AquaLogic HydroMate 3000 Installation & Setup Instructions

Download this manual

URINAL CONTROL SYSTEMS

HydroMate 3000

Installation & Setup

Please check your box has the following contents

You will require the following:

1mm twin & earth flex

Cable Clips, Trunking or Conduit

20mm Cable glands, wall or celing

fixing Screws/plugs.

Recommended:

15mm isolation valve "AQRIV" (To comply with water regulations)

Supply from fused spur using 3 amp fuse (BS1361)

AUQHM

Instructions

1 x Hydromate control standard surface mount

box.

1 x 15mm 230v Solenoid Valve.

Need help?

Do you have a question about the HydroMate 3000 and is the answer not in the manual?

Page 1 URINAL CONTROL SYSTEMS HydroMate 3000 Installation & Setup Instructions Please check your box has the following contents 1 x Hydromate control standard surface mount box. 1 x 15mm 230v Solenoid Valve. You will require the following: 1mm twin & earth flex...
Page 2 Thank you for purchasing Aqualogic’s Hydromate. Following these guidelines will help you to get the most from your product. Hydromate 3000 Features Explained Flush Frequency. Set at 10 mins, the urinal will flush 10 minutes after detecting the first user. Set at 40 mins, the urinal will flush 40 mins after detecting first user. This can be al- tered at any time after set up.
Page 3 Hydromate 3000 — identification Hydromate 3000 Control Panel Solenoid Valve Connections Dia 1 Dia 2 Valve Dia 3 Flush Frequency 230v supply Table 1 Using the Blue DIL Switch, select Flush Frequency, (See above Diagram 3). For cistern fed urinals to comply with IRN R075 refer to Table 1.
Page 4 Hydromate 3000 - Lighting Controls Hydromate Control Panel Sections Dia 4 Lights on Illustration shown: Reset Button time delay 1,2,3 on (up) = 15 minutes All Switches off = 1min Sw1 on adds 2 mins Sw2 on adds 4 mins...
