Quanser QNET 2.0 HVAC Quick Start Manual

Quick Start Guide:
STEP 1
Check Components and Details
Make sure your QNET HVAC experiment includes the following components:
1
STEP 2
Additional Components Required
To complete your QNET HVAC setup, you will also need the following hardware:
1
STEP 3
Install LabVIEW and Add-Ons
Make sure the following versions of LabVIEW™ and required add-ons are installed:
1. LabVIEW™ 2012 or later
2. NI DAQmx 9.5.5 or later
3. NI ELVISmx 4.4 or later
4. LabVIEW™ Control Design and Simulation Module 2012 or later
QNET 2.0 HVAC
2
3
2
1. Quanser QNET 2.0 HVAC board
2. 24VDC, 2.7A Power Supply
Note: The QNET curriculum resources are
available for download at www.ni.com/qnets
1. NI ELVIS II or NI ELVIS II
2. +5VDC / 5A, +15VDC / 2A,
-15VDC / 0.8A Power Supply
3. USB Cable
Power Cable for the QNET 2.0 HVAC
4.
power supply (available through
National Instrument based on your
4
country's power/voltage requirements)
Note:
this guide apply to both NI ELVIS II
and NI ELVIS II
+ workstation
All references to NI ELVIS II in
devices.
+
