GAS GRILLS BLZ-3(NG/LP), BLZ-4(NG/LP), BLZ-5(NG/LP)
DANGER
- IF YOU SMELL GAS:
I) Shut off the gas supply to the appliance at its source.
2) Extinguish any open flames.
3) Open grill hood to release any accumulation of gas
vapor.
4) If a gas odor persists, keep away from your
appliance and contact your gas supplier or fire
department immediately.
ATTENTION:
INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.
CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE
INSTALLING OR OPERATING.
USE & CARE GUIDE
- CONTACT INFORMATION -
Blaze Outdoor Products:
6620 Greenwell Springs Rd, Baton Rouge, LA 70805
Phone: 866-976-9510
CustomerService@BlazeGrills.com
BLAZEGRILLS.COM
Blaze Outdoor Products Instructional Book
Page | 1
WARNING
I) Do not store or use gasoline or other flammable
liquids or vapor in the vicinity of this or any other
appliance
2) A LP cylinder not connected for use shall not be
stored in the vicinity of this or any other appliances.
Advertisement
Table of Contents
Related Manuals for Blaze Outdoor Products BLZ-3NG
Summary of Contents for Blaze Outdoor Products BLZ-3NG
- Page 1 CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE INSTALLING OR OPERATING. - CONTACT INFORMATION - Blaze Outdoor Products: 6620 Greenwell Springs Rd, Baton Rouge, LA 70805 Phone: 866-976-9510 CustomerService@BlazeGrills.com BLAZEGRILLS.COM Blaze Outdoor Products Instructional Book Page | 1...
-
Page 2: Table Of Contents
Outdoor Kitchen Ventilation 23-24 ii. Building BBQ Specifications and Instruction 24-26 iii. Installation Diagrams VII. First Time Operation i. Lighting the Appliance 28-29 ii. Manually Lighting the Appliance 29-30 iii. Flame Adjustment 30-31 Blaze Outdoor Products Instructional Book Page | 2... - Page 3 Preheating the Infrared Burner iii. Infrared Burner Cleaning Fuel Conversion i. Gas Regulator 34-35 ii. Main Burner iii. Rear Burner XI. Warranty Registration XII. Grill Parts XIII. Product Serial Number XIV. Blaze Product Registration Blaze Outdoor Products Instructional Book Page | 3...
- Page 4 THIS MANUAL APPLIES TO THE FOLLOWING BLAZE GRILLS: Model: BLZ-3LP / BLZ-3NG 3 BURNER Model: BLZ-4LP / BLZ-4NG 4 BURNER Cutout Dimensions 23 1/4”W x 21 1/4”D x 8 1/2”H Cutout Dimensions 30 5/8”W x 21 1/4”D x 8 1/2”H...
- Page 5 *Limited Lifetime on valves Warranty *1 Year – Ignition components *Appliances must be registered within 30 days of purchase to validate this warranty. *See warranty section for details. Blaze Outdoor Products Instructional Book Page | 5...
-
Page 6: Bbq Specifications
BBQ SPECIFICATIONS NOTE: ALWAYS have equipment measured by Contractor before beginning any project. Blaze Outdoor Products Instructional Book Page | 6... -
Page 7: General Safety And Installation Warnings
Any non-approved alterations made to the appliance will void the product’s warranty. NOTE: The manufacturer cannot be held responsible for damage or injury caused by improper use of this appliance. Blaze Outdoor Products Instructional Book Page | 7... - Page 8 “T” handle type manual gas valve must be installed in the gas supply line to this appliance. This applies to permanently installed natural gas and propane installations. This does not apply to propane portable installations using a 20 pound tank. Blaze Outdoor Products Instructional Book Page | 8...
- Page 9 Although an obstructed burner tube is not the only cause of “FLASH- BACK” it is the most common cause, and frequent inspection and cleaning of the burner tubes is necessary. Blaze Outdoor Products Instructional Book Page | 9...
- Page 10 Use cooking utensils with wood handles and insulated oven mitts when operating the appliance. Do not store anything in the appliance. Make sure food is not forgotten in the appliance; forgotten items could melt or catch fire when the appliance is turned on. Blaze Outdoor Products Instructional Book Page | 10...
