- Page 1 Issued on: 15. Jan. 2016 Cal. VD56C ψ 29. 50 mm 3. 97 mm Item Version No. Specification - 1 Version 1 Version 1 Specification - 2 Version 1 Appearance Version 1 Casing Version 1 Hand Fitting Version 1 Hand Setting Stem...
- Page 2 MOVEMENT SPECIFICATION - 1 CAL.VD56C 12 3 / 4 Ligne Quartz Movement Three Hands with 4 Eyes ( Minute, Second, 1 / 10 Second Chronograph & 24H Indicator ) 1. MOVEMENT DIMENSIONS · Outside diameter ψ29.50mm x 26.00mm (12H~6H) (3H~9H) ·...
- Page 3 Movement Specification - 2 CAL. VD56C OPERATION 3 step motors ( 3 hands, 1 / 10 sec. chrono. maximum to 60 minutes ) Chronograph 1/10 second hand (This chronograph hand moves for the first minute which indicates the measurement time in 1/10 unit)
- Page 6 中心柱位 & " ¨ & " ¡ ¢ £ ¡ ¤ ¥ ¦ § £ 高針 一般針高 ¨ © © " © © 與機芯平面之最大高度 & © 機芯總高度...
- Page 8 一般針高 ¡ ¢ £ ¤ 高針 ¡ ¢ £ ¥ 高針 一般針高 ¡ ¢ £ ¥ ¡ ¢ £ ¤ 時針輪 ¦ § ¨ © 分針輪 © 秒針輪 § ¨ © 小時針輪 § ¨ © 計時分針輪 " & & 計時秒針輪 "...
- Page 14 ¡ ¡ ¢ £ ¤ ¥ ¦ § ¨ ¨ © ¢ © ¨ 7(&+1,&$/ *8,'( 3$576 &$7$/2*8( &DO9'& $1$/2*8( 48$57= 6,, 3URGXFWV...
-
Page 15: Parts Catalogue / Technical Guide
PARTS CATALOGUE / TECHNICAL GUIDE Cal.VD56C [SPECIFICATION] Version-01 Cal. No. VD56C Item Movement （ Ｄ） （ － ） ( 3H - 9H ) φ Outside diameter φ29.50 mm × 26.00 mm × ― （ Ｄ） （ － ） Movement φ... -
Page 16: Parts Catalogue
Version-01 PARTS CATALOGUE VD56C ⇒ Disassembling procedures Figs. Lubricating : Types of oil Oil quantity ⇒ Moebius A Normal quantity Reassembling procedures Figs. Moebius Ｆ Hour, minute second hands Chronograph minute, second and 1/10 second hands 0012 079 24-hour indicator... - Page 17 Version-01 PARTS CATALOGUE VD56C Battery 0351 178 Winding stem 0012 079 Switch spring screw 0012 079 Switch spring screw 4250 119 Switch spring 0012 079 Train wheel bridge (B) screw 4004 395 0125 331 Circuit block Train wheel bridge (B)
- Page 18 Version-01 PARTS CATALOGUE VD56C 0125 248 Train wheel bridge (A) 0241 177 Fourth wheel and pinion 0701 904 0231 904 Fifth wheel and pinion (A) Third wheel and pinion 4146 890 Step rotor (A) 0261 034 0221 156 Minute wheel and pinion...
-
Page 19: Technical Guide
Version-01 TECHNICAL GUIDE VD56C ・The explanation here is only for the particular point of Cal.VD56C Tweezers 1.REMARKS ON INSTALLING THE BATTERY 1) After the battery is replaced with a new one or after the battery is reinstalled following the repairing procedures,... - Page 20 Version-01 TECHNICAL GUIDE VD56C 1.REMARKS ON INSTALLING THE BATTERY (1) HAND ・How to install the hands Place the movement directly on a flat metal plate or the like and press in the hands. * Install the hour , minute and second hands at the "12"o'clock position.
-
Page 21: Operation
Version-01 OPERATION VD56C DISPLAY AND CROWN / BUTTON OPERATION Minute hand Stopwatch 1/10 second hand (Move in 1/10 second increments) Hour hand Button A In stopwatch function Stopwatch minute hand Start / Stop (Move in minute increments) Time setting Second hand... -
Page 22: Time Setting
Version-01 OPERATION VD56C TIME SETTING *Before setting the time , check that the chronograph measurement is stopped. Crown 1.Pull out the crown when 2.Turn the crown to set the 3.Push the crown back in to the second hand is at... - Page 23 Version-01 OPERATION VD56C (Accumulated elapsed time measurement) A / A ･･･ Ex) Basketball game (Press the buttons in the following order RESTART ・・・ START STOP STOP RESET (Restart of game) (Game over) (Start of game) (Time out) 5 minutes 10 seconds...
