Contents For Your Safety ............9 General Safety ..............9 FCC Compliance............10 Distraction ..............13 Driving ..............13 Operating Machinery ..........13 Product Handling ............13 General Statement on Handling and Use ....13 ...
Page 4
General Statement on Interface ....... 18 Pacemakers ............. 18 Hearing Aids ............18 Medical Devices ............19 Hospitals ..............19 Aircraft ..............19 Interference in Cars ..........19 Explosive Environments ..........20 ...
Page 5
Phone Calls ............29 Making Calls ..............29 Calling from the Phone ..........30 Calling from Your Contacts ........30 Calling from Your Call History ........30 Calling from a Text Message ........30 ...
Page 6
USB tethering & portable hotspot ........36 Enabling USB tethering ..........36 Disabling USB tethering ........... 37 Enabling the Wi-Fi Hotspot ........37 Disabling the Wi-Fi Hotspot ........38 Browsing the Internet ..........38 ...
Page 7
Setting Date and Time ........... 45 Display Settings ............. 45 Sound Settings............... 45 Language Settings ............46 Mobile Network Services ..........46 Disabling Data Services ........... 46 Switching Network Modes ........46 Switching Networks ..........
For Your Safety General Safety Don’t make or receive handheld calls while Don’t use at petrol driving. And never text stations. while driving. Keep your phone at least 15 mm away from Your phone may produce your ear or body while a bright or flashing light.
Switch off when near Only use approved explosive materials or accessories. liquids. Don’t rely on your phone for emergency communications. FCC Compliance This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 11
is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Page 12
phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.
exposure guidelines. If you do not use a body-worn accessory and are not holding the phone at the ear, position the handset a minimum of 1.0 cm from your body when the phone is switched on. Distraction Driving Full attention must be given to driving at all times in order to reduce the risk of an accident.
Page 14
measures designed to protect users and their environment. Always treat your phone and its accessories with care and keep it in a clean and dust-free place. Do not expose your phone or its accessories to open flames or lit tobacco products. ...
Small Children Do not leave your phone and its accessories within the reach of small children or allow them to play with it. They could hurt themselves or others, or could accidentally damage the phone. Your phone contains small parts with sharp edges that may cause an injury or may become detached and create a choking hazard.
bag deployment area. Store the phone safely before driving your vehicle. Seizures/ Blackouts The phone can produce a bright or flashing light. Repetitive Motion Injuries To minimize the risk of RSI when texting or playing games with your phone: Do not grip the phone too tightly.
devices. Phone Heating Your phone may become warm during charging and during normal use. Electrical Safety Accessories Use only approved accessories. Do not connect with incompatible products or accessories. Take care not to touch or allow metal objects, such as coins or key rings, to contact or short-circuit in the battery terminals.
centre. Interference General Statement on Interface Care must be taken when using the phone in close proximity to personal medical devices, such as pacemakers and hearing aids. Pacemakers Pacemaker manufacturers recommend that a minimum separation of 15 cm be maintained between a mobile phone and a pacemaker to avoid potential interference with the pacemaker.
Medical Devices Please consult your doctor and the device manufacturer to determine if operation of your phone may interfere with the operation of your medical device. Hospitals Switch off your wireless device when requested to do so in hospitals, clinics or health care facilities. These requests are designed to prevent possible interference with sensitive medical equipment.
Explosive Environments Petrol Stations and Explosive Atmospheres In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices such as your phone or other radio equipment. Areas with potentially explosive atmospheres include fuelling areas, below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders.
Function Power Key Hold to turn on or off Silent or Airplane mode, or to power off. Press to switch your phone to Sleep mode. Press to wake up your phone. Home Key Press to return to the Home Screen from any application or screen.
Page 23
2. Hold the SIM card with the cut corner oriented as shown and slip it into the card holder. 3. Follow the OPEN arrow to push the metal slot, and flip it up. Insert the memory card into the metal slot with the metal contacts facing down until it clicks to the right position.
