TRANSLATION OF THE ORIGINAL INSTRUCTIONS
We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Contents
40
40
44
45
46
47
47
48
50
50
51
51
59
60
63
65
66
66
66
66
66
67
68
68
69
69
69
70
71
39
Advertisement
Table of Contents
Related Manuals for Smeg SIM3643D
Summary of Contents for Smeg SIM3643D
-
Page 1: Table Of Contents
5.5 Section cut from the countertop 5.6 Mounting TRANSLATION OF THE ORIGINAL INSTRUCTIONS We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • Keep children under the age of 8 away from the appliance when it 1.1 General safety instructions is in use. • Cleaning and maintenance must Risk of personal injury not be carried out by • During use the appliance and its unsupervised children. - Page 3 Instructions • Do not place metal objects, such • Installation and servicing should as dishes or cutlery, on the hob be carried out by qualified surface during use as they may personnel in accordance with overheat. current standards. • Do not insert pointed metal •...
- Page 4 Instructions • Fire hazard: Never leave objects • Do not use rough or abrasive on the cooking surfaces. materials or sharp metal scrapers. • DO NOT FOR ANY REASON • Do not use cleaning products USE THE APPLIANCE AS A containing chlorine, ammonia or SPACE HEATER.
- Page 5 Instructions • Use cables that can withstand • Activate the controls lock when temperatures of at least 90 °C. you have children or pets which could reach the hob. • The tightening torque of the screws of the terminal supply •...
-
Page 6: Appliance Purpose
Instructions • Let the cooking surface cool 1.3 Manufacturer’s liability down before closing the cover. • The manufacturer declines all liability for damage to persons or • People who have pacemakers or property caused by: other similar devices fitted must make sure that the operation of •... -
Page 7: Disposal
Instructions 1.6 Disposal • Deliver the appliance to the appropriate recycling centre for This appliance conforms to the electrical and electronic WEEE European directive equipment waste, or return it to (2012/19/EU) and must be the retailer when purchasing an disposed of separately from other equivalent product, on a one for waste at the end of its service life. -
Page 8: How To Read The User Manual
Instructions 1.7 How to read the user manual This user manual uses the following reading conventions: Instructions General information on this user manual, on safety and final disposal. Description Description of the appliance and its accessories. Information on the use of the appliance and its accessories, cooking advice. -
Page 9: Description
Description 2 Description 2.1 General description 38 cm 60 cm 80 cm Only for 38 cm models: = Left cooking zones = Centre cooking zones = Front cooking zone = Right cooking zones = Rear cooking zone 1 = Rear central cooking zone 2 = Front right cooking zone... -
Page 10: Control Panel
Description 2.2 Control panel 1 Special functions buttons 2 Timer setting area 3 Cooking zones setting area 4 Scroll bar 5 On/Off button Maximum power consumption table Dimensions Level 9 Booster Double Booster H x L (mm) Single zone 180 x 240 2100 W 2500 W 3000 W... - Page 11 Description Advantages of induction cooking Power control The hob is fitted with a power control The appliance is equipped with an module that optimises/limits consumption. If induction generator for each the overall set power level exceeds the cooking zone. Each generator maximum limit permitted, the electronic located under the glass ceramic circuit board will automatically manage the...
-
Page 12: Use
3 Use High temperature Danger of fire or explosion 3.1 Instructions High temperature • Do not use or leave flammable materials near the appliance or directly Danger of burns underneath the hob. • Do not cook in closed tins or containers, •... -
Page 13: Preliminary Operations
3.2 Preliminary operations List of symbols In order to remove any moisture that could On/Off button: turns the hob on or off. have accumulated during the manufacturing process and for the electronic circuits and Pause button: pauses cooking. control keypad to work properly: 1. - Page 14 Minimum cookware diameter Unsuitable cookware: • Copper, stainless steel, aluminium, Make sure that the minimum diameter of the fireproof glass, wood, ceramic and pans are those indicated in the following terracotta cookware. table, for both configurations. To see whether the pan is suitable, bring a Ø...
- Page 15 Limiting the cooking duration Advice on energy-saving The hob has an automatic device which • The diameter of the base of the pan must limits the duration of use. not exceed the width of the silk-screened cooking zone. If the cooking zone settings are not changed, the maximum duration of •...
- Page 16 Power levels Switching on the cooking zone automatically The power in the cooking zone can be adjusted to various levels. The table shows The hob is provided with an the levels suitable for various types of automatic pan sensing system. cooking.
- Page 17 2. Move your finger to the left or right on Quick selection the scroll bar to select the power level, This function allows you to quickly set the cooking zones to the from or activate the Booster required power. function (see “Booster Function”). After switching on the hob and having selected a cooking zone: 1.
