Controls ................... 21 Displays................... 21 5. Operation General .................... 22 System Requirements..............26 Preparatory Operations ..............26 Working with the CSH24 Chain Saw ..........31 After Use ..................33 6. Maintenance General .................... 34 Maintenance and Service Table ............36 7. Servicing General ....................
Product description Usage Information Intended purpose The CSH24 Chain Saw is designed and built for the following applications: • Cutting of concrete (including reinforced), masonry and natural stone • Cutting of severance cuts, flush cuts and cross-cuts in ceilings, floors and walls •...
Length 6.5ft Hydraulic hose Water 36 psi Minimum working pressure 2 gpm Minimum flow Weight CSH24 Chain Saw with bar and chain 23 pounds Dimensions of the CSH24 Chain Saw 38-3/8" 16-5/16" 22" Dimensions of CSH24 Chain Saw Fig. 1-3...
Page 7
Product description Noise level Depending on the working environment, the CSH24 Chain Saw can cause excessive noise during operation. The noise can permanently harm the hearing of operating personnel and of other people nearby within a short time. Ear protection must therefore always be worn while working.
This chapter describes the safety instructions that are essential to follow when using the CSH24 Chain Saw All persons who work on and with the CSH24 Chain Saw, have a duty to read and understand the chapters of the Operating instructions relevant to their particular activities.
Safety instructions Safety principles Safety Boundaries The CSH24 Chain Saw has no effect on the safety concept of the connected systems, apparatus and installations. Safety elements Protection from personal injury is based primarily on a safety concept and design safety.
Inspection and maintenance obligation The operator is under an obligation to only use the CSH24 Chain Saw when it is in a perfect and undamaged condition. The maintenance intervals shown in the Operating instructions must be adhered to without fail.
Safety instructions Personal Protective Equipment 2 / 3 Personal Protective Equipment Fig. 2-1 1. Helmet with ear protectors 5. Waterproof, sturdy, 2. Visor or goggles comfortable clothing 3. Breathing mask 6. Work boots with steel toecaps 4. Waterproof gloves and non-slip soles Personal Protective equipment must always be worn when drilling, sawing, hammering or compressing concrete or stone in order to protect against the following dangers:...
Safety instructions Information and symbols In these Operating instructions information panels are used to draw attention to residual dangers and to point out important technical requirements. Danger symbols in the Operating instructions Danger Warning of danger, where failure to comply could lead to death or serious injury.
Safety instructions General Warnings The following warnings shown are generally applicable to all work (with and on the saw systems and during all phases of the life of the systems). Danger Electric shock due to defective electronic equipment. The electrotechnical equipment must be checked prior to each use and from time to time during prolonged usage.
Operative (user) User is the term employed by Diamond Products to designate a person who independently performs the following work: • Setup Diamond Products machines or systems for tasks according to the intended purpose.
Page 15
User • Has completed concrete expert training or has professional experience. • Has received an introduction (basic training) to operation of the CSH24 Chain Saw from a service engineer. • Has read and understood chapter 2 “Safety instructions”. Service engineers •...
4. Chain guard Function The overall function of the CSH24 Chain Saw remains exactly the same. The CSH24 Chain Saw is powered by a hydraulic drive assembly. The chain is driven by the hydraulic motor incorporated into the chain saw unit.
The chain saw unit is the central component of the CSH24 Chain Saw. The chain saw unit incorporates the drive motor and the operating handle and front handle for using the CSH24. The unit along with its valve block and the hydraulic and water connections also constitutes the interface with...
Page 18
Design and function Chain Saw Bar Fig. 3-3 1. Water inlet 4. Assembly opening 2. Chain guide 5. Reversing wheel 3. Assembly bore hole for chain tensioner Function The bar is securely fixed to the chain saw unit. The chain runs and is guided on the bar.
Design and function Diamond chain Dimensions of a new chain 7/32" Fig. 3-4 Dimensions of new chain Dimensions of a worn chain 3/16" Fig. 3-5 Dimensions of worn chain Danger When working with a worn chain there is a danger of the chain breaking.
Page 20
Insert the chain correctly according to the engraved mark. Failure to comply with this regulation may lead to serious physical injury or death. Function The diamond chain constitutes the tool for the CSH24 Chain Saw. It is with the help of the chain that the cut is performed.
CSH24 Chain Saw Front handle The front handle is used to hold and carry the CSH24 Chain Saw. Operating handle with manual starter The operating handle with manual starter is secured by the locking cut-out against unintentional activation.
Danger Danger from machine suddenly starting up. Before switching on the CSH24 Chain Saw the operator must ensure that no other person is present in the danger areas. Failure to observe this regulation may lead to serious physical injury, property damage, and possibly even death.
Page 23
Danger Danger from uncontrolled movements When the CSH24 Chain Saw is switched on, always hold it with both hands using the handles. Thumbs and fingers must be closed around the handles. Otherwise you may loose control of the Chain Saw. Handles must always be clean and dry.
Page 24
Failure to observe this regulation may lead to serious injury to body parts, and possibly even death. Danger Danger of the CSH24 Chain Saw restarting in the event of an accident Ensure that you can quickly stop the CSH24 Chain Saw (see Emergency Stop in the Operating instructions of the drive assembly you are using).
Page 25
Warning Warning against working when not in a fit state to do so. Do not use the CSH24 Chain Saw if you are under the influence of sedatives, alcohol or if you are overtired. Failure to adhere to this regulation may result in personal injury.
Operation System requirements In order to use the CSH24 Chain Saw, a hydraulic drive assembly is needed. Drive assembly power requirements: Minimum flow 9.25 gpm Minimum power: Max. pressure 2,000 psi Maximum flow 12gpm Maximum power: Max. pressure 2,000 psi If the basic power of the drive assembly used is higher, a flow divider / pressure limiter or a pressure relief valve can be used.
