SolarGoesGreen SGG-F108-3T
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGHT.
DESCRIPTION
The SolarGoesGreen solar SMD-LED flood light is the premier choice for indoor or outdoor solar
lighting. The versatility of the SolarGoesGreen SGG-F108-3T makes it the best choice for use in
gardens, parks, warehouses, garages, driveways, signs, yards, farms, horse riding arenas and
businesses. The SolarGoesGreen solar LED flood light is easily installed. The battery is protected by
an auto-detection circuit maximizing the brightness of the lamp and allowing the light to operate
longer as the battery charge declines.
PARTS
1 each 11W Solar Panel
1 each 108 SMD-LED Light Lamp
1 each waterproof 11.1V, 6Ah Lithium Ion Battery, attached to panel with aluminum alloy stock
1 each RF Wireless Remote Control and Timer
1 each Ground Stakes for Solar Panel
Mounting Screws
INSTALLATION
1) INSTALLATION OF SOLAR PANEL
Mount the solar panel with unobstructed view to direct sunlight. For optimum performance, the solar
panel must face the southern horizon, positioned at a 45 degree angle using the ground mount stake or
wall mount provided. For ideal mounting of solar panel, the Optional SGG-PoleMT-301 Solar Panel
Mount can be purchased from an authorized retailer.
2) INSTALLATION OF LIGHT
•
Mount the light to customer supplied pole or fix it on the wall using mounting screws provided.
•
Connect lamp wire to battery connector.
•
Switch the power to ON position. Lamp will light up (flash on then off) and shut down after several
seconds.
To test operation of unit, completely shield the face of solar panel by laying it face down on a flat
surface or cover the panel with thick black cloth. The Lamp will turn ON after several seconds.
After completing the above, the remote control functionality can now be used to manage the unit's
brightness and working time independently. Please note the remote control only operates light
function when the switch is set to the "ON" power position on light.
POWER SWITCH DESCRIPTION:
– ON at night and charging during the day.
– Completely OFF - no charging.
O
– Only charging.
REMOTE CONTROL
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Related Manuals for SolarGoesGreen SGG-F108-3T
Summary of Contents for SolarGoesGreen SGG-F108-3T
- Page 1 The SolarGoesGreen solar SMD-LED flood light is the premier choice for indoor or outdoor solar lighting. The versatility of the SolarGoesGreen SGG-F108-3T makes it the best choice for use in gardens, parks, warehouses, garages, driveways, signs, yards, farms, horse riding arenas and businesses.
- Page 2 In the Dusk to Dawn mode (no remote control), the lamp will turn on automatically at dusk and off at dawn. The factory default setting of SGG-F108-3T when the ON position is selected and no Remote Control used is fixed for 4 hours at 100% brightness then automatically switches to 50%. If the light operates without remote control, lamp keeps this working mode all the time.
- Page 3 For use with earth stake attaching U-shaped lamp bracket. Order of Assembly Bolt through bottom of earth stake, U shape bracket through bolt in center hole of bracket, washer, and then lock washer and tighten. Note: Bolt will sit at a slight angle. www.SolargoesGreen.com...
