INSTRUCTION MANUAL
Autofill Wallmount Waterboilers
(Filtration & Non-Filtration models)
These instructions cover the following Burco models:
069801
069818
Burco Autofill Filtration: 5L –
, 10L -
Burco Autofill (without Filter): 3L –
069924
069931
, 7.5L -
Burco is part of:
Glen Dimplex Heating & Ventilation
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF.
Aftersales Tel: 0344 879 3470
www.burco.co.uk
Please keep these instructions in a safe place.
08/54071/0 (Jan 19)
1
Advertisement
Table of Contents
Related Manuals for Burco 069818
Summary of Contents for Burco 069818
- Page 1 INSTRUCTION MANUAL Autofill Wallmount Waterboilers (Filtration & Non-Filtration models) These instructions cover the following Burco models: 069801 069818 Burco Autofill Filtration: 5L – , 10L - Burco Autofill (without Filter): 3L – 069924 069931 , 7.5L - Burco is part of: Glen Dimplex Heating &...
-
Page 2: Table Of Contents
Page About my product (please complete the details below) Warning and Precautions Introduction Warranty Information Accessories Kit Technical Data Installing Burco water boiler Operating Instructions 9-12 Descaling & Cleaning advice and information 13-14 Changing Water Filter Troubleshooting Spare / Replacement Part information Frequently asked questions (FAQ’s) -
Page 3: Warning And Precautions
Warnings and Precautions WARNING. THIS SYMBOL MEANS THERE IS A RISK OF PERSONAL INJURY. IMPORTANT. THIS SYMBOL MEANS THERE IS A RISK OF DAMAGING THE APPLIANCE. THIS APPLIANCE MUST BE INSTALLED, COMMISSIONED AND SERVICED BY A QUALIFIED PERSON IN ACCORDANCE WITH THE NATIONAL AND LOCAL REGULATIONS IN FORCE IN THE COUNTRY OF INSTALLATION. - Page 4 THIS APPLIANCE MUST ONLY BE USED FOR HEATING WATER. THE UNIT MUST BE INSTALLED ON A SOLID CONCRETE / BRICK WALL BY A QUALIFIED FITTER. BURCO DOES NOT ACCEPT ANY RESPONSIBILITY FOR THE SAFETY OF ANY UNIT NOT INSTALLED IN THIS WAY.
-
Page 5: Introduction
Warranty Information This Burco boiler comes with a comprehensive 1 year parts and labour warranty. If you have purchased a Burco boiler with a water filter, then the warranty is 2 years parts and labour. -
Page 6: Technical Data
Please ensure there is at least 220mm of clearance below the boiler to allow for filter changes, the location must be frost free. The unit must be installed on a solid concrete / brick wall by a qualified fitter. Burco does not accept any responsibility for the safety of any unit not installed in this way. - Page 7 In hard water areas, it is always advisable to fit an inline filtration unit to limit scale build-up. If you have purchased a Burco boiler that does not have a water filter system included, we recommend you fit a separate water filter between the boiler and the mains supply.
- Page 8 Electrical Connection Electrical Safety All electrical work must comply with all relevant wiring regulations and carried out by a qualified electrician. To protect against fire, electric shock and personal injury, do not immerse cord, plug, or water boiler in water or any other liquid.
-
Page 9: Operating Instructions
Operating Instructions Burco boilers are designed for continuous operation and should only be switched off for the purpose of maintenance or emergency. Boiler Overview This product is supplied with a power cord. Connection to electrical outlet is required and should be carried out by qualified personnel to the appropriate standards. - Page 10 Touch Screen Display (filtered models only): STANDBY STANDBY The LCD screen will illuminate with the Burco logo. The default temperature and the time will flash waiting to be set. The hour figure will flash. Use the scroll buttons and press MENU to set when the correct time is shown.
- Page 11 When no water is drawn from the boiler in 2 hours, the eco mode is engaged. The backlight turns off and the only data displayed is the Burco logo along with the time and the status indicator. Water should be drawn off to resume normal operation.
- Page 12 Heating up: HEATING will flash on controller screen during the heating up period. LOW TEMP may be shown on the screen during this time. When selected temperature is achieved – READY is shown. Filling: Once the INITIAL SET UP is complete, the filling process will start.
-
Page 13: Descaling & Cleaning Advice And Information
Cleaning and Descaling advice and information Descaling The descaling procedure must be performed by suitable personnel as it requires the removal of panels from the boiler and access to live electrical components. Always use a descaling agent suitable for stainless steel. Isolate the boiler from electrical supply. -
Page 14: Changing Water Filter
The boiler will alert when a new filter cartridge is required. The boiler should be descaled in conjunction with the filer change, see page 14 of instructions. The water filter cartridge is unique to Burco. Only Burco “BC02” replacement filter (Part No. 01/74334/0) will fit these models. Please either purchase a replacement from your catering equipment supplier, or 0344 879 3470 www.burco.co.uk... -
Page 15: Troubleshooting
Troubleshooting If you believe your Burco Boiler isn’t working correctly, please contact our Aftersales Team on 0344 879 3470. Your boiler is fitted with a fault system that is able to detect fault conditions. Some of the conditions are less serious and the boiler will continue to operate normally, while other faults are more serious and will disable the appliance. -
Page 16: Frequently Asked Questions (Faq's)
What Warranty does my water boiler have? Your Burco boiler will come with a 1 year parts and labour warranty. If you have purchased a boiler with a water filter, it will come with a 2 years parts and labour warranty. Please see the ‘Warranty’ section on page for details.