- Page 24 English OPERATION MANUAL OF VD5 CHRONOGRAPHS DISPLAY AND CROWN / BUTTON OPERATION VD50 VD51 VD52 VD53 VD54 VD55 VD56 VD57 VD59 VD50 VD51 VD52 VD53 VD54 VD55 VD56 VD57 VD59 Center Hour Hand Hour Hands Center Minute Hand Minute Center Second Hand Second Window Date...
- Page 25 English If either of the stopwatch hands are not in the "0" position , reset them following the procedure below. 1) Pull the crown out to : VD50, VD51, VD52, VD53, VD57 (calibres with date window) : second click Button A VD54, VD55, VD56, VD59 (calibres without date window) : first click 2) Press button A or B to reset all stopwatch hands to "0"...
- Page 26 English Accumulated elapsed time measurement (e.g. basketball game) Button A Button A Button A Button A Button B (START) (STOP) (RESTART) (STOP) (RESET) * Restart and stop of the stopwatch can be repeated as many times as necessary by pressing button A.
- Page 27 German BEDIENUNGSANLEITUNG FÜ R VD5 CHRONOGRAPH ANZEIGE UND KRONE / BEDIENTASTEN FUNKTIONEN VD50 VD51 VD52 VD53 VD54 VD55 VD56 VD57 VD59 VD50 VD51 VD52 VD53 VD54 VD55 VD56 VD57 VD59 Mitte Stundenzeiger Stunde Zeiger Mitte Minutenzeiger Minute Mitte Sekundenzeiger Sekunde Fenster Datum 1.
- Page 28 German EINSTELLUNG DER STOPPUHR-ZEIGER UND STOPPUHRZEIGER-POSITIONEN * Ü berprüfen Sie vor der Zeiteinstellung, ob sich alle Stoppuhrzeiger in der - 1/10 Sekunden (wo vorhanden), Sekunde, Minute - in der "0"-Stellung(12 Uhr) befinden. * Wenn die Stoppuhr im Einsatz ist, dann betätigen Sie die Tasten wie folgt, um eine Rücksetzung durchzuführen, und prüfen Sie anschließ...
- Page 29 German VD54, 55, 56, 59 (Modelle ohne Datum-Fenster) : 1) Ziehen Sie die Krone heraus, sobald sich der Sekundenzeiger in der 12-Uhr Stellung befindet. Stellung befindet. Der Sekundenzeiger hält unverzüglich 2) Bringen Sie die Zeiger in die gewünschte Zeiteinstellung Zeit indem Sie an der Krone drehen.
- Page 30 VD50/VD51/VD52/VD54/VD55/VD56/VD59 - Calibre List Date : 20.10.2016 Reference VD50C11 VD50C117 VD50C1B VD51C1 VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph Product Line Series Series Series Series Function Chrono/Date Chrono/Date Chrono/Date Chrono/Date Appearance Size 12 3/4''' 12 3/4''' 12 3/4''' 12 3/4''' *Category...
- Page 31 VD50/VD51/VD52/VD54/VD55/VD56/VD59 - Calibre List Date : 20.10.2016 Reference VD51C17 VD51C3 VD51C1B VD51C31B VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph Product Line Series Series Series Series Function Chrono/Date Chrono/Date Chrono/Date Chrono/Date Appearance Size 12 3/4''' 12 3/4''' 12 3/4''' 12 3/4''' *Category...
- Page 32 VD50/VD51/VD52/VD54/VD55/VD56/VD59 - Calibre List Date : 20.10.2016 Reference VD51C2 VD51C27 VD51C2B VD51C38 VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph Product Line Series Series Series Series Function Chrono/Date Chrono/Date Chrono/Date Chrono/Date Appearance Size 12 3/4''' 12 3/4''' 12 3/4''' 12 3/4''' *Category...
- Page 33 VD50/VD51/VD52/VD54/VD55/VD56/VD59 - Calibre List Date : 20.10.2016 Reference VD51C387 VD51C38B7 VD52C12 VD52C327 VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph Product Line Series Series Series Series Function Chrono/Date Chrono/Date Chrono/Date Chrono/Date Appearance Size 12 3/4''' 12 3/4''' 12 3/4''' 12 3/4''' *Category...
- Page 34 VD50/VD51/VD52/VD54/VD55/VD56/VD59 - Calibre List Date : 20.10.2016 Reference VD54C1 VD54C3 VD55C1 VD55C3 VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph Product Line Series Series Series Series Function Chrono/No Date Chrono/No Date Chrono/No Date Chrono/No Date Appearance Size 12 3/4''' 12 3/4'''...
- Page 35 VD50/VD51/VD52/VD54/VD55/VD56/VD59 - Calibre List Date : 20.10.2016 Reference VD56C1 VD56C3 VD59C1 VD5 Basic Chronograph VD5 Basic Chronograph VD5 Basic Chronograph Product Line Series Series Series Function Chrono/No Date Chrono/No Date Chrono/No Date Appearance Size 12 3/4''' 12 3/4''' 12 3/4''' *Category Spec Sheet Dial Drawing No.
