ENVIROAIR DUCTLESS SPLIT SYSTEMS
SINGLE AND MULTI-ZONE
SINGLE ZONE
COOLING ONLY
ACW-09D-B – CCW-09D-B
ACW-12D-B – CCW-12D-B
ACW-18D-B – CCW-18D-B
ACW-24D-B – CCW-24D-B
COOLING AND HEATING
AHW-12D-B – CHW-12D-B
AHW-18D-B – CHW-18D-B
AHW-24D-B – CHW-24D-B
MULTI-ZONE
COOLING ONLY
ACM-09D-B – CCM-09D-B
ACM-12D-B – CCM-12D-B
COOLING AND HEATING
AHM-09D-B – CHM-09D-B
AHM-12D-B – CHM-12D-B
