MS3C-300WC
Battery Operated Stair Climbing Trolley for Wheelchairs
Deploying Wheelchair Stair Chair:
1. To unfold chair, grasp backrest with one hand
and grasp the seat with other hand. Slowly
guide chair into a fully open position.
2. Chair will automatically lock when it reaches
its fully open position. You may now roll chair.
Battery Installation:
1. Align battery power along battery support
rail located on the back of chair.
2. Slide battery into place.
3. Lock battery onto rail by turning locking key.
4. Chair is now ready for use.
IMPORTANT: Follow all local safety protocols
Loading Wheelchair into Trolley:
1. Position wheelchair in front of trolleys red wheel
supports to have a visual reference of the distance
needed between the supports.
2. Pull red wheel support adjustment knob out and up
to release locking mechanism on trolleys wheel
supports.
3. Slide the red wheel supports in or out to the
distance necessary to allow for wheelchairs wheels
to slide onto wheel supports.
User Manual
toll free: 1-877-706-4480
international/local: 713-706-4480
fax: 713-706-4161
www.MS3C.co
Advertisement
Table of Contents
Related Manuals for MS3C MS3C-300WC
Summary of Contents for MS3C MS3C-300WC
- Page 1 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co MS3C-300WC Battery Operated Stair Climbing Trolley for Wheelchairs User Manual Deploying Wheelchair Stair Chair: 1. To unfold chair, grasp backrest with one hand and grasp the seat with other hand. Slowly guide chair into a fully open position.
- Page 2 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co Note: Adjust wheelchair so that it is centered on the trolley before locking the wheel support knob. Wheelchair should be all the way back, with trolley frame centered between the wheelchair push handles.
- Page 3 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co 1. Operator will roll the evacuation chair to top of the staircase. 2. Turn on battery with red button located on the bottom of the battery pack. 3. Operator will LOCK rear casters.
- Page 4 1-877-706-4480 international/local: 713-706-4480 fax: 713-706-4161 www.MS3C.co position making sure front wheels are securely placed on ground. 7. Operator will then disengage track by pushing red release bar located on the back of chair and pushing in. Make sure track is in closed locked position.
