Model 3991B112KG
MEMS SHOCK ACCELEROMETER
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com
Advertisement
Related Manuals for PCB Piezotronics 3991B112KG
Summary of Contents for PCB Piezotronics 3991B112KG
- Page 1 Model 3991B112KG MEMS SHOCK ACCELEROMETER Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
- Page 2 Piezotronics, user servicing or repair is critical test. not recommended and, if attempted, may void the factory warranty. Routine PCB Piezotronics maintains an ISO- maintenance, such as the cleaning of 9001 certified metrology laboratory and electrical connectors, housings, and offers calibration services, which are...
- Page 3 50% of the general contact numbers are: replacement cost returned item(s). PCB will provide a price PCB Piezotronics, Inc. quotation replacement 3425 Walden Ave. recommendation for any item whose Depew, NY14043 USA repair costs would exceed 50% of...
-
Page 4: China Rohs Compliance
PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 汞 镉 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 铅 (Pb) (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接... - Page 5 Component Name Hazardous Substances Lead Mercury Cadmium Chromium VI Polybrominated Polybrominated (Pb) (Hg) (Cd) Compounds Biphenyls Diphenyl (Cr(VI)) (PBB) Ethers (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
- Page 6 3991 Series Piezoresistive Shock Accelerometer Operating Guide Introduction display a slight linear decrease in sensitivity as temperature increases. TZS – Thermal Zero Shift, the change in ZMO due to This Operating Guide contains information that will familiarize the user with the basic operation and installation of temperature.
- Page 7 3991 Series Piezoresistive Shock Accelerometer Operating Guide they are preferred for applications in which integration from with unwanted static strain, possibly resulting in zero-shift acceleration to velocity or displacement may be performed: during a shock measurement. Rigid-body motion penetration studies Prepare a smooth, flat mounting surface and, if applicable, drill and tap mounting holes according to the Sensor ...
- Page 8 3991 Series Piezoresistive Shock Accelerometer Operating Guide Sensor Verification information, such as model number, serial number and description of the problem, available. Generally the ZMO of a PR transducer is a good measure of the health of the transducer. Input Resistance (from Red to Customers outside the U.S.
- Page 9 Model Number Revision: E MEMS SHOCK ACCELEROMETER ECN #: 48068 3991B112KG Performance ENGLISH OPTIONAL VERSIONS Sensitivity(± 50 %)(at 10 VDC excitation) 0.20 mV/g 0.02 mV/(m/s²) Optional versions have identical specifications and accessories as listed for the standard model Sensitivity 0.02 mV/V/g 0.002 mV/V/(m/s²)
- Page 10 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION .56 [14.2] without the written consent of PCB Piezotronics Inc. REMOVED ITAR CONTROL STAMP 48068 .375 [9.53] .19 [4.8] ...
- Page 11 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. -SEE SHEET 1- "SERVICE LOOP" TO ALLOW MOTION WITHOUT PULLING...
