Aztech HL115EP Easy Start Manual

Advertisement

Quick Links

DEVICES ARE PLUG
AND PLAY READY.
A
Package Contents
The following items are included in your HL115EP package.
HL115EP
Ethernet
Cable
B
Device Overview
Power LED
Powerline
Activity LED
Ethernet
Activity LED
HomePlug AV devices are preconfigured with a common Private Network Name. Adding new HomePlug AV devices to an existing
network with the default Private Network Name is as easy as plugging the device into the power outlet. If you wish to have a unique
private Network Name, simply follow the instructions below. This Easy Start Guide, the User Manual, and the HomePlug AV Utility
software is included in the Resource CD and is also downloadable on our Aztech Support Website (www.aztech.com/support).
Resource CD
Easy Start
Guide
You may use this AC Pass-through
as an extra power outlet.
Reset
Button
Ethernet
Port
MODEL
HL115EP
C
Setting up your HomePlug AV Network
Step 1
In Room A, plug in your HomePlug AV device into the power outlet
and connect it to the router using an Ethernet cable.
NOTE: Ensure that your router's internet connection is UP to allow
access to the internet.
Step 2
In Room B plug in your other Homeplug AV device into the power
Simple
Connect
outlet and connect it to your computer's ethernet port using an
Button
Ethernet cable.
Step 3
Confirm that a connection has established on both HomePlug AV
devices. All 3 LEDs (Power
must be ON. Your Homeplug AV Network is now ready to use and
can access Internet.
, Powerline
, and Ethernet
)

Advertisement

loading
Need help?

Need help?

Do you have a question about the HL115EP and is the answer not in the manual?

Questions and answers

Summary of Contents for Aztech HL115EP

  • Page 1 AND PLAY READY. private Network Name, simply follow the instructions below. This Easy Start Guide, the User Manual, and the HomePlug AV Utility software is included in the Resource CD and is also downloadable on our Aztech Support Website (www.aztech.com/support). Package Contents Setting up your HomePlug AV Network The following items are included in your HL115EP package.
  • Page 2 If in case you have changed the Private Network Name of your existing network, you may use the Simple Connect Button of your HomePlug X HomePlug Y HL115EP and the other devices as indicated below: (Your new HomePlug) (A HomePlug that belongs to the existing...
