- Page 1 SERVICE MANUAL USER MANUAL WIRE REMOT CONTROL ROOF-TOP Serie WIRE REMOT CONTROL ROOF-TOP Edition 01/21 Models CCRTD-12B...
- Page 2 1. Wired controller: CCRTD-12B CCRTD-12B 1.1 Wired controller specifications CCRTD-12B Model Power supply 5.0V DC Operation temperature -15°C～43°C Operation humidity 40%~90% RH 1.2 Introduction of indicators function 1. Operation mode indication: When press ‘MODE’ button, the following mode can be selected in circle. For cooling only model, the indicator ‘HEAT’...
- Page 3 2. Timer ON/OFF When adjust setting on time or only on time is set, the indicator ‘ON’ is lighted. When adjust setting off time or only off time is set, the indicator ‘OFF’ is lighted. If timer-on and timer-off timer both set, the indicators ‘ON’ and ‘OFF’ will be both lighted. 3.
- Page 4 1. Mode button: When press this button, the operation mode changes as the following sequence: But for the cooling only model, the heating mode is skipped. 2. TIMER ON button: Press this button, timer-on function is active. Then every press, the time will increase 0.5h, after 10 hours, increase by 1 hour for each press.
- Page 5 4. FOLLOW ME button: When under cool, heat and auto mode, and press this button, follow me function is active. Press again, this function is ineffective. 5. AUXIL HEATER button: (Only available for Cooling only with EHK model.) If press this button in heat mode, electrical heater function become ineffective. 6.
-
Page 6: Operation
13. LOCK button: (Hidden) When push the LOCK button, all current settings are locked in and the wired controller does not accept any instruction except that of the LOCK button. Use the lock mode when want to prevent setting from being changed accidentally or play fully. Push the LOCK button again when want to cancel the lock mode. - Page 7 Step 2: Press temperature adjust button to select setting temperature. Step 3: Press ON/OFF button, indoor unit operation lamp on, it works in dry mode. Press ON/OFF button again, it stops to work. Notes: Under dry mode, economy operation and fan speed adjustment are ineffective. Timer setting The timer time is relative time, and that is delay after setting time.
- Page 8 Notes: Timer-off time must be longer than timer-on time. Step 3: 0.5 second after setting, the wired controller send information to the unit. And the setting is finished. Change timer When need to change timer time, press corresponding button to revise it. If cancel timer, please change timer time to 1.5 Installation of wired controller Caution...
- Page 9 Accessories Item Quantity Remarks Wired controller Wood mounting screw M4×20 (For mounting on the wall) Mounting screw M4×25 (For mounting on the electrical switch box) Installation manual Owner’s manual 5P terminal group Installation screw For fixing terminal. Preparing at site Item Quantity Remarks...
- Page 10 Installation figure as following: A: Turn a screwdriver at the concave on bottom panel of the wired controller to remove the back cover. B: When installing the wired controller cover, it is sure that there is a hole in the wall to avoid the wired controller back cover being fixed directly to the wall which is not allowed for the wire joint extrudes out of the back cover.
- Page 11 Eurofred S.A Marqués de Sentmenat 97 08029 Barcelona www.eurofred.es...
