SMMI-FLEX SMMI-FLEX Fixed height mobile floor stand Soporte con altura fija de ruedas Installation manual Manual de instalación Manuale di installazione Asennusopas Manuel d’installation.
TRAULUX SMMI-FLEX No seguir estas instrucciones puede provocar accidentes y fallos en el producto. Failure to follo these instructions may result in accidents or the product being damaged. INSTRUCCIONES DE SEGURIDAD / SAFETY INSTRUCTIONS GENERAL: Este producto no se ha diseñado para el uso por parte de niños pequeños.
Page 6
DIN 912 M8x70 (x4) TRAULUX SMMI-FLEX DIN 912 M8x70 (x4) DIN 912 M8x80 (x4) ALLEN M6 DIN 912 M8x80 (x4) DIN 912 M8x70 (x6) ALLEN M8 DIN 912 M10x30 (x4) Self-locking nut (x6) Self-locking nut M10 (x4) 7 mm spile (x4)
Page 7
TRAULUX SMMI-FLEX DIN 912 M10x80 (x4) Self-locking nut M10 (x8) Washer M10 (x16) ALLEN M10 ALLEN M10 DIN 912 M10x80 (x4) DIN 912 M10x20 (x4) Self-locking nut M10 (x8) Washer M10 (x16)
