User Guide
The Tubing Connector joins two pieces of oxygen tubing
together. Intended to be used with patients who have a
prescription for oxygen therapy in the home, outpatient,
extended care, transport, and hospital environments.
The Tubing Connector is available in swivel and
non-swivel configuration.
Product Use
1. Wash hands. Open package and remove the Tubing Connector.
2. Hold the middle of the Tubing Connector and
align with the oxygen tubing end.
3. Insert, push, and twist the tapered end of the Tubing Connector
into oxygen tubing end connector.
4. a–Repeat step 3 to attach the other side of the connector
to the nasal cannula or oxygen mask tubing.
b–Gently tug on connection to check for a secure fit.
5. To remove Connector, hold the center of the Tubing Connector,
twist and pull on the tubing end connector.
1
NASAL CANNULA
Tubing Connector
Please read and follow the Instructions for Use
provided with the products prior to using the Tubing Connector.
TUBING CONNECTOR
OXYGEN TUBING
2
3
4
5
800-433-2797
www.Sun-Med.com
Advertisement
Table of Contents
Related Manuals for SUNMED UG-10007
Summary of Contents for SUNMED UG-10007
- Page 1 User Guide Tubing Connector Please read and follow the Instructions for Use provided with the products prior to using the Tubing Connector. The Tubing Connector joins two pieces of oxygen tubing together. Intended to be used with patients who have a prescription for oxygen therapy in the home, outpatient, extended care, transport, and hospital environments.
- Page 2 User Guide Tubing Connector Troubleshooting Guide PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Flow control valve is not turned on. Set flow control to prescribed setting. Oxygen system is not functioning properly or oxygen Switch to backup oxygen. container is empty. No oxygen flow from The nasal cannula is disconnected from oxygen device Reconnect oxygen tubing.
