6. Remove OIL FILL CAP . Add recommended oil (see
SPECIFICATIONS). DO NOT FILL ABOVE THE DIPSTICK
"FULL" MARK. Crankcase oil capacity is 5.5 U.S. quarts (5.2
liters).
After refilling the crankcase with oil, always
check oil level on dipstick. NEVER OPERATE
ENGINE WITH OIL BELOW THE DIPSTICK
"ADD" MARK.
7. Start engine and check for oil leaks.
Figure 10.2 - Oil Filter
Oil Filter

CHANGING THE ENGINE AIR CLEANER

To replace the engine air cleaner, remove the air cleaner cover and
replace the air filter making sure it is positioned properly before
reattaching the cover.
See the "Service Schedule" section for air cleaner maintenance.

SPARK PLUGS

Reset the spark plug gap or replace the spark plugs as neces-
sary.
1. Clean the area around the base of the spark plugs to keep dirt
and debris out of the engine. Clean by scraping or washing
using a wire brush and commercial solvent. Do not blast the
spark plugs to clean.
2. Remove the spark plugs and check the condition. Replace
the spark plugs if worn or if reuse is questionable. See the
"Service Schedule" section for recommended inspection.
3. Check the spark plug gap using a wire feeler gauge. Adjust the
gap to 1.01 mm (0.040 inch) by carefully bending the ground
electrode (Figure 10.3).
Maintenance
Figure 10.3 – Setting the Spark Plug Gap

COOLANT CHANGE

Every year, have an Authorized Service Facility drain, flush and
refill the cooling system. See the "Specifications" section for cool-
ing system recommendations.

MISCELLANEOUS MAINTENANCE

CLEANING THE GENERATOR

Keep the generator as clean and as dry as possible. Dirt and
moisture that accumulates on internal generator windings have an
adverse effect on insulation resistance.
Periodically clean generator exterior surfaces. A soft brush may be
used to loosen caked on dirt. Use a vacuum system or dry, low
pressure air to remove any accumulations of dirt. The generator is
housed inside an all-weather enclosure, clean the enclosure with a
soft, damp cloth or sponge and water.
Once each year, have the generator cleaned and inspected by an
Authorized Service Dealer. That dealer will use dry, low pressure air
to clean internal windings. Parts inside the control console should
be cleaned and inspected at this time as well.
Finally, have the insulation resistance of stator and rotor windings
checked. If insulation resistances are excessively low, the genera-
tor may require drying.

BATTERY

All lead-acid storage batteries discharge when not in use. Refer to
specific instructions and warnings that accompany the battery. If
such information is not available, observe the following precau-
tions when handling a battery:
• DO NOT use jumper cables and a booster battery to crank or
start the generator engine.
• DO NOT recharge a weak battery while it is installed in the gen-
erator. Remove battery from generator and recharge in a well-
ventilated area, away from fuel vapors, sparks, heat or flames.
• Battery electrolyte fluid is an extremely caustic sulfuric solution
that can cause severe burns. DO NOT permit fluid to contact
eyes, skin, clothing, painted surfaces, wiring insulation, etc.
If any battery fluid is spilled, flush the affected area with clear
water immediately.
