- Page 1 CROSSFADE 3 WIRELESS XFBT3 OVER-EAR BLUETOOTH HEADPHONES ® USER MANUAL...
- Page 2 Before using this product, carefully read the safety and warranty information in the booklets provided. Please then keep the documents where they can be available for immediate reference. To acquire a full printable version of the manual, please visit www.v-moda.com/manuals...
-
Page 3: Important Notes
IMPORTANT NOTES * This document explains the specifications of the product at the time that the document was issued. For the latest information, refer to www.v-moda.com. * Use a standard USB AC adaptor (5V /over 500mA) for charging. * This product is equipped with a lithium-ion battery. - Page 4 WELCOME Welcome to V-MODA, the music lifestyle. We sincerely hope you enjoy our headphones, the pinnacle of sound and quality design. With the essence of music at the foundation of all we do, we have precisely engineered our headphones to provide an enjoyable and...
-
Page 5: Package Contents
PACKAGE CONTENTS Crossfade 3 Wireless Over-Ear Headphones Accessories Headphones BoomPro X Mic, custom metal shields, Audio Cables, 3-Button SpeakEasy Mic Carrying Case Cable and XL cushions are available at 1-Button SpeakEasy Mic Cable www.v-moda.com. USB-C Charging Cable 1/4" Pro Adapter... -
Page 6: Using Your Headphones
USING YOUR HEADPHONES Very important: Place earcups on Push hair back, extend the earcups corresponding ear. “L” on left ear, “R” from headband until they fit on right ear comfortably on ear, creating a snug fit to ensure highest sound quality and comfort... - Page 7 When wearing headphones wired When using the included cable, insert (with cable connected), hang cable straight plug into earcup (not 45° in front of your head to ensure angled plug) headphones stay put during strenuous activity...
- Page 9 Volume Down Volume Up 3-Way Switch / LED Indicator Multifunction Microphone 3.5mm Stereo Mini Port Charge Port...
- Page 10 Once powered on, slide 3-way switch to the right, hold 3 seconds, when the LED starts to blink twice per second, release the switch. The switch will return to the “V-MODA Crossfade 3” middle position and begin to search. Once appears in the “new Bluetooth devices”...
-
Page 11: Pairing A Second Device
Once powered on, slide switch to the right, hold 3 seconds, when the LED starts to blink twice per second, release the switch and enter secondary pairing mode (sonar sound) When “V-MODA Crossfade 3” appears in the “new Bluetooth devices” section on your device, select it to pair... - Page 12 To switch between devices via multipoint, ensure that both of your paired devices have Bluetooth activated Turn the headphones off and then on again Select “V-MODA Crossfade 3” in the Bluetooth settings of the device you want to play audio from Press “Play” to play audio from your selected device The headphones will now switch its active connection to your selected device.
-
Page 13: Multifunction Button
MULTIFUNCTION BUTTON Answer a call Press once (music pauses automatically) Refuse incoming call Press and hold for 1-2 seconds then release Play and pause audio Press once Skip to next song Press twice Go to previous track Press three times Summon voice assistant Press and hold for 3 seconds* *Depending on your devices, there may be restrictions on the use of the voice assistant. -
Page 14: Volume Buttons
VOLUME BUTTONS Volume Up Press + button Volume Down Press – button Reset paired device history Press and hold "+" and "-" at the same time for 3 seconds. LED lighting will change to blinking white... -
Page 15: Wired Mode
WIRED MODE DURING MUSIC PLAYBACK • Click V button once to pause and again to resume playback • Click V button twice quickly for next track • Click V button three times quickly for previous track DURING CALLS • Click V button once to answer incoming call, click once to end call •... -
Page 16: Getting Started With The App
GETTING STARTED WITH THE APP Get the “V-MODA HEADPHONE EDITOR” app from Google Play or the App Store and download/install the app to your device Pair the headphones with your device settings Go to STEP BY STEP GUIDE 2 PAIRING NEW DEVICES... - Page 17 • Close any application on your device that is not in use and disable Wi-Fi In case, you cannot connect After closing the app and disconnect Bluetooth, try the following procedures: Delete V-MODA Crossfade 3 from Bluetooth device list of your device Clear headphones' device paired history by following STEP BY STEP GUIDE 8...
-
Page 18: Folding Your Headphones
FOLDING YOUR HEADPHONES Hold the two ear cups lightly together, cushion to cushion Place the heel of other hand on top of headband Push gently together to activate the CliqFold hinge Place the headphones in the carrying case, with the headband placed closest to the case’s hinge Insert any cables you wish in the extra space below Zip the carrying case to close... -
Page 19: Troubleshooting
TROUBLESHOOTING If you are experiencing trouble with your headphones, please refer to the troubleshooting guidelines below. If the problem persists, please contact the V-MODA Support Team or the nearest Roland service center. TROUBLE SUGGESTIONS Pairing process • Make sure headphones are not connected to the charger and... - Page 20 TROUBLE SUGGESTIONS Receiving no • Check the battery audio or low • Check the pairing quality audio from • Make sure the audio source is playing an audio source • Make sure the volume on the device is not muted or turned down •...
- Page 21 TROUBLE SUGGESTIONS Audio and video Try streaming from another device or select another track. do not match Due to technology limitations, there may be a delay from some sources or applications No audio (in wired Make sure the audio device and the headphones jacks are free mode) of debris and that the cable is securely connected Lack of or...
- Page 22 TROUBLE SUGGESTIONS Distorted sound Check to make sure the problem is not with the audio device or the file you are listening to. Ensure the EQ settings on the device are set properly. Make sure you have a snug fit and that the driver is pointing directly towards the ear Headphones will •...
- Page 23 (50–86 °F) • If the indicator continues blinking fast orange even though you are charging in the recommended temperature range, contact the V-MODA Support Team or your dealer or nearest Roland service center Headphones are Charge the headphones and then turn on...
- Page 24 ©2022 V-MODA. All rights reserved. V, V-MODA and the V-MODA logo are registered trademarks of V-MODA. Patents: roland.cm/patents The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. ® and any use of such marks by V-MODA is under license.
- Page 25 ISSUES WITH THE PRODUCT For any issues relating to your V-MODA product, please contact our Support Team directly. VISIT www.v-moda.com/support EMAIL support@v-moda.com CALL +1 888.866.3252...
- Page 26 REGISTER NOW AT www.v-moda.com/register...
