Summary of Contents for Eltek R7121-L1
Page 1
Eltek R7121-L1 Eltek R7141-L1 Eltek R7111-L1 Analogue Telephone Adapter User Manual Note: default value are different based on different firmware version. Default Login Detail WAN IP Address: DHCP LAN IP Address: http: 192.168.1.1 User Name: admin Password: admin...
TART 2.4 W IZARD ETUP NETWORK SETTING ........................21 3.1 WAN I NTERFACE 3.2 LAN I NTERFACE 3.3 NAT VOIP SETTING (R7121-L1/R7141-L1/R7111-L1) ................30 4.1 SIP S ETTING 4.2 P HONE 4.3 P HONE 4.4 PSTN L (R7141-L1 ONLY SECURITY ............................47 5.1 F...
Page 3
MAINTENANCE ..........................50 6.1 S YSTEM 6.2 T OOLS 6.3 L INFORMATION ..........................58 IVR COMMAND ..........................59 APPENDIX ............................59 A - FAQ L B - S CENARIO PPLICATION AMPLES...
0.4 Safety Instructions The most careful attention has been devoted to quality standards in the manufacture of the Analogue Telephone Adapter (R7121-L1/R7141-L1). Safety is a major factor in the design of every set. But, safety is your responsibility too. Use only the required power voltage. Power Input: AC 110V/220V, 1A, 50-60Hz To reduce the risk of electric shock, do not disassemble this product.
Page 5
Note Repair or replacement, as provided under this warranty, is the exclusive remedy of the purchaser. This warranty is in lieu of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular use or purpose. We shall in no event be held liable for indirect or consequential damages of any kind of character to the purchaser.
R7121-L1/R7141-L1/R7111-L1 (Analogue Telephone Adapter) 1.1 Overview An Analogue Telephone Adapter, or R7121-L1/R7141-L1, is a device that allows one to connect a normal PSTN telephone to the Internet in order to make or place telephone calls. R7121-L1/R7141-L1 provides a direct analog interface for PSTN, PBX, fax machines, analog telephones, and other devices that require an analog port.
1.5 Front Panel LED Indicators & Rear Panels R7121-L1 ------------------------------------------------------------------------------------ State Description ------------------------------------------------------------------------------------ 1. POWER R7121-L1 is power ON R7121-L1 is power Off ------------------------------------------------------------------------------------- 2. LAN port LAN is connected successfully Flashing Data is transmitting Ethernet not connected to PC ------------------------------------------------------------------------------------- 3.
Page 8
------------------------------------------------------------------------------------- R7141-L1 ------------------------------------------------------------------------------------ State Description ------------------------------------------------------------------------------------ 1. POWER R7141-L1 is power ON R7141-L1 is power Off ------------------------------------------------------------------------------------- 2. LAN port LAN is connected successfully Flashing Data is transmitting Ethernet not connected to PC ------------------------------------------------------------------------------------- 3. WAN port R7141-L1network connection established Flashing Data traffic on cable network Waiting for network connection...
2. LAN port LAN is connected successfully Flashing Data is transmitting Ethernet not connected to PC ------------------------------------------------------------------------------------- 3. WAN port R7111-L1 network connection established Flashing Data traffic on cable network Waiting for network connection ------------------------------------------------------------------------------------- 4. FXS (Phone) Telephone Set is On-Hook Flashing Ring Indication Telephone Set is Off-Hook...
Page 10
Peer to Peer Call by Dial Plan Different Country Tone Table(Region) G.168 Echo cancelation Hook-Flash Timing Call Transfer Pulse Dial Detection Auto Dial Off-Hook Alarm Configuration & Management: Web-based Graphical User Interface Remote management over the IP Network Web Base firmware upgrade Backup and Restore Configuration file Different Account Login Back to Factory Default...
Please check enclosed product and its accessories before installation. (Refer to the item number). These contents are from pre-released product. The contents for the final product might change a little bit. Package packet contents: ATA (R7121-L1/ R7141-L1/R7111-L1) RJ-45 AC Power Adapter (1A) CD-Rom(User manual) 2.2Hardware Installation Port Description: DEMO Model R7121-L1...
Page 12
Port Description: DEMO Model R7141-L1 Port Description: DEMO Model R7111-L1 Item Port Description AC power(DC in 12V) A power supply cable is inserted RES(Reset button) Push this button until 3 seconds, and ATA will be set to factory default configuration. WAN(Wide Area Network) Connect to the network with an Ethernet cable.
