2. Unpacking and Set-Up

1.
Remove the freezer and all accessories from the box. Carefully inspect
the freezer and all accessories for any shipping damage.
2.
Check the packing list to verify that the shipment is complete.
3.
Ensure the access port stopper or sealant is in place.
4.
Place the freezer on a level surface.
5.
Make sure that the air inlets and outlets are not blocked.
Connect to a power source. While the freezer can be used with either the AC
6.
Power Cord for lab, home or office use, or the DC Power Cord for mobile use, it is
recommended that the initial pull-down to Setpoint be completed via AC power.
Power Cord Available
Separately.
Power Cord Available
Separately.
8 of 28
A. To use the AC Power Supply:
i. During setup, identify the service power and plug
ii. If the appropriate line cord is not currently installed,
iii. Plug the other end of the line cord into the power
B. To use the DC Power Cord in a motor vehicle:
i. Make sure the freezer remains level. Exceeding an
ii. Plug the DC Power Cord into a 12V outlet that is
iii. Plug the opposite end into the freezer. Slide the
Operating Manual: ULT25 NEU
configuration available and then locate the
appropriate line cord for the service type you will
be using.
simply unplug the line cord from the unit and then
plug the appropriate line cord in its place.
source and then attempt to power on the unit.
angle of 12 degrees may cause loss of cooling.
rated at 20 amps.
NOTE: Not for use with 24 volt automotive systems.
20 A DC REQUIREMENT: Consult your automotive
specialist if your vehicle lacks 20 A rated 12V outlets.
male line cord adapter into the female connection
port, lining up the two plastic bungs on the male
adapter with the cutouts in the female port of the
freezer. Press the male adapter firmly into the
connection port and turn clockwise until an audible
"click" indicates full connection.
