Warner Howard EI1100W Instructions

EI1100W INSTRUCTIONS
SERVICING
Periodic cleaning of the inside of the dryer is recommended to prevent a build-up of dirt and fibres.
With the power disconnected and the cover removed a soft brush can be used to dislodge any debris.
An inlet filter is fitted to prevent debris from entering the motor. This filter can be removed and
replaced by pulling upward as shown. (Fig.7) Replacement is the reversal of removal.
Fig.7
TABLE 1
Recommended mounting heights from floor to dryer bottom surface (mm)
Men's Washroom
Women's Washroom
Children's Washroom (Aged 4-7)
Children's Washroom (Aged 7-10)
Children's Washroom (Aged 10-14)
Children's Washroom (Aged 14-17)
Disabled Mounting Height
051309-A
For further information please contact us on :
0370 850 4352 | sales@warnerhoward.co.uk
Inlet Filter
1168
1118
812
914
1016
1118
1016
| www.warnerhoward.co.uk
WARNER HOWARD EL1100W
DESCRIPTION:
High speed warm air hand dryer powered by universal brush motor, delivering 1100 Watts
of drying power. This hand dryer runs on 230 Volts ac electrical supply. An infrared sensor
is used to automatically turn the dryer on and off. This model is intended for use in
commercial, industrial, office and public facility environments.
SPECIFICATION:
Rating: 1100W at 230V ac 50Hz
Construction: ABS
Dimensions (mm): 221x268x149
Weight: 2.3 Kg
IMPORTANT:
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Warner Howard c/o PHS Group, Claymore, Tame Valley Industrial Estate, Tamworth, Staffs. B775DQ Tel: 08708504352 Fax: 08708504354
www.warnerhoward.co.uk