Page 13
2 Connect the other end of the Ethernet cable to your PC’s installed network interface card (NIC). Connecting to an External Ethernet Hub or Switch: 1 Connect the Ethernet cable (with RJ-45 connector) to WAN port. 2. Connect the other end of the Ethernet cable to DSL/Cable modem or the external Ethernet hub or switch. R7121-L1:...
For LAN: IP: 192.168.1.1 Subnet mask: 255.255.255.0 How to configure R7121-L1/R7141-L1/R7111-L1? Configure your PC or NB to the same subnet with R7121-L1/R7141-L1/R7111-L1. Use web browser (IE/Firefox) link to url: http://192.168.1.1 (If you connect to LAN port, link to url: http://192.168.1.1...
Page 16
Confirmed Password Configure SIP registrar server and proxy server, use web configuration: “SIP Settings” -> “Server Setting” a. Registrar Server Address b. Outbound Proxy Address Make sure R7121-L1/R7141-L1/R7111-L1 has already registered to your proxy, and then you can make a call...
2.4 Wizard Setup Wizard for Quick Setup ATA after finishing the authentication, the Main menu will display 2 parts of configuration, please click “Connection wizard” to enter quick start: Step 1. Connection wizard Step 2. Welcome to the VOIP ATA Connection Wizard Step 3.
Page 18
Time Zone Select : Choose your time zone NTP Server : Select NTP server. Step 4. WAN Port Type Setup: For most users, Internet access is the primary application. The ATA support the WAN interface for Internet access and remote access. The following sections will explain more details of WAN Port Internet access and broadband access setup.
Page 19
Some ISPs provide DSL-based service and use PPPoE to establish communication link with end-users. If you are connected to the Internet through a DSL line, check with your ISP to see if they use PPPoE. If they do, you need to select this item. PPPoE User Name: Enter User Name provided by your ISP PPPoE Password: Enter Password provided by your ISP.
Page 20
□SIP Number: you need to input the User Name get from your ISP. □SIP Server add: you need to input the Proxy add get from your ISP. □SIP Server Domain: you need to input the SIP Domain get from your ISP. □User Name: you need to input the Register User Name get from your ISP.
ISP and often times referred to as "public settings". Please select the appropriate option for your specific ISP. For most users, Internet access is the primary application. R7121-L1/R7141-L1/R7111-L1 supports the WAN interface for internet access and remote access. The following sections will explain more details of WAN Port Internet access and broadband access setup.
Page 23
Static IP If you are a leased line user with a fixed IP address, enter in the IP address, subnet mask, gateway address, and DNS (domain name server) address(es) provided to you by your ISP. Each IP address entered in the fields must be in the appropriate IP form, which are four IP octets separated by a dot (x.x.x.x). The Router will not accept the IP address if it is not in this format.
Page 24
DHCP client Dynamic Host Configuration Protocol (DHCP), Dynamic IP (Get WAN IP Address automatically). If you are connected to the Internet through a Cable modem line, then a dynamic IP will be assigned. Note: WAN port gets the IP Address, Subnet Mask and default gateway IP address automatically, if DHCP client is successful.
Page 25
PPPoE Point-to-Point Protocol over Ethernet (PPPoE). Some ISPs provide DSL-based services and use PPPoE to establish communication link with end-users. If you are connected to the Internet through a DSL line, check with your ISP to see if they use PPPoE. If they do, you need to make sure the following items, PPPoE User name: Enter username provided by your ISP.
Page 26
PPTP with WAN (Static、DHCP、PPPoE) Some ISPs provide DSL-based service and use PPTP with Static, DHCP or PPPoE to establish communication link with end-users. ■PPTP Server IP Address: check with your VPN /PPTP Server provider ■PPTP User Name: PPTP Dial-in account ■PPTP Password: PPTP Dial-in Password ■PPTP MTU Size ■Request MPPE Encryption...
3.2 LAN Interface These are the IP settings of the LAN (Local Area Network) interface for the device. These settings may be referred to as "private settings". You may change the LAN IP address if needed. The LAN IP address is private to your internal network and cannot be seen on the Internet.