4. Insert the battery by aligning the gold contacts on the battery with the gold contacts in the battery compartment. Gently push down on the battery until it clicks into place. 5. Press the cover gently back into place until you hear a click.
force the connector into the charger jack. 2. Connect the charger to a standard AC wall outlet. 3. Disconnect the charger when the battery is fully charged. Switching Your Phone On/Off Make sure the SIM card is in your device and the battery is charged.
can start sleep mode by the following method. Press Power Key to switch to Sleep Mode. Waking Up Your Phone 1. Press Power Key to activate your screen display. 2. Drag the arrowhead icon to the top. NOTE: If you have set an unlock pattern, PIN or password for your phone (see chapter Sorting out Your Phone Settings –...
landscape orientation simply by holding it upright or turning it on its side. Not all screens are viewable in landscape. Home Screen In the Home screen, besides the shortcut icon is displayed, you can also set your own wallpaper, add the widgets or application shortcuts you need, or remove them as you like.
release your finger. 4. Or you can Tap Menu Key and select Add to add the items you want to use. Removing Items from Your Home Screen 1. Press Home Key to return to the Home Screen. 2. Tap and hold the item you want to delete until the icon appears on the screen.
Bluetooth icon USB debugging connected New Wi-Fi network detected Data Conn off Using the Notification Panel Flick the status bar downwards from across the top of the screen to open the Notification Panel, where you can see your calendar events, new Messaging, and current settings –...
Calling from the Phone 1. Press Home key>tap > Phone or tap on the Home Screen. 2. Enter the phone number using the on-screen keypad. to delete wrong digits. 3. Tap the dial icon. TIPS: To make international calls, hold to enter the “+”.
1. Press Home key> tap > Messaging. 2. Tap the conversation and then the message that contains the phone number you need. 3. Tap the message, the phone will list the numbers. 4. Tap the number you want to dial the number . Receiving Calls Answering a Call Press Answer to answer the call (In addition to the locked...
appear on the status bar. To turn your microphone back on, tap Mute again. Turning the Speakerphone On/Off Tap Speaker during a call to turn the speakerphone on. Tap Speaker again to turn off the speakerphone. Ending a Call to finish a call. Contacts You can add contacts on your phone and synchronize them with the contacts in your Google account or other accounts that...
Searching for a Contact 1. Tap on the top of the Contacts Screen. 2. Input the contact name you want to search for. The contacts matched will be listed. Messaging Your SMS (text message) and MMS (multimedia messaging service) are combined into one menu in Home Key > >...
4. Tap Type to compose and type your message. Tap Menu Key to insert quick text, smiley, or contact. If you are sending an MMS, tap Menu Key to add a subject, or attach pictures, videos, audio, or slideshows.
Getting Connected to the Internet Your phone’s impressive networking capabilities allow you to access the Internet or your corporate network with ease. You can use default connection settings to connect to the Internet via your mobile network, or Wi-Fi. The network connection can be enabled /disabled manually. Just select >...
2. Tick the Wi-Fi box to turn it on. Connecting to a Wi-Fi Network 1. Press Home key>tap > Settings > Wireless & networks > Wi-Fi settings. The Wi-Fi access points, or “hotspots”, that your phone has detected are displayed with their names and security settings.
Press on the phone Home Key >tap Menu Key > Settings > Wireless & networks > Tethering & portable hotspot and tick the USB tethering check box. A new network connection will be created on your PC. Disabling USB tethering Press Home Key >...
and connect to it. Disabling the Wi-Fi Hotspot Press Home Key >tap Menu Key > Settings > Wireless & networks > Tethering & portable hotspot and clear the Portable Wi-Fi hotspot check box. Browsing the Internet You can use your phone to get on the Internet via a network or Wi-Fi connection.
add bookmarks, downloads, or configure browser settings etc.). Using Bookmarks If you know the Web address, you can manually add bookmarks. To bookmark a web page, open it and tap Menu Key > Bookmarks. Then tap Add bookmark. Give the bookmark a name and save it.
