Part List
Item
Description
①
Side panel (right)
②
Side panel (left)
③
Bottom panel
④
Back panel
⑤
Top panel
b
Cam
c
Hinge
e
Wooden dowel
f
Metal dowel
Screw
g
(M4*15)
Two Door
Wall Cabinet
Safety Instructions
These unit should be placed on a level surface.
Evenly distibute the weight on each level and always keep the
heavier loads on the bottom.
Use care when working with metal parts.
To facilitate assembly we recommend having two persons assemble
the cabinet.
(Notice: Small lable with item# on each parts)
Q'ty
1
1
1
1
1
Accessory
15
4
8
15
24
Item
Description
Door with logo
⑥
(right)
⑦
Door (left)
⑧
Shelf
⑨
Top spanner
⑩
wall cleat
h
Bolt
i
Handle
j
Bracket
k3
wall anchor
Model Number
K7803
Required Tools
Phillps screw driver
Flat screw driver
Rubber mallet
Q'ty
1
1
1
1
1
4
2
4
2
Advertisement
Table of Contents
Related Manuals for kincrome K7803
Summary of Contents for kincrome K7803
- Page 1 Two Door Model Number Wall Cabinet K7803 Safety Instructions These unit should be placed on a level surface. Evenly distibute the weight on each level and always keep the heavier loads on the bottom. Use care when working with metal parts.
- Page 2 Assembly Instructions Step 1 Front View: 8*( f ) Screw 8*( f ) Metal dowel in the side panels, and push in 4*(e) Wooden dowel at the bottom of the side panels. Insert the back panel to the slots of the side panels and bottom panels.
- Page 3 Assembly Instructions Step 3 Assemble the two doors: Set hinges(c) into the doors, 4*(c) using a screwdriver, turn the 2*(g) screws in the hinge 24*(g) until tight to lock the place. Lift door to side panel and set top hinge into the hinge mounting plate, assemble ⑦...
