Switch off the water tap. Operation at a low voltage will cause a decline in performance levels.
- Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
-
Page 10: Installation
1. INSTALLATION WARNING: Run water through the new hose before connecting. 1.1. Machine positioning When positioning the machine, place it in an area where dishes can be easily loaded WARNING: Connect the hose and unloaded. Do not put the machine in an directly to the water inlet tap. -
Page 11: Electrical Connection
1.5. Electrical connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. The earthed plug of the machine must be connected to an earthed outlet supplied by suitable voltage and current. -
Page 12: Technical Specifications
2. TECHNICAL SPECIFICATIONS 2.2. Technical specifications 10 place Capacity settings Dimensions Height 820-870(mm) Width 450(mm) Depth 570(mm) Net weight 32 kg Operating 220-240V 50 voltage / (Hz) frequency Total 10(A) current Total power 1900(W) 2.1. General appearance Maximum: 1. Upper basket with racks Water 1 (Mpa) 2. -
Page 13: Before Using The Appliance
. BEFORE USING THE APPLIANCE .1. Preparing your Dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine. •... -
Page 14: Test Strip
.3. Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices. -
Page 15: Filling The Detergent
4.8. Filling the detergent In order to change the rinse aid level, follow the below steps before turning on Push the latch to open the dispenser and the machine: pour in the detergent. • Push the programme button and hold it Close the lid and press it until it locks in down. -
Page 16: Loading Your Dishwasher
You can also place long forks, knives and spoons on the racks laterally. WARNING: Always place sharp utensils with the sharp point down and open utensils with their openings down. Upper Basket Height adjustment... -
Page 17: Alternative Basket Loads
5.2. Alternative Basket Loads Lower Basket Top Basket Incorrect Loads Important Note for Test Laboratories For detailed information required for tests according to EN normatives and a softcopy of the manual, please send the model name and serial number to the following address: dishwasher@standardtest.info EN - 13... -
Page 18: Programme Table
6. PROGRAMME TABLE Detergent A: 5cm³ Duration Programme Description B1: 15cm³ (min) B2: 25cm³ Intensive A+B2 For heavily soiled dishes. A+B2 Standard programme for normally soiled, daily-used/ dishes. (Reference) Prewash To rinse dishes that you plan to wash later. NOTE: THE PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF DISHES, THE WATER TEMPERATURE, THE AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. -
Page 19: The Control Panel
7. THE CONTROL PANEL 7.2. Cancelling a Programme If you would like to cancel a programme while in operation. Open the door of your machine. The light corresponding to the selected program will illuminate. Press the Power On/Off button (1). The End Of Programme Indicator (3) will illuminate. -
Page 20: Cleaning And Maintenance
8.CLEANING AND the filters. Replace the filter insert, and MAINTENANCE rotate it clockwise (4). • Never use your Dishwasher without a Cleaning your Dishwasher is important filter. to maintain the machine’s service life. • Incorrect fitting of the filter will reduce Oil and lime may build up in your the washing effectiveness. -
Page 21: Troubleshooting
9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start. - Page 22 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
-
Page 23: Practical Information
AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE CODE POSSIBLE FAULT WHAT TO DO Make sure the water inlet tap is open and water is flowing. Insufficient water Separate the inlet hose from the tap and clean the filter of the hose. Contact for service if the error continues. - Page 24 Register your product here WWW.SHARPHOMEAPPLIANCES.COM, by registering with Sharp you become part of our For Life promise to always be there for you and your appliance. Visit our website: www.sharphomeappliances.com Or contact us: Service & Support %100 recycleable paper 52248258 R36...
