kincrome K7529 Operation Manual

Operation Manual

Parts List

TOOLS & ASSISTANCE NEEDED
K7529 manual.indd 1
Chest & Trolley Combo
9 Drawer
16 x 12mm Bolts
Keys x 6
for Castors
10 x EVA Liners
Handle x 1 Screws;
4 x Short,
4 x Long
(Screwed into
Removeable Panel)
Side Parts Tray x 1
Non-Locking Castors x 2
Locking Castors x 2
2 People Lift
1
THIS OPERATING MANUAL CONTAINS IMPORTANT
SAFETY INFORMATION. READ CAREFULLY AND
UNDERSTAND ALL INFORMATION BEFORE
OPERATING STORAGE CABINET.
SAVE THIS MANUAL FOR FUTURE USE
TOOL CHEST SPECIFICATIONS
Width
Overall 648mm
Top Section 605mm
Small Drawers
Shallow 175mm
Large Drawers
Shallow 580mm
Deep 580mm
TOOL TROLLEY SPECIFICATIONS
Width
Overall 765mm
Overall (w/o 765mm
Castors)
Top Section 765mm
Drawers
Shallow 605mm
Deep 605mm
Cabinet 675mm
Side Parts Tray 80mm
Castors 125 x 50mm (5 x 2") 2 x Locking
Weight 45.8kg
OVERALL SPECIFICATIONS
Width
Overall 765mm
Overall (w/o 765mm
Castors)
Weight 69.8kg
Removing Chest Castor
or
+
12mm Spanner + 12mm Spanner or
Phillips Screwdriver 5mm Hex Key
K7529
Bunnings Weight Icons (2676) 30/3/04 10:11 AM Page 3
40kg+
This product requires a two person lift
- use proper lifting techniques
Depth Height
315mm 480mm
310mm 145mm
260mm 38mm
260mm 38mm
260mm 65mm
Depth Height
460mm 1105mm
460mm 955mm
455mm 15mm
395mm 55mm
395mm 135mm
435mm 555mm
440mm 75mm
Depth Height
460mm 1570mm
460mm 1415mm
Handle
10mm Spanner