Changing Browser Settings Tap Menu Key > More > Settings from a browser window to change browser settings. Bluetooth Bluetooth is a short-range wireless communication technology. Phones or other devices with Bluetooth capabilities can exchange information wirelessly within a distance of about 10 meters.
Making the Most of Multimedia Taking Pictures with Your Camera Your phone has camera function. Open it by pressing Home Key > tap > Camera. to take a shot. To view it, just tap the picture in the right corner of the screen. Or select Menu Key > Gallery to view all your pictures.
to them, and save them on your phone. Note that the quality of the radio broadcast depends on the coverage of the radio station in your area. The wired headset works as an antenna, so always connect the headset when using the radio. ...
Making Voice Memos Sound Recorder enables you to record your voice memos. You need a microSD card to use it. 1. Press Home Key > tap > Sound Recorder. 2. Tap to start recording. 3. Tap to stop recording. 4. Tap to play back the voice recording.
you sign in to your Google account. Depending on your synchronization settings, the Gmail on your phone can be automatically synchronized with your Gmail account on the web. This is how to enter Gmail: Open Gmail by Pressing Home Key > tap >...
Sorting out Your Phone Settings Setting Date and Time 1. Press Home key> tap > Settings > Date & time. 2. Clear the Automatic check box if you want to set the time and date by yourself. 3. Set date, time and change the other options. Display Settings By tapping Menu key >...
Language Settings You can change the language of your phone system in two simple steps. 1. Press Home key>tap > Settings > Language & keyboard > Select language. 2. Select a language from the list given. Mobile Network Services Press Home key> tap >...
Switching Networks 1. Press Home key> tap > Settings > Wireless & networks > Mobile networks > Network operators. The phone automatically searches for all available networks. 2. Tap a network to register manually, or tap Select automatically. Setting Access Point Names To connect to the Internet you can use the default Access Point Names (APN).
pattern. 4. Touch Continue. 5. Redraw your pattern to confirm. Unlocking the Screen with Your Pattern 1. Press Power Key to wake up the screen. 2. Draw the pattern you set to unlock the screen. If you make a mistake, your phone will ask you to try again. Protecting Your Phone with a PIN or Password Creating a PIN or Password...
can disable it. 1. Press Home key>tap > Settings > Security > Change screen lock. 2. Draw the screen unlock pattern or enter your PIN/ password you have created. 3. Tap None. Protecting Your SIM Card with a PIN Every SIM card comes with a PIN. The initial PIN is provided by your mobile phone carrier.
2. Make sure you already tick the Lock SIM card check box. 3. Tap Change SIM PIN. Setting up Credential Storage This lets you select applications to access secure certificates and other credentials. Enabling Secure Credentials 1. Press Home key>tap >...
Erase SD card: Erase all data on the microSD card. Privacy: Reset to Factory Settings Press Home key> tap > Settings > Privacy > Factory data reset > Reset phone > Erase everything. WARNING: All your personal information and downloaded applications on your phone will be erased after the resetting.
application and follow it to complete the setup. NOTE: please take your handset as the standard. Removing an Application 1. Press Home key> tap > Settings > Applications > Manage applications. 2. Select the application you want to delete. 3. Tap Uninstall and OK to confirm. Moving an Application You can move the applications downloaded or installed on your phone to the memory card when the phone memory is...
by pressing Home Key >tap > Settings > Voice input & output. NOTE: You need to download voice data in order to use the text-to-speech function. Accessibility You can configure accessibility options for accessibility-related applications by pressing Home Key > tap >...
Page 54
Calculator You can use the phone directly perform simple mathematical calculations. 1. Press Home Key > Tap > Calculator. 2. Click the button corresponding with the calculator display, perform basic arithmetic. TIPS: Tap Menu Key > Advanced panel to use scientific calculation.
