- Page 1 INSTALLATION, OPERATION AND M A I N T E N A N C E I N S T R U C T I O N S High-temperature heat pumps 61AF-B Nominal heating capacity 14 - 20 kW / 50 Hz Original document...
-
Page 3: Table Of Contents
61 AF High temperature Heat Pumps with integrated hydronic module For the use of the control system, refer to the Pro-Dialog + control manual. Contents Page Start-up check list ......................................1 Physical data and electrical data ................................2 Dimensions and location of connections (mm) ..........................3 User interface and main switch ................................ -
Page 4: Physical Data And Electrical Data
61 AF Physical data and electrical data Table I: Physical data 61AF 014-7 014-9 019-9 Operating weight Standard unit (without hydronic kit) Standard unit (plus hydronic module option) Sound levels Sound power level dB(A) Sound pressure level at 10 m dB(A) Compressor Hermetic scroll 48.3 r/s... -
Page 5: Dimensions And Location Of Connections (Mm)
61 AF Dimensions and location of connections (mm) E N G L I S H 61AF014 1 water outlet 2 water inlet Fixing Holes 3 relief valve outlet 4 electrical connections 61AF019 Fixing Holes 0 10 1 water outlet 2 water inlet 3 relief valve outlet 4 electrical connections GB - 3... -
Page 6: User Interface And Main Switch
61 AF User interface and main switch 61AF014 61AF019 User Interface User Interface Disconnector Service Door Service Door * Check that the user interface is protected as described in section “Electronic control”. Minimum Clearances (mm) 61AF 1000 GB - 4... -
Page 7: General Information And Hydronic Module
For other Directive and EMC Directive. applications, please consult Carrier. • In the case of heat pump operation with an outdoor temperature • Check that the impedance of the mains power supply is in of less than 0 °C the unit must be installed at least 300 mm above... - Page 8 61 AF General information and hydronic module Hydronic module 019P The hydronic module is factory-installed. This eliminates the need to install the necessary components onsite, making the unit more compact and easy to install. 014P 1 air purge 1 air purge 2 water pump 2 water pump 3 Brazed Plate Heat exchanger...
- Page 9 40 % (higher concentrations depend on the mix viscosity and the operating conditions address to Carrier for further details). For an application with a water circuit, the following recommendations must be taken into account.
- Page 10 61 AF Water connections Water pressure drop of the unit without hydronic module 61AF014 - 019 1 - 61AF 014 2 - 61AF 019 water flow rate [l/s] Outlet available static pressure of the unit with hydronic module 61AF014 014 - 100% 014 - 80% 014 - 50% water flow rate [l/s]...
- Page 11 1 and 3 bars No control is required at start-up, but the control mode (maximum), must be selected in the unit control by a Carrier service • to clean the hydronic circuit before charging water representant.
-
Page 12: Electrical Connections And Refrigerant Charge
Operation of the unit on improper line voltage constitutes abuse and is methods which reduce leaks and losses to a minimum not covered by the Carrier warranty. • Leaks must be repaired immediately. IMPORTANT: •... -
Page 13: Start-Up
- Ensure that the power supply corresponds to the applicable In case of use other than the manufacturer configuration, Carrier Service standards. must be asked for permission to change the Pro-Dialog + system - Make sure that compressors float freely on the mounting springs. -
Page 14: Operating Limits
61 AF Operating limits These units have been designed to operate within the following limits: This tank should be equipped with baffles to allow mixing of the fluid (water or brine). Please refer to the examples below. 61AF Minimum Maximum Plate heat Exchanger Entering water temperature at start-up °C... -
Page 15: General Maintenance, Maintenance And Final Recommendations
- Use only Carrier Original Spare Parts when repair is required. Always as well as the drain valve on the plate-type exchanger, which must make sure the spare parts are installed correctly. Always install the be installed on the hydraulic circuit. -
Page 16: Troubleshooting
61 AF Troubleshooting A list of possible faults, as well as the probable cause and suggested solutions is shown as follows. In the event of a unit malfunction it is recommended to disconnect the power supply and ascertain the cause. SYMPTOMS CAUSE REMEDY... - Page 18 Order No.: 10003, 07.2017. Supersedes order No.: 10003, 01.2017. Manufacturer: CARRIER SCS, MontluelFrance. The manufacturer reserves the right to change the specification without prior notice. Printed in the European Union.
