3. Features of the
3.1 – Pictorial Tour, Freezer
The Stirling Ultracold ULT25NEU free-piston Stirling engine ultra-low
temperature freezer has the following features:
1. A freezer chamber which is protected by two lids
— Inner lid has a tight fitting foam lid.
2. Control Panel
— Described in more detail on page 12.
3. Lid Latch
— For positive closure.
4. Access Port
— For thermocouple wires, etc.
5. Cleanable Filter
— Helps protect the heat rejection fins from dust.
6. AC Power Connection
— Polarized to avoid error.
7. DC Power Connection
8. Temperature Probe Clip (optional)
— For holding the temperature probe in place
for calibration and monitoring.
9. Remote Alarm Contacts (optional)
10. Key Lock
— Locking lid for
sample integrity.
11. Power Supply Fan
12. Vent
10 of 28
2
9
12
Operating Manual: ULT25 NEU
25NEU Freezer
ULT
8
7
ULT25NEU-LIT-OM-BX2
3
1
5
7.15.19
|
4
10
