Important before assembly:
Read these instructions carefully before assembling or using the product.
Please check the contents of the boxes before attempting to assemble this product. The instructions will
have a checklist of parts and fittings.
It would be sensible to lay a rug or a carpet on the floor where you intend to assemble the product, to avoid
scratches and damaging the product or the floor.
Assemble the product as close to its intended final location/room as possible.
Do NOT use any power tools as this may damage the frame.
Health & Safety:
This product or some parts of this product will be heavy. Please use an assistant when lifting.
Please keep small parts out of reach of children.
Always use on a level, even surface.
DO NOT jump on the product or any of its parts.
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Please keep these instructions for future reference.
Assembly Instructions
Malmo - King
.
.
www.happybeds.co.uk
Advertisement
Related Manuals for Happybeds Malmo - King
Summary of Contents for Happybeds Malmo - King
- Page 1 Assembly Instructions Malmo - King Important before assembly: Read these instructions carefully before assembling or using the product. Please check the contents of the boxes before attempting to assemble this product. The instructions will have a checklist of parts and fittings.
- Page 2 Never drag or push the pieces across a hard or stone floor as this will cause damage to the joints. Use a carpet or a rug for extra care. If you have problems assembling or have damaged or missing pieces, please contact us by visiting: https://www.happybeds.co.uk/customer-service...
- Page 3 Parts List Parts Description Headboard Frame 1 / 4 Left Wooden Post 2 / 4 Right Wooden Post Footboard 1 / 4 Left Side Rail Right Side Rail 4 / 4 Centre Storage Panel Back Storage Panel Hydraulic Arm Spacer Left Side Metal Bar Right Side Metal Bar Headboard End Metal Bar...
- Page 4 Hardware List (Found in box #) Parts Description Mini Fix 8 x 30 mm Wooden Dowel Metal Corner Block M6 x 90 mm RBW + Barrel Nut M8 x 25 mm JCBC Bolt RBW M8 x 15 mm JCBC Bolt RBW 3 / 4 M8 x 35 mm JCBC Bolt RBW M6 x 15 mm JCBC Bolt RBW...
- Page 5 Step 1: Attach the headboard frame (1) and back storage panel (8) to the left wooden post (2) and right wooden post (3). Secure the headboard frame using hardware parts B, D and P, then secure the back storage panel with hardware parts B, H and I. DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 6 Step 3: Join together the left side rail (5) and right side rail (6) with the centre storage panels (7) using hardware parts A and B. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 4: Attach the headboard frame (1) and footboard (4) using hardware part E.
- Page 7 Step 5: Fix metal corner block C to the edge of footboard and side rails with bolt F as shown. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 6: Join together all the bed base parts (10),(11),(12),(13) and (14) using hardware parts L,T,U and also attach hardware part K by slot to the part (13).
- Page 8 Step 7: Insert the slats (16) to hardware parts N and O then press into the base making sure they are secure. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 10: Assemble the bed base on the right &...
- Page 9 Step 10: Adjust the bed base making sure that the distance to the footboard is approximately 15 mm to above. Tighten all bolts and screws now. DO NOT use any power tools as this may damage the frame and will invalidate any claim. HEADBOARD 15 mm to above FOOTBOARD...
-
Page 10: Important Note
IMPORTANT NOTE WHEN THE BED IS BUILT AND THE MATTRESS FRAME IS AT 45 DEGREE ANGLE PLEASE PLACE THE MATTRESS ON THE BED. PLEASE NOTE THAT THE WEIGHT OF THE MATTRESS IS REQUIRED TO HELP CLOSE THE BED. TO LOWER THE SLEEPING PLATFORM STAND AT THE FOOT END OF THE BED AND PUSH SHARPLY DOWNWARDS USING BOTH HANDS. - Page 11 CAUTION : PLEASE USE HYDRAULIC PUMP STOPPER FOR SAFETY PURPOSE. HYDRAULIC PUMP STOPPER (LOCK IN) (LOCK OUT) Page 11 of 12...
- Page 12 If this is not adhered to, it could result in failure to the product that will invalidate the warranty. For more information on cleaning and product care visit: https://www.happybeds.co.uk/help-and-advice Notes We’ve tried to make this product as easy to assemble as possible. In the unlikely event that...