-
Page 11: Location Of Appliance
Non-Combustible Enclosure: The BLAZE GRILL must be installed in a NON-COMBUSTIBLE ENCLOSURE ONLY. The determination of whether a location is combustible or non-combustible construction is made by the local fire marshal, building inspector or the local safety authority having Blaze Outdoor Products Instructional Book Page | 11... - Page 12 When using a vent hood, the area above the cooking surface of the griddle must be covered with a vent hood larger than the cooking area of the griddle, and with a minimum of 1200 CFM for proper outdoor application. Blaze Outdoor Products Instructional Book Page | 12...
-
Page 13: Electrical Safety And Installation Warnings
This appliance conforms to all uniform electrical safety codes and electrical grounding regulations. Install unit according to I.A.W. local codes or with National Electrical Code ANSI/NFPA 70 or CSA C22.1 in their absence. Blaze Outdoor Products Instructional Book Page | 13... -
Page 14: Gas Safety And Installation Warnings
CHECK TO ENSURE THAT THE GAS SUPPLY HOSE DOES NOT COME IN CONTACT WITH ANY HOT SURFACE, SHARP OR ROUGH EDGES OF THE GRILL OR OUTDOOR KITCHEN CONSTRUCTION. DO NOT KINK THE GAS LINE WHEN INSTALLING. Blaze Outdoor Products Instructional Book Page | 14... - Page 15 Finding and/or fixing a gas leak is NOT a “DO-IT-YOURSELF” procedure – ONLY USE A PROFESSIONAL. NEVER USE THE GRILL WITHOUT FIRST LEAK TESTING THE GAS CONNECTIONS INCLUDING ALL OF THE VALVES, FITTINGS, LINES ETC. (ALL GAS CONNECTIONS SHOULD BE CHECKED) Blaze Outdoor Products Instructional Book Page | 15...
-
Page 16: Checking For Gas Leaks
Check to ensure that flexible hoses do not have any cuts and wear that may affect the safety before each use. Only the factory supplied hose and regulator must be used. Use only replacement regulator and hose assemblies specified by BLAZE OUTDOOR PRODUCTS. Checking for Gas Leaks Perform a leak test before each use. - Page 17 Ensure the leak test includes all valves, pipe connections, joints, lines and every point from the gas source to the burners. NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS. Blaze Outdoor Products Instructional Book Page | 17...
-
Page 18: Unpacking Unit
This is accomplished by first placing the burner tube shutter hole securely over the valve orifice and ensuring the male post on the burner rests in the corresponding slot in the rear of the grill chassis. Blaze Outdoor Products Instructional Book Page | 18... -
Page 19: Gas Connections
Never store any spare or extra gas cylinder(s) around or in the outdoor kitchen containing the BLAZE GRILL or any other open flame, heat-producing appliance(s) or heat source. Blaze Outdoor Products Instructional Book Page | 19... -
Page 20: Transporting And Storing Lp Gas
The LP Gas Cylinder must be in compliance with the specifications for LP‐Gas Cylinders of the US Department of Transportation or the National Standard of Canada, CAN/CSA‐ B339. The basic tank size is 12” in diameter and 18” High with a QCC‐1 cylinder valve. Blaze Outdoor Products Instructional Book Page | 20... - Page 21 6. To disconnect after you have used the appliance, turn the burner knobs to the OFF position. 7. Close the Cylinder Valve by turning the Hand Wheel counter-clockwise until it stops. 8. Disconnect the regulator from the LP cylinder after use. Blaze Outdoor Products Instructional Book Page | 21...
-
Page 22: Installing The Appliance In A Bbq Island
This can back up the heat behind the control panel potentially creating a gas leak, damage to the product, and injury. A wind block behind the grill may be necessary. Blaze Outdoor Products Instructional Book Page | 22... -
Page 23: Outdoor Kitchen Ventilation
These are not the only possible options for venting but instead simply some examples of the more common configurations found. Notice the middle set of vents being positioned lower on the island cavity for LP gas. Blaze Outdoor Products Instructional Book Page | 23... -
Page 24: Building Bbq Specifications And Instruction
Before installing the grill into the island cutout, the main burner cotter pins may be removed for convenience of service, adjustments and maintenance in the future. These are accessible from the outside rear of the grill. Blaze Outdoor Products Instructional Book Page | 24... - Page 25 Check to make sure the appliance is level and is supported around the entire outside edge. If the appliance i s not level or is unstable, use non-combustible shims under the outside lip to stabilize it. • Perform the leak test procedure as described earlier in this manual. Blaze Outdoor Products Instructional Book Page | 25...
