SolarGoesGreen SGG-FL3W-Extreme Manual

SolarGoesGreen SGG-FL3W-Extreme
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

DESCRIPTION

The SolarGoesGreen solar SMD-LED flood light is the premier choice for indoor or outdoor solar lighting. The versatility of
the SolarGoesGreen SGG-FL3W-Extreme makes it the best choice for use in gardens, parks, warehouses, garages, driveways,
signs, yards, farms, horse riding arenas and businesses. The SolarGoesGreen solar LED security flood light is easily installed.
The battery is protected by an auto-detection circuit maximizing the brightness of the lamp and allowing the light to operate
longer as the battery charge declines.

PARTS

1 each 11W Solar Panel
1 each 30 SMD-LED Light with 11.1V Lithium Ion battery
1 each RF Wireless Remote Control
1 each external PIR motion sensor
1 each Allen wrench
1 each metal bracket for Solar Panel
Mounting Screws

INSTALLATION

1) INSTALLATION OF SOLAR PANEL
Mount the solar panel with unobstructed view to direct sunlight. For optimum performance, the solar panel must face the
southern horizon, positioned at a 45 degree angle. For ideal mounting of solar panel, the Optional SGG-PoleMT-301 Solar
Panel Mount can be purchased from an authorized retailer. If drilling through aluminum solar panel edge for any mounting
needs, great care must be taken to prevent drill bit from impacting solar panel.
2) INSTALLATION OF LIGHT
Mount the light to customer supplied pole or attach it on the wall using mounting screws provided.
Connect lamp wire to solar panel connector.
Located on the lamp housing, switch the power to the ON position. Lamp will light up (flash on then off) and shut down after
several seconds. Please note the lamp is off when the Power button switch is sunken and the lamp is ON when the button
switch is in the popped up position.
To test operation of unit, completely shield the face of solar panel by laying it face down on a flat surface or cover the panel
with thick black cloth. The lamp will turn ON after several seconds.
After completing the above, the remote control functionality can now be used to manage the unit's brightness and working
time independently. Please note the remote control only operates light function when the switch is set to the "ON" power
position on light.

REMOTE CONTROL Use

Dimmer and timer function.
Dimmer Options: 10%, 30%, 50%, 70%, 100%
Timer Options: 2 Hours, 4 Hours, 6 Hours, 8 Hours, 10 Hours
Press the corresponding button for desired working mode.
Selected working mode remains unchanged until new mode
is selected or power switch is turned to off position.
If the light is turned OFF by remote control, lamp must be turned
ON again by remote control or by resetting the power switch to the
OFF position. Doing so returns the unit to Factory Default settings.
NOTE: When lamp is set by remote control, light will have a flash to
hint selected mode is set successfully.