- Page 18 After switching on the hob and having Double Booster Function (except for selected a cooking zone: zone 1) 1. Place a finger on the left-hand side of the The Double Booster function allows more scroll bar. power to be supplied compared to the Booster function.
- Page 19 2. Use the left-hand scroll bar to set the If a large, oval or oblong pan is being used, make sure that it is placed in the required cooking power. centre of the cooking zone. The same parameters are set on both cooking zones.
-
Page 20: Special Functions
To deactivate the Multizone function: Residual heat Simultaneously press the buttons of the Improper use cooking zones on which the Multizone Danger of burns function is active. The symbol disappears and the two zones can be • Supervise children carefully as they regulated separately. - Page 21 Pause function Grill Function This function is used to This function pauses the operation automatically activate the of all the cooking zones. Multizone function for the left zones only. It is used when using a To activate the Pause function: griddle or cooking with long pans.
-
Page 22: Additional Functions
• After the heating time has elapsed, the Controls lock cooking zone reverts to the previously selected power level. This function allows you to disable all the buttons of the appliance. This function can be deactivated by pressing and holding the set power level for at least 3 seconds, or by selecting a lower This is useful when cleaning the appliance power level. - Page 23 4. When the time elapses, a series of beeps • The flashing symbol will appear will sound. Press any button to deactivate above the cooking zone display. them. 3. Use the + and - buttons to select the required time. A maximum of 9 hours and 59 minutes can be set.
- Page 24 3. Use the + and - buttons to modify or reset 3.6 User menu the timer. The user menu is used to modify the operating characteristics of the appliance. 4. After 10 seconds, the timer will start the 7 options in the user menu can be modified. new countdown or will be deactivated.
-
Page 25: User Menu
Press all the buttons of the cooking zones in The Eco-Logic Advance function allows to sequence in a clockwise direction starting increase or decrease appliance total from the front left. Every effective touch will power by 0.1 kW steps. be confirmed by a beep. The timer display on the other hand will 38 cm models: indicate the default power setting... - Page 26 • 0: minimum volume. Option U6 allows you to activate or deactivate the automatic pan detection • 3: maximum volume. function. (see “Switching on the cooking zone automatically”). The sound associated with the • 0: automatic detection off. button and the sounds associated •...
-
Page 27: Error Codes
3.7 Error codes If the appliance malfunctions or operates incorrectly, the associated error code appears on the cooking zones display. The error codes always begin with “E..” or “Er..”, followed by a number. The following error codes can be corrected without having to contact the Technical Support Service. -
Page 28: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance 4.3 Ordinary weekly cleaning Clean and maintain the hob once a week 4.1 Instructions using an ordinary glass cleaning product. Always follow the manufacturer’s Improper use instructions. The silicon in these products Risk of damage to surfaces creates a protective, water-repellent membrane which also resists dirt. -
Page 29: What To Do If
Cleaning and maintenance Changes in colour do not affect the The cooking results are unsatisfactory: operation and stability of the glass. These • Make sure that the cooking temperature are not alterations to the material of the hob is not too high or too low. but just residues which have not been The hob smokes: removed and have then carbonised. -
Page 30: Installation
Installation 5 Installation 60 and 80 cm models: • 220-240 V / 380-415 V 2N~ 5.1 Electrical connection Power voltage Danger of electrocution • Have the electrical connection performed by authorised technical 6 x 1.5 mm² six-core cable. personnel. • Use personal protective equipment. •... -
Page 31: Instructions For The Installer
Installation Fixed connection 5.3 Safety instructions Fit the power line with an all-pole circuit Heat production during appliance breaker in compliance with installation operation regulations. The circuit breaker should be Risk of fire located near the appliance and in an easily reachable position. -
Page 32: Section Cut From The Countertop
Installation 5.5 Section cut from the countertop Hob seal To prevent leakage of liquid between the The following operation requires frame of the hob and the countertop, place building and/or carpentry work the adhesive seal provided along the entire and must therefore be carried out outer edge of the hob before assembly. -
Page 33: Mounting
Installation In the event the hob needs to be removed, cut the silicone using a cutter before attempting to remove it (C). 5.6 Mounting Over built-in oven unit If installed on top of an oven, the latter must be equipped with a cooling fan. - Page 34 Installation opens on rear Failure to install the double-layer opens on bottom and on rear wooden base exposes the user to possible accidental contact with On top of an empty kitchen unit or sharp or hot parts. drawers If there are other pieces of furniture (lateral Ventilation walls, drawers, etc.), dishwashers or fridges The illustrations below show two examples...
- Page 35 Installation Position of slot for clips Spring clips To ensure the hob is fixed and centred as accurately as possible, the clips provided must be positioned as described below: 1. Fit the clips by gently pressing them horizontally into the appropriate space. 2.
