INSTRUCTIONS FOR USE
Mark 5 Nuvo Family
(NUVO, NUVO 8 & NUVO 10)
OXYGEN CONCENTRATOR
For models: 505, 565, 585, 595, 905, 965, 985 and 1005
[Original language is English]
This unit is not a life-support device. Geriatric,
pediatric, or any other patient unable to
communicate discomfort while using this device
should receive additional monitoring.
This device supplies highly concentrated oxygen
enriched product gas that promotes rapid
burning.
DO NOT allow smoking or open flames within the
same room of this device or the administration
accessory (cannula). Failure to observe this
warning can result in severe fire, property
damage, and / or cause physical injury or death.
Oxygen accelerates the combustion of flammable
substances. DO NOT use oil, grease, petroleum
based or other flammable products on the
device, the administration accessory (cannula) or
the patient's face / neck.
Only persons who have read and understood this
entire manual should be allowed to operate the
device.
CONTRAINDICATIONS - Those who continue to
smoke (because of the increased fire risk and the
probability that the poorer prognosis by smoking
will offset the treatment benefit).
Federal Law (US) restricts this device to sale by, or
℞
on the order of, a licensed physician. This oxygen
Only
concentrator should be used only under the
supervision of a licensed physician.
______________________________________________________________________________________________________________
2010-2324CE-G
(and variants thereof)
March 2022
NUVO 10 (Model 1005) shown for reference.