- Page 26 (such as a combustible wall) be located behind the grill that the needed 5” for lid clearance doesn’t satisfy the distance required from a combustible surface. See diagram on next page. Blaze Outdoor Products Instructional Book Page | 26...
-
Page 27: Installation Diagrams
Additional Hood Clearance Installation Diagram Installation Method for Low Pressure Gas (5 Gallon LP tank shown) Source- (Natural Gas Regulator Shown) Blaze Outdoor Products Instructional Book Page | 27... -
Page 28: First Time Operation
If the burner does not light on the first try, repeat immediately. (For rear burner, a slower turn of the knob is necessary. This allows gas to accumulate in Blaze Outdoor Products Instructional Book Page | 28... -
Page 29: Manually Lighting The Appliance
Wait five minutes until the gas clears before attempting to light it again. If the burner does not light after several attempts, immediately close all gas valves and consult an authorized service technician. Blaze Outdoor Products Instructional Book Page | 29... -
Page 30: Flame Adjustment
Inspect burners for proper flame appearance. The ideal flame appearance is one that is mostly blue and not lifting off of the burner surface. There is an air shutter found at the end of the burner (close to Blaze Outdoor Products Instructional Book Page | 30... -
Page 31: Cleaning Your Appliance
Before installing the cover, always allow the surface to dry. DO NOT cover a damp appliance. Blaze Outdoor Products Instructional Book Page | 31... - Page 32 Failure to meet these conditions can cause dangerous conditions that can cause personal injury and/or property damage. Blaze Outdoor Products Instructional Book Page | 32...
-
Page 33: Optional Infrared Sear Burner
This allows any food particles or grease drippings to burn away. Once your appliance has cooled completely, use a soft brush or vacuum to remove any ash accumulation on the burner if necessary. Blaze Outdoor Products Instructional Book Page | 33... -
Page 34: Fuel Conversion
2. If converting to Natural Gas, a low pressure regulator with an outbound pressure set to 4” of Water Column pressure must be used. 3. With either setup, remember to always check for gas leaks after the job is complete (see checking for gas leaks). Blaze Outdoor Products Instructional Book Page | 34... - Page 35 Blaze Outdoor Products Instructional Book Page |...
-
Page 36: Main Burner
For the Blaze 4 & 5 Burner, replace the back burner orifice by removing the plate on the rear of the BBQ and carefully removing the fitting. Replace with the provided conversion back burner orifice – large brass fitting (differs from small main burner orifice). Blaze Outdoor Products Instructional Book Page |... -
Page 37: Warranty Registration
Outdoor Products for more information on correct installation of the gas appliance. Blaze Outdoor Products shall not be liable under this or any implied warranty for incidental or consequential damages and Blaze Outdoor Products liability is limited to the purchase price of the appliance only. This warranty gives you specific legal rights, and you may also have other rights, which may vary from state to state. -
Page 38: Grill Parts
Blaze 3 Burner Blaze 4 & 5 Burner Note: Add one burner, one flame tamer, one heat separator and one grid for the Blaze 5 Burner. Blaze Outdoor Products Instructional Book Page |... -
Page 39: Product Serial Number
Appliance model: Appliance serial number: □ Propane □ Natural Gas Type of fuel being used: Date purchased: Date installed: Blaze dealer’s name: Blaze dealer’s address: Blaze dealer’s phone number: Blaze Outdoor Products Instructional Book Page |... -
Page 40: Blaze Product Registration
What is the model number of the Blaze Product purchased? What is the serial number on the Blaze product? Where did you buy your Blaze product? Mail To: Blaze Outdoor Products, Warranty Registration, 6620 Greenwell Springs Rd Baton Rouge, LA 70805 Blaze Outdoor Products Instructional Book Page |...