Page 27
Operation Sawing Conditions • Determine the position of pipes and cables in walls, floors and ceilings. • Where does the cooling water used for sawing flow to? (Think about water damage to the electrical supply). Securing the site • See “Chapter 1” Workplace and danger areas. Securing cutouts Secure cutouts from walls and especially from ceilings and floors by suitable means, e.g.
Page 28
Operation Perform a visual inspection of the CSH24 Chain Saw Check the chain tension 6 mm Fig. 6-3 Chain tension – The chain tension is correctly set if with a moderate pull the chain can be pulled away from the bar by a maximum of 1/4"...
Page 29
Connecting the CSH24 Chain Saw Connecting the hoses Warning Danger from uncontrolled movements of the CSH24 Never connect or disconnect hoses when the unit is running. Failure to adhere to this regulation may result in personal injury and property damage.
Page 30
Operation Hose connections Before connecting, check couplings, the CSH24 and feed lines for cleanliness. The following hose connections must be established: Fig. 6-6 Hose connections HCH50 Chain Saw Hoses Drive assembly hoses Water inlet (1) Water outlet (2) (Coupling – male connector) (Coupling –...
• Open the water valve on the drive assembly and check the water outlet on the CSH24 Chain Saw Information The water outlet on the CSH24 Chain Saw is released by pressing the locking cut-out and the manual starter. • Set the required operating pressure.
Page 32
Operation Working with cutting mandrel The cutting mandrel (1) has been developed as a mechanical aid that can be used for horizontal and vertical cuts. Fig. 6-7 Cutting mandrel...
• After final use rinse chain and bar with water. Allow chain to run for 5 seconds without water • Disconnect the CSH24 Chain Saw from the drive assembly • Lubricate the chain and bar (chain spray) • Store the CSH24 Chain Saw in the dry state Information Frequent lubrication will extend the life of the diamond chain and the bar.
Safety instructions It is essential to observe the following safety instructions, in particular in relation to the maintenance of the CSH24. Danger Danger of falling heavy parts. When performing the types of work described in this chapter, it is...
Page 35
Failure to adhere to this regulation may result in personal injury and property damage. Personnel qualifications The CSH24 Chain Saw should not be maintained by unauthorised persons. Personnel are only authorised where they meet the following requirements. • Have completed concrete expert training or professional experience.
Chain saw unit Tightness / cleanliness Retighten accessible screws and nuts Water cleaning Lubrication Check for wear Diamond chain Water cleaning Lubrication Chain tension Check for wear Major service May only be carried out by Diamond Products or an authorized representative...
Page 37
Maintenance Information Wear in the drive and reversing wheel / diamond chain and bar is highly dependent upon the thickness, condition and degree of reinforcement of the concrete being worked. Information In order to achieve an optimum balance between the diamond chain and the drive wheel, whenever the chain is exchanged due to wear the drive wheel should also be replaced.
Failure to observe this regulation may lead to serious physical injury, property damage, and even death. Warning Danger from uncontrolled movements of the CSH24! Never connect or disconnect hoses when the unit is running. Failure to adhere to this regulation may result in personal...
Page 39
Failure to adhere to this regulation may result in personal injury and property damage. Personnel qualifications The CSH24 Chain Saw should not be serviced by unauthorised persons. Personnel are only authorised where they meet the following requirements. • Have completed concrete expert training or professional experience.
Tensioning the diamond chain Proceed as follows: To tension the diamond chain you will need the wrench supplied with the CSH24. • Loosen both nuts (1) • Adjust the adjusting screw (2) for the correct chain tension • Tighten both nuts (1) Correct chain tension 1.
Servicing Changing the diamond chain To change the diamond chain you will need the wrenches supplied with the CSH24. Fig. 8-3 Changing the diamond chain Removing the diamond chain Proceed as follows: • Loosen the three chain guard securing screws (3) •...
Servicing Changing the bar To change the bar you will need the wrenches supplied with the CSH24. Fig. 8-4 Changing the bar Dismantling the bar Proceed as follows: • Loosen the three chain guard securing screws (3) • Remove the chain guard (4) and the chain bar plate (5) •...
In order to be able to change the drive wheel you must first dismantle the bar. To change the drive wheel you will need the wheel stop and Allen key supplied with the CSH24 Fig. 8-5 Changing the drive wheel...
The following table will help you to narrow down and rectify the source of the fault. Fault Possible cause Solution CSH24 Chain Saw cannot be Drive assembly is switched off Switch on drive assembly started Emergency stop on drive assembly...
Page 45
Servicing Fault Possible cause Solution No water coming from the bar and Water line is blocked Clean water line diamond chain Water valve on feed line is closed Open water valve. Insufficient water pressure Ensure a minimum water pressure of 36psi and 2gpm flow Diamond chain jumps from bar Chain tension too low Tension diamond chain correctly...
Failure to observe this regulation may lead to serious physical injury, property damage, and possibly death. Warning Danger from uncontrolled movements of the CSH24! Never connect or disconnect hoses when the unit is running. Failure to adhere to this regulation may result in property damage or personal injury.
Taking out of service and storage Personnel qualifications The CSH24 Chain Saw should not be taken out of service by unauthorised persons. Personnel are only authorised where they meet the following requirements. • Have completed concrete expert training or professional experience.
Transport Transporting the CSH24 Protect the CSH24 against transport damage: • Do not place anything on or against the CSH24 Chain Saw • Protect the CSH24 Chain Saw from impacts • Secure the CSH24 for transport to help prevent damage...
Page 52
(1) year from the date of shipment to Customer. The responsibility of Diamond Products under this Warranty is limited to replacement or repair of defective parts at Diamond Products’ Elyria, Ohio...
