MS3C -300TSB Manual

Battery Powered Stair Evacuation
MS3C-300TSB

Deploying Chair:

1. To unfold chair, release seatbelt, grasp backrest with one hand and
grasp the seat with other hand. Slowly guide chair into a full open
position.
2. Chair will automatically lock when it reaches its full open position. You
may now roll the chair.

Battery Installation:

1. Align the battery power along the battery support rail located under the chair.
2. Slide the battery into place.
3. Lock battery onto the rail by turning the locking key.
4. Chair is now ready for use.
IMPORTANT: Follow all local safety protocols

Preparing for passenger loading:

1. Roll evacuation chair next to patient, once chair is in position,
LOCK rear wheels.
2. To lock rear wheels, push down the red lever located on top of
rear wheels.
3. Make sure locks are engaged by trying to move chair.
4. If chair does not move, you are ready to seat and secure your
passenger.

Loading your Passenger:

1. Assist your passenger into seat using side handlebars for support
and balance if necessary.
2. Secure your passenger with horizontal lap and shoulder belts.
3. Place passenger's feet on foot rest

Patient Transport Descending Stairs:

Chair