MAC and IP address which are active now. When you enable the DHCP server, □Assigned DHCP IP Address: Enter the starting IP address for the DHCP server’s IP assignment and the ending IP address for the DHCP server’s IP assignment. □DHCP IP Lease Time - Assign the length of time for the IP lease, default setting is 86400 seconds.
Page 29
computer s, you can choose to simply place one of the computers between the Internet connection and the firewall. If you have a computer that cannot run Internet applications properly from behind the device, then you can allow the computer to have unrestricted Internet access. Enter the IP address of that computer as a DMZ host with unrestricted Internet access.
VOIP Setting (R7121-L1/R7141-L1/R7111-L1) SIP is a request-response protocol, dealing with requests from clients and responses from servers. Participants are identified by SIP URLs. Requests can be sent through any transport protocol. SIP determines the end system to be used for the session, the communication media and media parameters, and the called party's desire to engage in the communication.
4.1 SIP Setting Sip setting In SIP Settings you can setup the Service Domain, Port Settings, Codec Settings, Codec ID Settings, RTP Setting, RPort Setting and Other Settings. If the VoIP service is provided by ISP, you need to setup the related information correctly then you can register to the SIP Proxy Server correctly.
Page 33
You can see the Register Status in the Status item. If the item shows “Registered”, then your VoIP Phone is registered to the ISP, you can make a phone call directly. If you have more than one SIP account, you can following the steps to register to the other ISP. When you finished the setting, please click the Apply button.
Page 34
SIP Advance □SIP Port Number - Assign the SIP port number of R7141-L1/R7121-L1/R7111-L1., default setting is 5060. □Media Port Start - The starting range of port for RTP . Port number for initial of sending RTP packet., default setting is 9000.
Page 35
Forwarding Mode You can setup the phone number you want to forward in this page. There are three type of Forward mode. You can setup Immediate Forward, Busy Forward, and No Answer Forward by click the icon. Immediate Forward: All incoming call will forward to the number you entered. You can input the phone number.
Page 36
FAX Option G.711 Fax Pass through: Select this if the R7141-L1/R7121-L1/R7111-L1 should use G.711 to send fax messages. The peer devices must also use G.711. T.38 Fax Relay: Select this if the R7141-L1/R7121-L1/R7111-L1 should send fax messages as UDP packets through IP networks.
Page 37
Codec A CODEC is an algorithm for taking voice or video and compressing the information. This type of codec combines analog-to-digital conversion and digital-to-analog conversion functions in a single chip. The Codec is used to compress the voice signal into data packets. Each Codec has different bandwidth requirement.
Page 38
VLAN Setting: You can set the VLAN setting in this page. There are two parts in this page. First one is to set the packets related to the R7141-L1, and the second one is if you use the VLAN setting in the NAT Mode. There are two kind of destination packets will come from the R7141-L1’s WAN port, one kind of packets will go to the R7141-L1, the other will go through the LAN port to the PC.
Advanced Setup: Jitter Buffer Control In R7141-L1/R7121-L1 VoIP device, The jitter buffer control is a shared data area where voice packets can be stored , collected , and sent to the voice shared Buffer in evenly spaced intervals. modify in packets arrival time, called jitter, can occur because of network congestion, timing drift, or route changes.
Page 40
□Max delay (ms): Select Max delay Buffer time.( 130ms – 300ms) □Optimization factor: Controls quickly the length of the Jitter Buffer is increased when Voice RTP on the network. .Default is 7 □Voice Active Detector - It is used in speech encoding software to determine if the voice being encoded is human speech or background noise Voice Activity Detection If this function is enabled, when silence is occurred for a period of time, no data will be sent across the...
Page 41
As Callee Answer - Check this box to generate line polarity reversal while the remote user picks up the phone call. As Callee On-Hook - Check this box to generate line polarity reversal while the remote user hangs off the phone call. Caller ID Mode: FSK Date &...
Page 42
Hook-Flash Timing Minimum on-hook time default =30 ms Maximum on-hook time default =2000 ms Hot Line This service allows you to make a call to a pre-programmed number by only lifting the handset. Common Dialing Parameter □Auto Dial Time- If no other number is being dialed within this interval, the R7141-L1 will terminate this call.
Page 43
Region Region Setting - Adjust the tone frequency according to each country. Select a country from the pull-down menu.
4.3 Phone Book Speed Dial Speed Dial lets you define a button or a set of buttons to link to a specific number defined in Speed Dial list. □Position - Select the speed dial shortcut to use from 0 to 9. □Name–Phone number note.
