InterConnect Lock System
Lock Set Up and Update Instructions
The InterConnect lock system features an easy-to-follow
interface. Using the keypad, follow the prompts to set up and
update your lock information.
Table of Contents:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Overview
The lock system stores up to 9,800 individual users and administrator
codes per fleet at each facility within a healthcare system.
InnerSpace carts feature access control RFID from industry-leader HID
and read both iClass (13.56 MHz) and Proximity (125 kHz) frequencies
in any format. iClass and Proximity badges are compatible with our
products.
To order RFID cards, call InnerSpace Customer Service at 888-435-2256.
Access Types
•
PIN - enter 4-digit PIN code
•
Badge - Scan a badge
•
PIN or Badge - Scan a badge or enter a 4-digit PIN code
•
PIN and Badge - Scan a badge and enter a 4-digit PIN code
Location of badge scanner
Access Rights
•
Administrators have access rights and can add and remove user
and administrator profiles; users have access only.
•
User and administrator profiles contain card information and/or a
PIN. Each profile identifies access type and credentials.
Response to Power or Battery Failure
•
The lock's non-volatile memory retains access information and
settings in the event of a power failure.
•
Every InnerSpace electronic lock is equipped with a key override
for emergency access or access in the event of battery failure.
Warranty
InnerSpace InterConnect locks are warranted to the original purchaser to
be free from defects in material and workmanship for one (1) year from
the date of purchase.
S t o r a g e s o l u t i o n s f o r h e a l t h c a r e
1
Advertisement
Table of Contents
Related Manuals for Solaire Medical InnerSpace InterConnect
Summary of Contents for Solaire Medical InnerSpace InterConnect
-
Page 1: Table Of Contents
Every InnerSpace electronic lock is equipped with a key override for emergency access or access in the event of battery failure. Warranty InnerSpace InterConnect locks are warranted to the original purchaser to be free from defects in material and workmanship for one (1) year from the date of purchase. -
Page 2: Settings
InterConnect Lock System Lock Set Up and Update Instructions Settings Settings can be accessed by the administrator. The default administrator PIN is 5143. To start, enter credentials (PIN, badge, PIN or badge, and PIN and badge) Select Settings Settings display has four options: •... -
Page 3: Lock
InterConnect Lock System Lock Set Up and Update Instructions Lock Select (1) from Settings menu to access Lock Select (2) to access the Setup menu (1) Lock (1) Information (1) Auto Lock (2) User (2) Setup (2) Lockout (3) Wi-fi (1) Lock (4) Access (2) User... -
Page 4: User
InterConnect Lock System Lock Set Up and Update Instructions User These instructions reference all access types, but some screens may (3) Modify User or Admin: look different depending on whether you’ve been assigned PIN only, Select by (1) Name, (2) PIN, or (3) Card (badge). Select 5 to view Badge only, PIN or badge, or PIN and badge. -
Page 5: Wi-Fi
InterConnect Lock System Lock Set Up and Update Instructions User (continued) Wi-Fi (4) Remove User or Admin: InterConnect locks can be connected to Wi-Fi to access the subscription- based Smart Solutions platform, which allows administrators to manage Select by (1) Name, (2) PIN, or (3) Card (badge). Select 5 to view InterConnect locks remotely via computer. - Page 6 InterConnect Lock System Lock Set Up and Update Instructions (1) Lock (2) User (1) Connect to Wi-fi (1) Edit Sync Interval (1) Edit Sync Interv (3) Wi-fi (2) Network Status (2) Check Sync (4) Access (3) Cloud Configuration (3) Force Sync Current Sync Interv SELECT NUMBER OR BACK SELECT NUMBER OR BACK...
-
Page 7: Access
InterConnect Lock System Lock Set Up and Update Instructions Access Select (4) from Settings menu for Access (1) Lock (2) User (3) Wi-fi (4) Access (1) Lock (2) User SELECT NUMBER OR BACK (3) Wi-fi (4) Access Select the lock latch you’re assigning access type to. A Pace cart will SELECT NUMBER OR BACK have 1 lock latch, a Roam cart could have 1 or 2 lock latches depending (1) Lock Latch 1... -
Page 8: Unlocking The Cart
InterConnect Lock System Lock Set Up and Update Instructions Unlocking the Cart Resetting Factory Settings The InterConnect home screen displays the cart name and location The reset function clears all user data from the lock as well as that was entered during lock setup. audit records, lock preferences, network configuration, and device serial number. -
Page 9: Replacing Batteries
Marne, Michigan 49435 888-435-2256 phone 616-743-5944 fax innerspacehealthcare.com © 2021 Solaire Medical, Marne, MI 49435 ® InnerSpace is a registered trademark of Solaire Medical LLC, Marne, MI 49435 ™ Ventaire is a trademark of Solaire Medical LLC, Marne, MI 49435 1021...
