- Page 1 SBC-212-WT User Manual Version 1.0 Published September 2017 Copyright©2017 ASRock INC. All rights reserved.
- Page 2 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
- Page 3 The terms HDMI™ and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
-
Page 4: Table Of Contents
Contents 1 Introduction ............6 1.1 Package Contents ............6 1.2 Specifications ..............7 1.3 Motherboard Layout ............9 1.4 I/O Panel ................ 11 2 Installation ............12 2.1 Screw Holes ..............12 2.2 Pre-installation Precautions ........... 12 2.3 Installation of Memory Modules (SO-DIMM) ....13 2.4 Expansion Slots (mini-PCIe and mini-PCIe/mini-SATA Slots) ................ - Page 5 4 Software Support ..........38 4.1 Install Operating System ..........38 4.2 Support CD Information ..........38 4.2.1 Running Support CD ..........38 4.2.2 Drivers Menu ............38 4.2.3 Utilities Menu............38 4.2.4 Contact Information ..........38...
-
Page 6: Introduction
If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. www.asrock.com/support/index.asp 1.1 Package Contents ASRock SBC-212-WT Motherboard (3.5” SBC (5.8-in x 4.0-in) / (148 x 102 mm)) ASRock SBC-212-WT Driver CD ASRock SBC-212-WT Jumper setting instruction... -
Page 7: Specifications
1.2 Specifications Form Dimensions 3.5" SBC (5.8-in x 4.0-in) / (148 x 102 mm) Factor ® Intel new Atom™ Baytrail-E3800 Series Supports Hyper-Threading Technology Core Processor Number System Max Speed (By CPU) L3 Cache Chipset BIOS UEFI Expansion Mini-PCIe 1 (Half Size) + 1 (Full Size) shared with mSATA Slot mSATA 1 (Full Size) shared with SATA2... - Page 8 Serial PS/2 6 (3 x 2.54 pitch header USB 2.0 compliant) LVDS/ Inverter 1 x COM1 (RS-232/422/485), 3 x COM Serial (RS-232) SATA 2 x SATA2 (3.0Gb/s) Internal mPCIe Connector Parallel mSATA 1 (shared) IrDA GPIO 8-bit 4 x GPI + 4 x GPO SATA PWR Output Con Speaker...
-
Page 9: Motherboard Layout
1.3 Motherboard Layout LPC1 USB2H_2_3 USB2H_4_5 DDR3 (Support DDR3L Only) CHA_FAN1 BIOS Chip CPU_FAN1 JGPIO1 LAN1 SATAII_2 LAN2 SATAII_1 T: USB 2.0 B: USB 3.0 SATA_PWR1 Line Out PLED PWRBTN PWR_JP1 HDLED RESET ATX12V1 PANEL1 BUZZ1 HD_AUDIO1 COM4 COM3 COM2 COM1 SET_CM1 SPEAKER1... - Page 10 1 : LPC Header 2 : 3-Pin Chassis FAN Connector (+12V) 3 : USB2.0 Headers (USB2H_2_3, USB2H_4_5, USB2_0_1) 4 : Backlight Power Selection (LCD_BLT_VCC) (BKT_PWR1) 5 : Panel Power Selection (LCD_VCC) (PNL_PWR1) 6 : Clear CMOS Headers (CLRMOS1, CLRMOS2) 7 : Backlight & Amp Volume Control (BLT_VOL1) 8 : Inverter Power Control Wafer (BLT_PWR1) 9 : mSATA Select (MSATA_SEL1) 10 : Backlight Control Level (BLT_PWM1)
-
Page 11: I/O Panel
1.4 I/O Panel HDMI Port (HDMI1) USB 3.0 Port VGA Port (VGA1) USB 2.0 Port LAN RJ-45 Port (LAN1)* Line out (Green) LAN RJ-45 Port (LAN2)* * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. -
Page 12: Installation
Chapter 2: Installation This is a 3.5” SBC (5.8-in x 4.0-in) form factor (148 x 102 mm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. -
Page 13: Installation Of Memory Modules (So-Dimm)
2.3 Installation of Memory Modules (SO-DIMM) SBC-212-WT provides one 204-pin DDR3 (Double Data Rate 3) SO-DIMM slot, which supports single channel DDR3L SDRAM only. Step 1. Align a SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot. -
Page 14: Expansion Slots (Mini-Pcie And Mini-Pcie/Mini-Sata Slots)
2.4 Expansion Slots (mini-PCIe and mini-PCIe/mini-SATA Slots) There is 1 mini-PCIe slot and 1 mini-PCIe/mini-SATA slot on this motherboard. mini-PCIe slot: MINI_PCIE1 (mini-PCIe slot; half size) is used for PCI Express mini cards. mini-PCIe/mini-SATA slot: MINI_PCIE2 (mini-PCIe/mini-SATA slot; full size) is used for PCI Ex- press mini cards or mSATA cards. -
Page 15: Jumpers Setup
2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”... - Page 16 Panel Power Select (LCD_VCC) Use this to set up the VDD power of the LVDS connector. (5-pin PNL_PWR1) 1-2: +3V (see p.9 No. 5) 2-3: +5V 3-4: +5V 4-5: +12V Backlight Power Select Use this to set up the backlight (LCD_BLT_VCC) power of the LVDS connector.