Page 45
□“Prefix Number” is the digits that will be added to the beginning of the dialed number. □“Destination IP/ URI” is the IP address / Domain Name of the destination R7121-L1/R7141-L1/R7111-L1 that owns this phone number. □“Destination SIP Port” is port of the destination R7121-L1/R7141-L1/R7111-L1 use.(Default is 5060) Call By PSTN: Priority to dial from PSTN...
4.4 PSTN Line (R7141-L1 only) Call out by PSTN line □ call through PSTN line: set up the prefix digit function key. For example, the PSTN line Prefix Number is **. It means that the analog phone connect to FXS port can press **, then, get a dial tone of PSTN port to dial destination number via PSTN port.
Security 5.1 Firewall IP Filtering Mac Filtering Port Filtering Content Filtering IP Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network. □...
Page 48
□MAC Enable/Disable –from your local network to Internet through the Gateway MAC filter function,default setting is disable. Port Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network Content Filtering URL filter is used to deny LAN users from accessing the internet.
Page 49
URL filter allows you to block sites based on a black list and white list. Sites matching the black list but not matching the white list will be automatically blocked and closed. □Enable - Enable/Disable the URL filter function, default setting is Disable. □Client IP - This is the Clinet IP is LAN address.
Page 50
Maintenance System Account setting Time Zone Auto Provision DDNS Tool Configuration Upgrade Firmware Ping Test Restart System Log...
Page 51
6.1 System General This page is used to set the Router or Bridge mode. And the account to access the web server of Access Point. Empty user name and password will disable the protection. Note: If select Bridge mode, the system will disable the firewall and NAT automatically. If select Bridge mode, please set the Management IP Address Time Setting You can maintain the system time by synchronizing with a public time server over the Internet.
Page 52
Without DDNS, the users should use the WAN IP to reach internal server. It is inconvenient for the users if this IP is dynamic. With DDNS supported, you apply a DNS name (e.g., www.R7121-L1.com) for your server (e.g., Web server) from a DDNS server. The outside users can always access the web server using the www.ata.com regardless of the WAN IP.
Page 53
□Enable - Enable/Disable the DDNS service, default setting is Disable. □DDNS Server Type - The R7141-L1 support two types of DDNS, DynDns.org or TZO.net □Domain Name - The hostname which you register in DynDns.org or TZO.net website. □DDNS Username - The username which you register in DynDns.org or TZO.net website. □DDNS Password - The password which you register in DynDns.org or TZO.net website.
Page 54
6.2 Tools Configuration This page allows you save current settings to a file or reload the settings from the file which was saved previously. Besides, you could reset the current configuration to factory default. Upgrade Firmware This page allows you upgrade the Access Point firmware to new version. Please note, do not power off the device during the upload because it may crash the system.
Page 55
Restart function you can restart theR7121-L1/R7141-L1/R7111-L1 device. If you want to restart the R7121-L1/R7141-L1, you can just click the Reboot button, than the VoIP Phone will automatically. If for any reason the device is not responding correctly, you may want to restart the...
Page 56
6.3 Log If you want to Log the R7141-L1/R7121-L1/R7111-L1 system log , you can enable log and enable system all , The system will record system log .
Page 57
Logout If you need to logout administrator right for web-access, please click the Logout link. The web system management interface will auto-logout with 1800 sec default value.
Page 58
Information System Information System Status This page shows the current status and some basic settings of the device. Click System Information to display system status, The Device Information has WAN type, and LAN type, Phone Status, more Status…etc. This page displays the current information for the device. It will display the LAN、 WAN and system firmware information.
Page 59
Voice firmware Version Appendix A - FAQ List 1. What is the default administrator password to login to the R7121-L1/R7141-L1/R7111-L1? How to Login? A: By default, default username is “admin”, default password is also “admin” to login to the router. For security, you should modify the password to protect your gateway against hacker attacks.
Page 60
A: Please check your PC connects the R7121-L1/R7141-L1/R7111-L1 Lan port or PC and R7121-L1/R7141-L1/R7111-L1 with the same Subnet. If you PC aren’t at the same Subnet, you can’t Login the R7141-L1 Web interface. Else you let your R7121-L1/R7141-L1/R7111-L1 on Public Internet (Public IP address).
Page 62
FCC ID: 2AB3KR7121-L1 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
