PCB Piezotronics ICP 209C02 Installation And Operating Manual page 16

Model Number
209C02
Performance
Sensitivity(± 15 %)
Measurement Range(Compression)
Maximum Static Force(Compression)
Broadband Resolution(1 to 10,000 Hz)
Low Frequency Response(-5 %)
Upper Frequency Limit
Environmental
Temperature Range
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(1 Hz)
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1000 Hz)
Output Polarity(Compression)
Physical
Stiffness
Size (Hex x Height)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Mounting Thread
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® FORCE SENSOR
ENGLISH SI
2200 mV/lb 494,604 mV/kN
2.2 lb 0.00979 kN
11 lb 0.0489 kN
0.00002 lb-rms 0.00009 N-rms
0.05 Hz 0.05 Hz
100,000 Hz 100,000 Hz
-65 to +250 °F -54 to +121 °C
≤ 0.05 %/°F ≤ 0.09 %/°C
≥ 10 sec ≥ 10 sec
18 to 30 VDC 18 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 12 VDC 8 to 12 VDC
0.0000123 lb/√Hz 0.0000548 N/√Hz
0.0000009 lb/√Hz 0.0000042 N√Hz
0.0000004 lb/√Hz 0.0000017 N/√Hz
0.0000001 lb/√Hz 0.0000003 N/√Hz
Positive Positive
2 lb/µin 0.35 kN/µm
0.375 in x 0.610 in 9.53 mm x 15.49 mm
0.28 oz 8 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
Side Side
10-32 Female No Metric Equivalent
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[1]
M
- Metric Mount
[2]
Supplied Accessory : Model M081A05 Mounting Stud 10-32 to M6 x 0.75 x 0.27" long BeCu
[3]
(H900), no shoulder (1)
N
- Negative Output Polarity
Output Polarity(Compression)
W
- Water Resistant Cable
Electrical Connector
Electrical Connection Position
[1]
[1]
NOTES:
[1]
[1]Typical.
[1]
[2]Calculated from discharge time constant.
[3]Estimated using rigid body dynamics calculations.
[4]See PCB Declaration of Conformance PS023 for details.
[1]
SUPPLIED ACCESSORIES:
Model 081A05 Mounting stud, 10-32 to 10-32 x 0.27" long, BeCu (H900), no shoulder (1)
Model 084A38 Thermal boot (for Series 209) (1)
Entered: LK Engineer: MJK
Date: 3/29/2016 Date: 3/29/2016
3425 Walden Avenue, Depew, NY 14043
Revision: J
ECN #: 45224
Negative Negative
Sealed Cable Sealed Cable
Side
Sales: KWW Approved: APB Spec Number:
Date: 3/29/2016 Date: 3/29/2016
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
Side
6359