-
Page 17: Onboard Headers And Connectors
2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! SATA2 Connectors These two Serial ATA2 SATAII_2 (SATA2) connectors support (SATAII_1, SATAII_2: see p.9, No. - Page 18 PLED (System Power LED): Connect to the power status indicator on the chassis front panel. The LED is on when the system is operating. The LED keeps blinking when the sys- tem is in S1 sleep state. The LED is off when the system is in S3/S4 sleep state or powered off (S5).
- Page 19 ATX Power Connector (Input 9V-36V) Please connect a DC power supply (9V-36V) to this (4-pin ATX12V1) connector. (see p.9 No. 18) 1-4 : GND 2-3 : DC Input SATA Power Output Connector (4-pin SATA_PWR1) (see p.9 No. 15) +12V COM Port Headers (10-pin COM1, COM2, COM3, COM4) (see p.9 No.
- Page 20 LVDS Connector Signal Name Signal Name LCD_BLT_VCC LCD_BLT_VCC (40-pin LVDS1) CON_LBKLT_CTR LCD_BLT_VCC (see p.9 No. 12) GND9 CON_LBKLT_EN LVDS_B_CLK# LVDS_B_CLK LVDS_B_DATA3 GND5 DPLVDD_EN LVDS_B_DATA3# LVDS_B_DATA2# LVDS_B_DATA2 LVDS_B_DATA1 GND4 GND8 LVDS_B_DATA1# LVDS_B_DATA0# LVDS_B_DATA0 LVDS_A_CLK GND3 GND7 LVDS_A_CLK# LVDS_A_DATA3# LVDS_A_DATA3 LVDS_A_DATA2 GND2 GND6 LVDS_A_DATA2# LVDS_A_DATA1#...
- Page 21 LPC Header This connector supports Trusted Platform Module (TPM) (19-pin LPC1) system, which can securely (see p.9 No. 1) store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. Chassis Intrusion Headers This motherboard supports CASE OPEN detection feature...
-
Page 22: Uefi Setup Utility
Chapter 3: UEFI SETUP UTILITY 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2>... -
Page 23: Navigation Keys
3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Enter>... -
Page 24: Advanced Screen
3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configu- ration, Chipset Configuration, Storage Configuration, Intel(R) Smart Connect Tech- nology, Super IO Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. -
Page 25: Cpu Configuration
3.3.1 CPU Configuration Intel SpeedStep Technology Intel SpeedStep technology is Intel’s new power saving technology. Pro- cessors can switch between multiple frequencies and voltage points to en- able power saving. The default value is [Disabled]. Configuration options: ® [Enabled] and [Disabled]. If you install Windows and want to enable this function, please set this item to [Enabled]. -
Page 26: Chipset Configuration
3.3.2 Chipset Configuration Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. Active LVDS Use this to enable or disable the LVDS. The default value is [Enabled]. Panel Type Selection Use this to select panel type. -
Page 27: Storage Configuration
3.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. Configuration options: [IDE Mode] and [AHCI Mode]. The default value is [AHCI Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance but IDE mode does not have these advantages. -
Page 28: Intel(R) Smart Connect Technology
3.3.4 Intel(R) Smart Connect Technology Intel(R) Smart Connect Technology Use this item to enable or disable Intel(R) Smart Connect Technology. Intel(R) Smart Connect Technology keeps your e-mail and social networks, such as Twitter, Facebook, etc. updated automatically while the computer is in sleep mode. -
Page 29: Super Io Configuration
3.3.5 Super IO Configuration COM1 Configuration Use this to set parameters of COM1. Select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Configuration Use this to set parameters of COM2. COM3 Configuration Use this to set parameters of COM3. COM4 Configuration Use this to set parameters of COM4. -
Page 30: Acpi Configuration
3.3.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. ACPI HPET Table Use this item to enable or disable ACPI HPET Table. The default value is [Enabled]. -
Page 31: Usb Configuration
3.3.7 USB Configuration Intel USB 3.0 Mode Use this item to enable or disable Intel USB 3.0 mode. Legacy USB Support Use this option to select legacy support for USB devices. There are four configuration options: [Enabled], [Auto] and [UEFI Setup Only]. The default value is [Auto]. -
Page 32: Trusted Computing
3.3.8 Trusted Computing Security Device Support Enable or disable BIOS support for security device. -
Page 33: Hardware Health Event Monitoring Screen
3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CPU_FAN1 Setting This allows you to set CPU fan 1’s speed. -
Page 34: Security Screen
3.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the ad- ministrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. -
Page 35: Boot Screen
3.6 Boot Screen In this section, it will display the available devices on your system for you to config- ure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer’s boot time. In fast mode you may not boot from an USB storage device. - Page 36 CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable ® unless you’re running a WHCK test. If you are using Windows 8.1 / 8 64- bit and all of your devices support UEFI, you may also disable CSM for faster boot speed.
-
Page 37: Exit Screen
3.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”... - Page 38 Click on a specific item then follow the installation wizard to install it. 4.2.4 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may con-...
